Dragon 200-E - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
dragon200e	trs/dragon.cpp		no	no	no	yes	Dragon 200-E	1985	Eurohard S.A.	dragon32	dragon32

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	372	293	49.967668	7109000	456	0	372	312	0	293	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
ic18_v1.4e.ic34	16384	95af0a0a	628543ee8b47a56df2b2175cfb763c0051517b90	maincpu	0	good	no
ic17_v1.4e.ic37	16384	48b985df	c25632f3c2cfd1af3ee26b2f233a1ce1eccc365d	maincpu	8000	good	no
rom26.ic1	4096	565724bc	da5b756ba2a9c9ecebaa7daa8ba8bfd984d56a6f	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	888625
audio	cassette	Cassette
audio	speaker	Speaker
audio	dac	6-Bit Binary Weighted DAC
audio	sbs	1-Bit DAC
audio	ext:dragon_fdc:wd2797:0:qd:flopsndout	Speaker
audio	ext:dragon_fdc:wd2797:0:qd:floppysound	Floppy sound	44100
audio	ext:dragon_fdc:wd2797:1:qd:flopsndout	Speaker
audio	ext:dragon_fdc:wd2797:1:qd:floppysound	Floppy sound	44100

softwarelist

tag	name	status
dragon_cart_list	dragon_cart	original
dragon_cass_list	dragon_cass	original
dragon_flop_list	dragon_flop	original
coco_cart_list	coco_cart	compatible
dragon_flex_list	dragon_flex	original
dragon_os9_list	dragon_os9	original

device_ref

name
mc6809e
ipt_merge_any_hi
ipt_merge_any_hi
pia6821
pia6821
sam6883
cassette_image
printer_image
screen
mc6847_pal
speaker
dac_6bit_bw
dac
address_map_bank
software_list
software_list
software_list
software_list
ram
cococart_slot
dragon_fdc
wd2797
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_connector
mos6551
clock
rs232
software_list
software_list

sound

channels
3

ramoption

name	default
64K	yes

device, instance

type	tag	interface	name	briefname
cassette	cassette	dragon_cass	cassette	cass
printout	printer		printout	prin
cartridge	ext	coco_cart	cartridge	cart
floppydisk	ext:dragon_fdc:wd2797:0:qd	floppy_5_25	floppydisk1	flop1
floppydisk	ext:dragon_fdc:wd2797:1:qd	floppy_5_25	floppydisk2	flop2

device, extension

type	tag	interface	extension_names
cassette	cassette	dragon_cass	wav, flac, cas
printout	printer		prn
cartridge	ext	coco_cart	ccc, rom
floppydisk	ext:dragon_fdc:wd2797:0:qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, dmk, sdf, jvc, vdk, os9
floppydisk	ext:dragon_fdc:wd2797:1:qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, dmk, sdf, jvc, vdk, os9

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	reverse	minimum	maximum	sensitivity	keydelta
stick	1	1	no	0	1023	100	10
keyboard	1	52	no
stick	2	1	no	0	1023	100	10

port, analog

port_tag	analog_masks
:LK1
:ctrl_sel
:hires_intf
:joystick_buttons
:joystick_lx	1023
:joystick_ly	1023
:joystick_rx	1023
:joystick_ry	1023
:row0
:row1
:row2
:row3
:row4
:row5
:row6
:vdg:artifacting

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
ext	premier_fdc	premier_fdc	no
ext	sym12	coco_symphony_twelve	no
ext	dragon_fdc	dragon_fdc	yes
ext	ssfm	dragon_msx2	no
ext	ccpsg	coco_psg	no
ext	jcbsnd	dragon_jcbsnd	no
ext	orch90	coco_orch90	no
ext	serial	dragon_serial	no
ext	gmc	cocopakgmc	no
ext	multi	dragon_multipack	no
ext	stecomp	coco_stereo_composer	no
ext	jcbspch	dragon_jcbspch	no
ext	sdtandy_fdc	sdtandy_fdc	no
ext	wpk2p	coco_wpk2p	no
ext	claw	dragon_claw	no
ext	max	cocopakmax	no
ext	midi	dragon_midi	no
ext	pak	cocopak	no
ext	ssc	coco_ssc	no
ext	ram	cocopakram	no
ext	sprites	dragon_sprites	no
ext:dragon_fdc:wd2797:0	qd	floppy_525_qd	yes
ext:dragon_fdc:wd2797:1	qd	floppy_525_qd	yes
ext:dragon_fdc:wd2797:2	qd	floppy_525_qd	no
ext:dragon_fdc:wd2797:3	qd	floppy_525_qd	no
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no

configuration

Inverse Video

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Inverse Video	LK1	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Inverse	0	no
Normal	1	yes

Right Controller Port (P1)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Right Controller Port (P1)	ctrl_sel	15

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Unconnected	0	no
Joystick	1	yes
The Rat Graphics Mouse	2	no	ctrl_sel	240	ne	32
Diecom Light Gun Adaptor	3	no	ctrl_sel	240	ne	48

Left Controller Port (P2)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Left Controller Port (P2)	ctrl_sel	240

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Unconnected	0	no
Joystick	16	yes
The Rat Graphics Mouse	32	no	ctrl_sel	15	ne	2
Diecom Light Gun Adaptor	48	no	ctrl_sel	15	ne	3

Hi-Res Joystick Interfaces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hi-Res Joystick Interfaces	hires_intf	7

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	0	yes
Hi-Res in Right Port	1	no	ctrl_sel	15	eq	1
Hi-Res CoCoMax 3 Style in Right Port	2	no	ctrl_sel	15	eq	1
Hi-Res in Left Port	3	no	ctrl_sel	240	eq	16
Hi-Res CoCoMax 3 Style in Left Port	4	no	ctrl_sel	240	eq	16

Artifacting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Artifacting	vdg:artifacting	3

setting

name	value	default
Off	0	no
Standard	1	yes
Reverse	2	no
