Xpander - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
xpander	oberheim/xpander.cpp		no	no	no	yes	Xpander	1984	Oberheim

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
exp1.2-0.u8	8192	dc3801b1	4064edc2fa0bea62684c28e8e004feb8229604fe	main_68b09	0	good	no		1.2
exp1.2-1.u7	8192	b57f8482	233efc3da3a96777b10a4d6fe7e80864e9231f04	main_68b09	2000	good	no		1.2
exp1.2-2.u6	8192	30f28710	798c1b28fb59819baadbf0142ecd1348e759fa70	main_68b09	4000	good	no		1.2
exp1.2-3.u5	8192	0bc8335e	5897ad0cd66cf37b8e9b277654aab4eb83d1c8ab	main_68b09	6000	good	no		1.2
exp1.0-0.u8	8192	d93fb34c	e470589562f6544507c276ccfc95632a6288eb18	main_68b09	0	good	no		1.0
exp1.0-1.u7	8192	80912a48	064e9fff26a4ebf8902c3e085fa631bb5579a160	main_68b09	2000	good	no		1.0
exp1.0-2.u6	8192	89e14d6e	7aef67db9d78523777af6f1edf04fd6b0d11229b	main_68b09	4000	good	no		1.0
exp1.0-3.u5	8192	21794b92	e544375c3fc29931497cb6429db7a2812f77c553	main_68b09	6000	good	no		1.0
ca1.4-0.u912	8192	79f4490a	5ab13ccc3b75df313a447520ca54a492102b7e3b	voice_68b09	2000	good	no
ca1.4-1.u914	8192	9b7a7914	951bbc197a0140a93bb7621a7aedbe0f4037990c	voice_68b09	4000	good	no

chip

type	tag	name	clock
cpu	main_68b09	Motorola MC6809	8000000
cpu	voice_68b09	Motorola MC6809	8000000

device_ref

name
mc6809
timer
nvram
nvram
acia6850
clock
midi_port
midiout_port
midiout
midi_port
midiout_port
midiout
midi_port
midiin_port
midiin
adc0804
pwm_display
pwm_display
pwm_display
mc6809
pit8253
pit_counter
pit_counter
pit_counter
output_latch
output_latch
output_latch

biosset

name	description	default
1.2	Xpander Main Processor Revision 1.2	yes
1.0	Xpander Main Processor Revision 1.0	no

sound

channels
0

feature

type	status	overall
sound	unemulated

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiout	mdout:midiout:midioutimg				midiout1	mout1
midiout	mdthru:midiout:midioutimg				midiout2	mout2
midiin	mdin:midiin:midiinimg				midiin	min

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiout	mdout:midiout:midioutimg				mid
midiout	mdthru:midiout:midioutimg				mid
midiin	mdin:midiin:midiinimg				mid, syx

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
dial				no	0	255	30
positional				no	0	30	20	1
pedal				no	0	255	30

port, analog

port_tag	analog_masks
:cv_in_1	255
:cv_in_2	255
:cv_in_3	255
:cv_in_4	255
:cv_in_5	255
:cv_in_6	255
:encoder_0	31
:encoder_1	31
:encoder_2	31
:encoder_3	31
:encoder_4	31
:encoder_5	31
:gate_inputs
:mdin:midiin:midiinimg:CFG
:memory_protect
:pedal_1	255
:pedal_2	255
:switches_0
:switches_1
:switches_2
:switches_3
:switches_4
:switches_5
:switches_6
:switches_7

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdout	midiout	midiout_port	yes
mdthru	midiout	midiout_port	yes
mdin	midiin	midiin_port	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
