Area 51 (Atari Games license, Oct 25, 1995) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
area51a	atari/jaguar.cpp		no	no	no	yes	Area 51 (Atari Games license, Oct 25, 1995)	1995	Atari Games	area51	area51

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	360	240	59.922743	7159090	456	42	402	262	17	257	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
136105-0003a.3h	524288	116d37e6	5d36cae792dd349faa77cd2d8018722a28ee55c1	maincpu	0	good	no
136105-0002a.3p	524288	eb10f539	dadc4be5a442dd4bd17385033056555e528ed994	maincpu	1	good	no
136105-0001a.3m	524288	c6d8322b	90cf848a4195c51b505653cc2c74a3b9e3c851b8	maincpu	2	good	no
136105-0000a.3k	524288	729eb1b7	21864b4281b1ad17b2903e3aa294e4be74161e80	maincpu	3	good	no
jagwave.rom	4096	7a25ee5b	58117e11fd6478c521fbd3fdbe157f39567552f0	waverom	0	good	no	jagwave.rom

disk

name	merge	sha1	region	index	writable	status	optional
area51	area51	3b303bc37e206a6d7339352c869f050d04186f11	ide:0:hdd	0	yes	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68EC020	25000000
cpu	gpu	Motorola Atari Jaguar GPU "Tom"	26000000
cpu	dsp	Motorola Atari Jaguar DSP "Jerry"	26000000
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	ldac	16-Bit R-2R Twos Complement DAC
audio	rdac	16-Bit R-2R Twos Complement DAC

device_ref

name
m68ec020
jaguargpu
jaguardsp
jag_blitter
nvram
watchdog
vt83c461
ata_slot
idehd
harddisk_image
ata_slot
screen
palette
speaker
speaker
dac_16bit_r2r_tc
dac_16bit_r2r_tc

sound

channels
2

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	ide:0:hdd:image	ide_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	ide:0:hdd:image	ide_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
2	4	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
lightgun	1	1		no	0	255	70	10
lightgun	2	1		no	0	255	70	10

port, analog

port_tag	analog_masks
:FAKE1_X	255
:FAKE1_Y	255
:FAKE2_X	255
:FAKE2_Y	255
:IN3
:P1_P2
:SYSTEM

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	SYSTEM	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no
