BINBUG 3.6 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
binbug	ausnz/binbug.cpp		no	no	no	yes	BINBUG 3.6	1980	MicroByte	pipbug	pipbug

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
s100:1:dg640:screen	raster	0	512	256	50.080128	12000000	768	0	512	312	0	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
binbug.rom	1024	2cb1ac6e	a969883fc767484d6b0fa103cfa4b4129b90441b	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Signetics 2650	1000000
audio	mono	Speaker
audio	cassette	Cassette

device_ref

name
speaker
cassette_image
timer
clock
s2650
rs232
serial_keyboard
quickload
s100_bus
s100_slot
dg640
screen
gfxdecode
palette

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
cassette	cassette				cassette	cass
quickload	quickload				quickload	quik

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
cassette	cassette				wav, flac
quickload	quickload				pgm

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:keyboard:keyboard:GENKBD_CFG
:keyboard:keyboard:GENKBD_MOD
:keyboard:keyboard:GENKBD_ROW0
:keyboard:keyboard:GENKBD_ROW1
:keyboard:keyboard:GENKBD_ROW2
:keyboard:keyboard:GENKBD_ROW3
:keyboard:keyboard:RS232_DATABITS
:keyboard:keyboard:RS232_PARITY
:keyboard:keyboard:RS232_STOPBITS
:keyboard:keyboard:RS232_TXBAUD
:s100:1:dg640:DSW

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
keyboard	terminal	serial_terminal	no
keyboard	sunkbd	sunkbd_adaptor	no
keyboard	dec_loopback	dec_rs232_loopback	no
keyboard	ie15	ie15_terminal	no
keyboard	null_modem	null_modem	no
keyboard	keyboard	serial_keyboard	yes
keyboard	patch	rs232_patch_box	no
keyboard	swtpc8212	swtpc8212_terminal	no
keyboard	printer	serial_printer	no
keyboard	scorpion	scorpion_ic	no
keyboard	loopback	rs232_loopback	no
keyboard	mockingboard	mockingboardd	no
keyboard	msystems_mouse	rs232_mouse_hle_msystems	no
keyboard	nss_tvi	nss_tvinterface	no
keyboard	rs232_sync_io	rs232_sync_io	no
keyboard	pty	pseudo_terminal	no
keyboard	votraxtnt	serial_votraxtnt	no
keyboard	rs_printer	rs_serial_printer	no
s100:1	dg640	dg640	yes

configuration

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	keyboard:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	keyboard:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	keyboard:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	keyboard:keyboard:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	keyboard:keyboard:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	keyboard:keyboard:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	keyboard:keyboard:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	yes
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	no
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

dipswitch

Base Address

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Base Address	s100:1:dg640:DSW	31

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no
SW1	5	no

value

name	value	default
0000	0	no
0800	1	no
1000	2	no
1800	3	no
2000	4	no
2800	5	no
3000	6	no
3800	7	no
4000	8	no
4800	9	no
5000	10	no
5800	11	no
6000	12	no
6800	13	no
7000	14	no
7800	15	yes
8000	16	no
8800	17	no
9000	18	no
9800	19	no
A000	20	no
A800	21	no
B000	22	no
B800	23	no
C000	24	no
C800	25	no
D000	26	no
D800	27	no
E000	28	no
E800	29	no
F000	30	no
F800	31	no
