Xyonix - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
xyonix	misc/xyonix.cpp		no	no	no	yes	Xyonix	1989	Philko

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	61.515748	8000000	508	0	320	256	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
xyonix3.bin	65536	1960a74e	5fd7bc31ca2f5f1e114d3d0ccf6554ebd712cbd3	maincpu	0	good	no
mc68705p3s.e7	1920	f60cdd86	e18cc598153b3e108942328ee9c5b9f83b034c41	mcu	0	baddump	no
xyonix1.bin	32768	3dfa9596	52cdbbe18f83cea7248c29588ea3a18c4bb7984f	tiles	0	good	no
xyonix2.bin	32768	db87343e	62bc30cd65b2f8976cd73a0b349a9ccdb3faaad2	tiles	8000	good	no
xyonix.pr	256	0012cfc9	c7454107a1a8083a370b662c617117b769c0dc1c	proms	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	mono	Speaker
audio	sn1	SN76496	4000000
audio	sn2	SN76496	4000000

device_ref

name
z80
screen
gfxdecode
palette
mc6845
speaker
sn76496
sn76496

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSW
:P1
:P2

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	3	yes
Normal	2	no
Hard	1	no
Hardest	0	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	48

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	16	no
1 Coin/1 Credit	48	yes
2 Coins/3 Credits	0	no
1 Coin/2 Credits	32	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	192

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	64	no
1 Coin/1 Credit	192	yes
2 Coins/3 Credits	0	no
1 Coin/2 Credits	128	no
