Air Duel (World, M82 hardware) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
airduel	irem/m72.cpp		no	no	no	yes	Air Duel (World, M82 hardware)	1990	Irem

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	384	256	55.017606	8000000	512	64	448	284	0	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
ad_=m82=_a-h0-d.ic52	131072	dbecc726	526e9fdf0ca3af3eae462524df71af8e6bfa85d0	maincpu	1	good	no
ad_=m82=_a-l0-d.ic60	131072	6a9fcf59	a2ae64d290137036c350f84c38054cf6681473a5	maincpu	0	good	no
ad_=m82=_a-h1-d.ic51	131072	bafc152a	e20fa8b832ebfb7a4407fc162f28388858686d61	maincpu	40001	good	no
ad_=m82=_a-l1-d.ic59	131072	9e2b1ae7	838ccffb760b464d7d7e108e033a09e6295e5fc8	maincpu	40000	good	no
ad_=m82=_a-sp-d.ic15	65536	16a858a3	51dbac5b37ecb30b46072f5a300a29dc7f7b8542	soundcpu	0	good	no
ad_=m82=_b-n0-d.ic44	131072	2f0d599b	a966f806b5e25bb98cc63c46c49e0e676a62afcf	sprites	0	good	no
ad_=m82=_b-n1-d.ic45	131072	9865856b	b18a06899ae29d45e2351594df544220f3f4485a	sprites	20000	good	no
ad_=m82=_b-n2-d.ic46	131072	d392aef2	0f639a07066cadddc3884eb490885a8745571567	sprites	40000	good	no
ad_=m82=_b-n3-d.ic36	131072	923240c3	f587a83329087a715a3e42110f74f104e8c8ef1f	sprites	60000	good	no
ad_=m82=_a-c0-d.ic49	131072	ce134b47	841358cc222c81b8a91edc262f355310d50b4dbb	tiles0	0	good	no
ad_=m82=_a-c1-d.ic48	131072	097fd853	8e08f4f4a747c899bb8e21b347635e26af9edc2d	tiles0	20000	good	no
ad_=m82=_a-c2-d.ic57	131072	6a94c1b9	55174acbac54236e5fc1b80d120cd6da9fe5524c	tiles0	40000	good	no
ad_=m82=_a-c3-d.ic56	131072	6637c349	27cb7c89ab73292b43f8ae3c0d803a01ef3d3936	tiles0	60000	good	no
mt_f0.ic38	131072	2d5e05d5	18bdc9c561dbf0f91642161ca985d2154bd58b5d	sprites2	0	good	no
mt_f1.ic39	131072	c68cd65f	8999b558b4af0f453ada9e4ef705163df96844e6	sprites2	20000	good	no
mt_f2.ic40	131072	a71feb2d	47e366b422772bed08ee4d1c338970687d6c3b4c	sprites2	40000	good	no
mt_f3.ic41	131072	179f7562	6d28b199daffc62e8fa9009878ac0bb976ccbb2a	sprites2	60000	good	no
ad_=m82=_a-vo-d.ic12	131072	339f474d	a81bb52598a0e31b2ed6a538755237c5d14d1844	samples	0	good	no
mt_a-2h-.ic5	279	21ede612	5d05d3088f3d248db8948da175551ea29d7478b5	plds	0	good	no
mt_a-5l-.ic31	279	e3064bfe	c25b0d734be332042f86661d8743008c2a9d3a4e	plds	200	good	no
mt_a-7d-.ic43	279	d7ec1cc6	94afb0098206777d68de5e6122114fdc76618931	plds	400	good	no

chip

type	tag	name	clock
cpu	maincpu	NEC V30	8000000
cpu	soundcpu	Zilog Z80	3579545
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	3579545
audio	dac	8-Bit R-2R DAC

device_ref

name
v30
z80
pic8259
buffered_spriteram16
gfxdecode
palette
screen
speaker
generic_latch_8
rst_neg_buffer
m72_audio
ym2151
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2	4	8	no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1

dipswitch

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	3

location

name	number	inverted
SW1	1	no
SW1	2	no

value

name	value	default
2	2	no
3	3	yes
4	1	no
5	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
Very Easy	0	no
Easy	8	no
Normal	12	yes
Hard	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	256

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	512

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	1024

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Coin Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode	DSW	2048

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mode 1	2048	yes
Mode 2	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	12288	DSW	2048	eq	0

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default
5 Coins/1 Credit	0	no
3 Coins/1 Credit	4096	no
2 Coins/1 Credit	8192	no
1 Coin/1 Credit	12288	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	49152	DSW	2048	eq	0

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default
1 Coin/2 Credits	49152	yes
1 Coin/3 Credits	32768	no
1 Coin/5 Credits	16384	no
1 Coin/6 Credits	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	61440	DSW	2048	ne	0

location

name	number	inverted
SW2	5	no
SW2	6	no
SW2	7	no
SW2	8	no

value

name	value	default
6 Coins/1 Credit	40960	no
5 Coins/1 Credit	45056	no
4 Coins/1 Credit	49152	no
3 Coins/1 Credit	53248	no
2 Coins/1 Credit	57344	no
3 Coins/2 Credits	12288	no
4 Coins/3 Credits	8192	no
1 Coin/1 Credit	61440	yes
2 Coins/3 Credits	16384	no
1 Coin/2 Credits	36864	no
1 Coin/3 Credits	32768	no
1 Coin/4 Credits	28672	no
1 Coin/5 Credits	24576	no
1 Coin/6 Credits	20480	no
Free Play	0	no
