Zankor (TMS5220 Italian speech) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
zankor2i	pinball/zac_2.cpp	genpin	no	no	yes	yes	Zankor (TMS5220 Italian speech)	1986	Zaccaria	zankor	zankor

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
zan_ic1.764	8192	e7ba5acf	48b64921dd8a22c2483162db571512cad8cbb072	maincpu	0	good	no	zan_ic1.764
zan_ic2.764	8192	5804ff10	fc3c4acb183c5c3e0a6504583c78f25a7a322cce	maincpu	800	good	no	zan_ic2.764
zan_1e.764	8192	3d2c53d2	2de4a56f50752a97af0acfed816eae83b36cf7af	cpu2	a000	good	no
zan_1f.128	16384	74fcadc9	efd6fc99d7a3ed8e59fbbafbee161af6fb527028	cpu2	c000	good	no	zan_1f.128
zan_ic4.128	16384	f34a2aaa	5e415874f68586aa30dba9fff0dc8990c636cecd	cpu3	0	good	no	zan_ic4.128
zan_ic5.128	16384	bf61aab0	939266696d0562f255f0fa5068280fe6a4cf8267	cpu3	4000	good	no	zan_ic5.128
zan_ic6.128	16384	13a5b8d4	d8c976b3f5e9c7cded0922feefa1531c59432515	cpu3	8000	good	no	zan_ic6.128

chip

type	tag	name	clock
cpu	maincpu	Signetics 2650	3000000
audio	mechvol	Speaker
audio	samples	Samples

device_ref

name
s2650
nvram
timer
timer
speaker
samples

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		54		no

port, analog

port_tag	analog_masks
:DSW
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7

dipswitch

Switch A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch A	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Switch B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch B	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Switch C

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch C	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Switch D

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch D	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no
