Area 51 (R3000) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
area51	atari/jaguar.cpp		no	no	no	yes	Area 51 (R3000)	1996	Atari Games

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	360	240	59.922743	7159090	456	42	402	262	17	257	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
2-c_area_51_hh.hh	524288	13af6a1e	69da54ed6886e825156bbcc256e8d7abd4dc1ff8	maincpu	0	good	no
2-c_area_51_hl.hl	524288	8ab6649b	9b4945bc04f8a73161638a2c5fa2fd84c6fd31b4	maincpu	1	good	no
2-c_area_51_lh.lh	524288	a6524f73	ae377a6803a4f7d1bbcc111725af121a3e82317d	maincpu	2	good	no
2-c_area_51_ll.ll	524288	471b15d2	4b5f45ee140b03a6be61475cae1c2dbef0f07457	maincpu	3	good	no
jagwave.rom	4096	7a25ee5b	58117e11fd6478c521fbd3fdbe157f39567552f0	waverom	0	good	no

disk

name	merge	sha1	region	index	writable	status	optional
area51		3b303bc37e206a6d7339352c869f050d04186f11	ide:0:hdd	0	yes	good	no

chip

type	tag	name	clock
cpu	maincpu	IDT R3041	40000000
cpu	gpu	Motorola Atari Jaguar GPU "Tom"	26000000
cpu	dsp	Motorola Atari Jaguar DSP "Jerry"	26000000
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	ldac	16-Bit R-2R Twos Complement DAC
audio	rdac	16-Bit R-2R Twos Complement DAC

device_ref

name
r3041
jaguargpu
jaguardsp
jag_blitter
nvram
watchdog
vt83c461
ata_slot
idehd
harddisk_image
ata_slot
screen
palette
speaker
speaker
dac_16bit_r2r_tc
dac_16bit_r2r_tc

sound

channels
2

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	ide:0:hdd:image	ide_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	ide:0:hdd:image	ide_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
2	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
lightgun	1	1		no	0	255	70	10
lightgun	2	1		no	0	255	70	10

port, analog

port_tag	analog_masks
:FAKE1_X	255
:FAKE1_Y	255
:FAKE2_X	255
:FAKE2_Y	255
:IN3
:P1_P2
:SYSTEM

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	SYSTEM	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no
