Cleopatra - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cleoptra	pinball/gts1.cpp	genpin	no	no	yes	yes	Cleopatra	1977	Gottlieb		gts1

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
a1752cf.u5	2048	614a3bd9	febca18fb6f96037ca82e515dd161dfcb0e4c776	maincpu	0	good	no	a1752cf.u5
a1753ce.u4	2048	4cd312dd	31245daa9972ef8652caee69986585bb8239e86e	maincpu	800	good	no	a1753ce.u4
409.cpu	1024	8063ff71	205f09f067bf79544d2ce2a48d23259901f935dd	module	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Rockwell PPS-4/2	3579545
audio	mechvol	Speaker
audio	samples	Samples

device_ref

name
pps4_2
nvram
ra17xx
ra17xx
r10696
r10696
r10788
speaker
samples

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
1

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		40		no

port, analog

port_tag	analog_masks
:DSW0
:DSW1
:DSW2
:X0
:X1
:X2
:X3
:X4
:X5
:X6

dipswitch

Coinage Left Slot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Left Slot	DSW0	15

location

name	number	inverted
SWM1	1	no
SWM1	2	no
SWM1	3	no
SWM1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	15	yes
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
1 Coin/7 Credits	9	no
1 Coin/8 Credits	8	no
1 Coin/9 Credits	7	no
2 Coins/1 Credit	6	no
2 Coins/2 Credits	5	no
2 Coins/3 Credits	4	no
2 Coins/4 Credits	3	no
2 Coins/5 Credits	2	no
1 coin 1 credit, 2 coins 3 credits	1	no
3 Coins/1 Credit	0	no

Coinage Right Slot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Right Slot	DSW0	240

location

name	number	inverted
SWM1	5	no
SWM1	6	no
SWM1	7	no
SWM1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	240	yes
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
1 Coin/7 Credits	144	no
1 Coin/8 Credits	128	no
1 Coin/9 Credits	112	no
2 Coins/1 Credit	96	no
2 Coins/2 Credits	80	no
2 Coins/3 Credits	64	no
2 Coins/4 Credits	48	no
2 Coins/5 Credits	32	no
1 coin 1 credit, 2 coins 3 credits	16	no
3 Coins/1 Credit	0	no

Balls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Balls	DSW1	1

location

name	number	inverted
SWM2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	0	yes
5	1	no

Match

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Match	DSW1	2

location

name	number	inverted
SWM2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	2	no

Preset score award

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Preset score award	DSW1	4

location

name	number	inverted
SWM2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Replay	0	yes
Extra Ball	4	no

Tilt Penalty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Tilt Penalty	DSW1	8

location

name	number	inverted
SWM2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Ball	0	yes
Game	8	no

Credits display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits display	DSW1	16

location

name	number	inverted
SWM2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	16	no

Game start sound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game start sound	DSW1	32

location

name	number	inverted
SWM2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	32	no

S15

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S15	DSW1	64

location

name	number	inverted
SWM2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	64	yes

S16

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S16	DSW1	128

location

name	number	inverted
SWM2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	128	yes

Max credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Max credits	DSW2	3

location

name	number	inverted
SWM3	1	no
SWM3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	3	no
8	2	no
10	1	no
15	0	yes

S1-4 control both slots

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S1-4 control both slots	DSW2	4

location

name	number	inverted
SWM3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	4	yes

Ingame sound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Ingame sound	DSW2	8

location

name	number	inverted
SWM3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	8	no

High game display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
High game display	DSW2	16

location

name	number	inverted
SWM3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	16	no

High game awards 3 credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
High game awards 3 credits	DSW2	32

location

name	number	inverted
SWM3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	32	no

Coin sound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin sound	DSW2	64

location

name	number	inverted
SWM3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	64	no

S24

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
S24	DSW2	128

location

name	number	inverted
SWM3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	128	yes
