ESQ-1 Digital Wave Synthesizer - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
esq1	ensoniq/esq1.cpp		no	no	no	yes	ESQ-1 Digital Wave Synthesizer	1986	Ensoniq

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
3p5lo.bin	32768	ed001ad8	14d1150bccdbc15d90567cf1812aacdb3b6ee882	osrom	0	good	no		v3.5
3p5hi.bin	32768	332c572f	ddb4f62807eb2ab29e5ac6b5d209d2ecc74cf806	osrom	8000	good	no		v3.5
2p2lo.bin	32768	ea11eca4	6a1f026f1371514664ac5d7ea87729c3038ac735	osrom	0	good	no		v2.2
2p2hi.bin	32768	78ed71a5	9a6c715fbba0f2d1afce2171f791affb4887a0bc	osrom	8000	good	no		v2.2
2p0lo.bin	32768	3b701b08	62f92e50ca6a68cfa87613d637e8c73938e62fd6	osrom	0	good	no		v2.0
2p0hi.bin	32768	10b0f436	f6ae76d4d42056c00577e131ee85527386f04649	osrom	8000	good	no		v2.0
1p7lo.bin	32768	cc67d98a	fda181aec18621499171d7090454c6d60625ec85	osrom	0	good	no		v1.7
1p7hi.bin	32768	59b2f8d1	eb82936f01f379c23df6523cddbac4c7c21b2d22	osrom	8000	good	no		v1.7
esq1wavlo.bin	32768	4d04ac87	867b51229b0a82c886bf3b216aa8893748236d8b	es5503	0	good	no
esq1wavhi.bin	32768	94c554a3	ed0318e5253637585559e8cf24c06d6115bd18f6	es5503	8000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	filters	ESQ1 Filters stage
audio	es5503	Ensoniq ES5503	8000000

device_ref

name
mc6809e
ipt_merge_any_hi
scn2681
duart_channel
duart_channel
esqpanel240
esq2x40
midi_port
midiin_port
midiin
midi_port
midiout_port
midiout
speaker
esq1_filters
es5503

biosset

name	description	default
v3.5	Version 3.5	yes
v2.2	Version 2.2	no
v2.0	Version 2.0	no
v1.7	Version 1.7	no

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdout:midiout:midioutimg				midiout	mout

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		22		no

port, analog

port_tag	analog_masks
:KEY0
:KEY1
:mdin:midiin:midiinimg:CFG

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
