Mahjong Yoshimoto Gekijou (Japan, medal) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
yosimotm	nichibutsu/nbmj9195.cpp		no	no	no	yes	Mahjong Yoshimoto Gekijou (Japan, medal)	1994	Nichibutsu / Yoshimoto Kougyou	yosimoto	yosimoto

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	240	60.000000	31457280	1024	0	640	512	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
1.7c	65536	d156b07d	8dcf2d8ac60920dc7ea286d4b91399ed2db05a3b	maincpu	0	good	no
2.12e	131072	e2d84085	890b4d4a02030253837b67e8232293dce30d7ca2	nichisnd:audiorom	0	good	no
3.3h	524288	f421c6c8	f9d68f542cbf379a7c41b47704b19e1aec69f237	blitter	0	good	no
4.5h	524288	a9b17359	84cb71ab32e069c8ff8cffff7badb3a823d3abfd	blitter	80000	good	no
5.5h	524288	927517b7	de4fcc4e87bc1a31834ffb2312b8cee167ec16b5	blitter	100000	good	no	5.5h
6.6h	524288	31b0b9de	b68c2028859b6804fe66a500f6afc375c1634bcd	blitter	180000	good	no	6.6h
7.7h	524288	a7249937	81d4adfb4bebe1e94fbbe70b7346c97f582f07a8	blitter	200000	good	no	7.7h
8.8h	524288	a3cd2458	a82b011a880f0d47362d2e70b9d77db85d83e6ed	blitter	280000	good	no

chip

type	tag	name	clock
cpu	maincpu	Toshiba TMPZ84C011	6000000
cpu	nichisnd:audiocpu	Toshiba TMPZ84C011	8000000
audio	nichisnd:speaker	Speaker
audio	nichisnd:ymsnd	YM3812 OPL2	4000000
audio	nichisnd:dac1	8-Bit R-2R DAC
audio	nichisnd:dac2	8-Bit R-2R DAC

device_ref

name
tmpz84c011
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
ttl166
timer
ttl166
timer
screen
palette
nichisnd
tmpz84c011
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
speaker
generic_latch_8
ym3812
dac_8bit_r2r
dac_8bit_r2r
nvram

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mahjong	1	26		no
mahjong	2	26		no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:P1_KEY0
:P1_KEY1
:P1_KEY2
:P1_KEY3
:P1_KEY4
:P2_KEY0
:P2_KEY1
:P2_KEY2
:P2_KEY3
:P2_KEY4
:SYSTEM

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	1

location

name	number	inverted
DSWA	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	2

location

name	number	inverted
DSWA	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	4

location

name	number	inverted
DSWA	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	8

location

name	number	inverted
DSWA	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	16

location

name	number	inverted
DSWA	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	32

location

name	number	inverted
DSWA	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Character Display Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Character Display Test	DSWA	64

location

name	number	inverted
DSWA	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Graphic ROM Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphic ROM Test	DSWA	128

location

name	number	inverted
DSWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWB	1

location

name	number	inverted
DSWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Character Display Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Character Display Test	DSWB	2

location

name	number	inverted
DSWB	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Score Pool

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Score Pool	DSWB	4

location

name	number	inverted
DSWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	8

location

name	number	inverted
DSWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	16

location

name	number	inverted
DSWB	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	32

location

name	number	inverted
DSWB	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	64

location

name	number	inverted
DSWB	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	128

location

name	number	inverted
DSWB	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	SYSTEM	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no
