Zektor (revision B) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
zektor	sega/segag80v.cpp		no	no	no	yes	Zektor (revision B)	1982	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	vector	180			40.000000								yes

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
1611.cpu-u25	2048	6245aa23	815f3c7edad9c290b719a60964085e90e7268112	maincpu	0	good	no
1586.prom-u1	2048	efeb4fb5	b337179c01870c953b8d38c20263802e9a7936d3	maincpu	800	good	no
1587.prom-u2	2048	daa6c25c	061e390775b6dd24f85d51951267bca4339a3845	maincpu	1000	good	no
1588.prom-u3	2048	62b67dde	831bad0f5a601d6859f69c70d0962c970d92db0e	maincpu	1800	good	no
1589.prom-u4	2048	c2db0ba4	658773f2b56ea805d7d678e300f9bbc896fbf176	maincpu	2000	good	no
1590.prom-u5	2048	4d948414	f60d295b0f8f798126dbfdc197943d8511238390	maincpu	2800	good	no
1591.prom-u6	2048	b0556a6c	84b481cc60dc3df3a1cf18b1ece4c70bcc7bb5a1	maincpu	3000	good	no
1592.prom-u7	2048	750ecadf	83ddd482230fbf6cf78a054fb4abd5bc8aec3ec8	maincpu	3800	good	no
1593.prom-u8	2048	34f8850f	d93594e529aca8d847c9f1e9055f1840f6069fb2	maincpu	4000	good	no
1594.prom-u9	2048	52b22ab2	c8f822a1a54081cfc88149c97b4dc19aa745a8d5	maincpu	4800	good	no
1595.prom-u10	2048	a704d142	95c1249a8efd1a69972ffd7a4da76a0bca5095d9	maincpu	5000	good	no
1596.prom-u11	2048	6975e33d	3f12037edd6f1b803b5f864789f4b88958ac9578	maincpu	5800	good	no
1597.prom-u12	2048	d48ab5c2	3f4faf4b131b120b30cd4e73ff34d5cd7ef6c47a	maincpu	6000	good	no
1598.prom-u13	2048	ab54a94c	9dd57b4b6e46d46922933128d9786df011c6133d	maincpu	6800	good	no
1599.prom-u14	2048	c9d4f3a5	8516914b49fad85222cbdd9a43609834f5d0f13d	maincpu	7000	good	no
1600.prom-u15	2048	893b7dbc	136135f0be2e8dddfa0d21a5f4119ee4685c4866	maincpu	7800	good	no
1601.prom-u16	2048	867bdf4f	5974d32d878206abd113f74ba20fa5276cf21a6f	maincpu	8000	good	no
1602.prom-u17	2048	bd447623	b8d255aeb32096891379330c5b8adf1d151d70c2	maincpu	8800	good	no
1603.prom-u18	2048	9f8f10e8	ffe9d872d9011b3233cb06d966852319f9e4cd01	maincpu	9000	good	no
1604.prom-u19	2048	ad2f0f6c	494a224905b1dac58b3b50f65a8be986b68b06f2	maincpu	9800	good	no
1605.prom-u20	2048	e27d7144	5b82fda797d86e11882d1f9738a59092c5e3e7d8	maincpu	a000	good	no
1606.prom-u21	2048	7965f636	5c8720beedab4979a813ce7f0e8961c863973ff7	maincpu	a800	good	no
1607.speech-u7	2048	b779884b	ac07e99717a1f51b79f3e43a5d873ebfa0559320	speech:cpu	0	good	no
6331.speech-u30	32	adcb81d0	74b0efc7e8362b0c98e54a6107981cff656d87e1	speech:proms	0	good	no
1608.speech-u6	4096	637e2b13	8a470f9a8a722f7ced340c4d32b4cf6f05b3e848	speech:data	0	good	no
1609.speech-u5	4096	675ee8e5	e314482028b8925ad02e833a1d22224533d0a683	speech:data	1000	good	no
1610.speech-u4	4096	2915c7bd	3ed98747b5237aa1b3bab6866292370dc2c7655a	speech:data	2000	good	no
s-c.xyt-u39	1024	56484d19	61f43126fdcfc230638ed47085ae037a098e6781	proms	0	good	no
pr-82.cpu-u15	32	c609b79e	49dbcbb607079a182d7eb396c0da097166ea91c9	proms	400	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3867120
cpu	speech:cpu	Intel 8035	3120000
audio	speaker	Speaker
audio	g80sound	Zektor Sound Board
audio	g80sound:sound_nl	Netlist Sound Device
audio	g80sound:psg	AY-3-8912A PSG	1933560
audio	speech	Sega Speech Sound Board
audio	speech:sp0250	GI SP0250 LPC	3120000

device_ref

name
z80
screen
vector_device
speaker
zektor_audio
netlist_sound
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_logic_in
nl_stream_in
nl_stream_in
nl_stream_in
nl_stream_out
ay8912
sega_speech_device
i8035
sp0250

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
dial		2		no	0	255	100	3

port, analog

port_tag	analog_masks
:D1D0
:D3D2
:D5D4
:D7D6
:FC
:SERVICESW
:SPINNER	255

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	D1D0	15

location

name	number	inverted
SW2	8	no
SW2	7	no
SW2	6	no
SW2	5	no

value

name	value	default
4 Coins/1 Credit	0	no
3 Coins/1 Credit	1	no
2 Coins/1 Credit 5/3 6/4	9	no
2 Coins/1 Credit 4/3	10	no
2 Coins/1 Credit	2	no
1 Coin/1 Credit	3	yes
1 Coin/1 Credit 5/6	11	no
1 Coin/1 Credit 4/5	12	no
1 Coin/1 Credit 2/3	13	no
1 Coin/2 Credits	4	no
1 Coin/2 Credits 4/9	15	no
1 Coin/2 Credits 5/11	14	no
1 Coin/3 Credits	5	no
1 Coin/4 Credits	6	no
1 Coin/5 Credits	7	no
1 Coin/6 Credits	8	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	D1D0	240

location

name	number	inverted
SW2	4	no
SW2	3	no
SW2	2	no
SW2	1	no

value

name	value	default
4 Coins/1 Credit	0	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit 5/3 6/4	144	no
2 Coins/1 Credit 4/3	160	no
2 Coins/1 Credit	32	no
1 Coin/1 Credit	48	yes
1 Coin/1 Credit 5/6	176	no
1 Coin/1 Credit 4/5	192	no
1 Coin/1 Credit 2/3	208	no
1 Coin/2 Credits	64	no
1 Coin/2 Credits 4/9	240	no
1 Coin/2 Credits 5/11	224	no
1 Coin/3 Credits	80	no
1 Coin/4 Credits	96	no
1 Coin/5 Credits	112	no
1 Coin/6 Credits	128	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	D3D2	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	1	yes
Cocktail	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	D3D2	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	D3D2	12

location

name	number	inverted
SW1	6	no
SW1	5	no

value

name	value	default
2	0	no
3	4	no
4	8	no
5	12	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	D3D2	48

location

name	number	inverted
SW1	4	no
SW1	3	no

value

name	value	default
Easy	0	yes
Medium	16	no
Hard	32	no
Hardest	48	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	D3D2	192

location

name	number	inverted
SW1	2	no
SW1	1	no

value

name	value	default
None	0	no
10000	192	no
20000	128	yes
30000	64	no
