Animal House (set 3) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
animalhsb	igs/goldstar.cpp		no	no	no	yes	Animal House (set 3)	1994	bootleg	scmaster	scmaster

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	240	60.000000	7864320	512	0	512	256	8	248	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
2_27c256.u10n	32768	2ab7d75d	53cebed677e1b7f57e07cea53357d5a9516ea22a	maincpu	0	good	no
1_27c010a.u65	131072	98bd34b6	e3ff6536eb421ed2e2f5d4354099078ba4ae5671	gfx1	0	good	no	27c010.u29
3_am27c020.u66	262144	6e81b70d	3e3c63ae7200f8f98cbaf999be4ae9d854b90a8e	gfx2	0	good	no
galce16v8a.u18	279	12998a17	080b04d5d756428a870c67aad57f4dace5447320	plds	0	good	no
palce16v8h.u8	279	c8f1c706	d91ab228a6effda76b7112b141c7afc1f7d141b2	plds	0	good	no
palce16v8h.u7	279	b9d6b3a0	0cf0f84f30a03ff3e0bb3f30bcb60cc519cac0f5	plds	0	good	no
palce16v8h.u44	279	fdbdb9de	5bb6c960c3adcc6fc03cc457783c00b61d9fcadf	plds	0	good	no
palce20v8h.u45	343	a187d5a1	344eb67fe9c3214b445c1118dcde36040920edd2	plds	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3000000
audio	mono	Speaker
audio	aysnd	AY-3-8910A PSG	1500000

device_ref

name
z80
nvram
screen
gfxdecode
palette
speaker
ay8910
ticket_dispenser

sound

channels
1

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
gambling		9		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:DSW4
:IN0
:IN1

dipswitch

Game Level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Level	DSW1	3

location

name	number	inverted
DSW1	1	no
DSW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	3	yes
Mid 1	2	no
Mid 2	1	no
Hard	0	no

Punti

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Punti	DSW1	4

location

name	number	inverted
DSW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Ticket	4	yes
Gettoni	0	no

Ticket Dispenser

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Ticket Dispenser	DSW1	8

location

name	number	inverted
DSW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Reel Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reel Speed	DSW1	16

location

name	number	inverted
DSW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Low	16	yes
High	0	no

Super Jackpot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Super Jackpot	DSW1	96

location

name	number	inverted
DSW1	6	no
DSW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	96	yes
5%	32	no
10%	0	no
20%	64	no

Bet Step On 8

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bet Step On 8	DSW1	128

location

name	number	inverted
DSW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	128	yes
Yes	0	no

Main/Bonus Game Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Main/Bonus Game Rate	DSW2	15

location

name	number	inverted
DSW2	1	no
DSW2	2	no
DSW2	3	no
DSW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50% / 55%	0	no
53% / 58%	1	no
56% / 61%	2	no
59% / 64%	3	no
62% / 67%	4	no
65% / 70%	5	no
68% / 73%	6	no
71% / 76%	7	no
74% / 79%	8	no
77% / 82%	9	no
80% / 85%	10	no
83% / 88%	15	yes

Max Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Max Bet	DSW2	48

location

name	number	inverted
DSW2	5	no
DSW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
8	0	no
16	16	no
32	32	no
64	48	yes

Min. Bet For Bonus Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Min. Bet For Bonus Play	DSW2	64

location

name	number	inverted
DSW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
8	0	no
16	64	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	128

location

name	number	inverted
DSW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Coin A Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A Rate	DSW3	7

location

name	number	inverted
DSW3	1	no
DSW3	2	no
DSW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	0	yes
1 Coin/2 Credits	1	no
1 Coin/4 Credits	2	no
1 Coin/5 Credits	3	no
1 Coin/8 Credits	4	no
1 Coin/10 Credits	5	no
1 Coin/20 Credits	6	no
1 Coin/50 Credits	7	no

Key In Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key In Rate	DSW3	24

location

name	number	inverted
DSW3	4	no
DSW3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5x Coin A	0	yes
10x Coin A	8	no
20x Coin A	16	no
50x Coin A	24	no

Coin C Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin C Rate	DSW3	32

location

name	number	inverted
DSW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/5 Credits	0	yes	DSW3	7	eq	0
1 Coin/10 Credits	32	no	DSW3	7	eq	0
1 Coin/10 Credits	0	yes	DSW3	7	eq	1
1 Coin/20 Credits	32	no	DSW3	7	eq	1
1 Coin/20 Credits	0	yes	DSW3	7	eq	2
1 Coin/40 Credits	32	no	DSW3	7	eq	2
1 Coin/25 Credits	0	yes	DSW3	7	eq	3
1 Coin/50 Credits	32	no	DSW3	7	eq	3
1 Coin/40 Credits	0	yes	DSW3	7	eq	4
1 Coin/80 Credits	32	no	DSW3	7	eq	4
1 Coin/50 Credits	0	yes	DSW3	7	eq	5
1 Coin/100 Credits	32	no	DSW3	7	eq	5
1 Coin/100 Credits	0	yes	DSW3	7	eq	6
1 Coin/200 Credits	32	no	DSW3	7	eq	6
1 Coin/250 Credits	0	yes	DSW3	7	eq	7
1 Coin/500 Credits	32	no	DSW3	7	eq	7

Coin B Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B Rate	DSW3	64

location

name	number	inverted
DSW3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1x Coin C	0	yes
2x Coin C	64	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	128

location

name	number	inverted
DSW3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	1

location

name	number	inverted
DSW4	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	2

location

name	number	inverted
DSW4	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	4

location

name	number	inverted
DSW4	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	8

location

name	number	inverted
DSW4	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	16

location

name	number	inverted
DSW4	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	32

location

name	number	inverted
DSW4	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW4	64

location

name	number	inverted
DSW4	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Cherry/Bell Bonus

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cherry/Bell Bonus	DSW4	128

location

name	number	inverted
DSW4	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
x6 / x3	128	yes
x9 / x5	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	IN1	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	IN1	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no
