Chess-Master (model G-5003-501) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
chessmst	ddr/chessmst.cpp		no	no	no	yes	Chess-Master (model G-5003-501)	1984	VEB Mikroelektronik "Karl Marx" Erfurt

snap

Chess-Master (model G-5003-501) png snap

Chess-Master (model G-5003-501) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
chessmst	59987	29/12/2025 11:31:18	725	500	96	96	0	Format24bppRgb	305:MAME 0.212 (Jul 31 2019)	e709e11e920bcbc13bac583376cab3588dc66dee

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
bm001.d204	8192	6be28876	fd7d77b471e7792aef3b2b3f7ff1de4cdafc94c9	maincpu	0	good	no
bm108.d205	2048	2599794f	8d612d6159b29f9fc6a58d8f1e5a86d0e7c2ce75	maincpu	2000	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

tag	name
:maincpu	z80
:z80pio0	z80pio
:z80pio1	z80pio
:board	sensorboard
:led_pwm	pwm_display
:speaker	speaker
:dac	dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		10		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.11
:board:RANK.12
:board:RANK.13
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

clones

name	description
chessmsta	Chess-Master (model G-5003-500)
