ESQ-M Digital Wave Synthesizer Module - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
esqm	ensoniq/esq1.cpp		no	no	no	yes	ESQ-M Digital Wave Synthesizer Module	1986	Ensoniq	esq1	esq1

snap

ESQ-M Digital Wave Synthesizer Module png snap

ESQ-M Digital Wave Synthesizer Module jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
esqm	16039	12/03/2026 20:38:07	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	0e5d5df1fcc9fa76729a65ee13e773933afd2cd2

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1355500157_d640_esq-m_oshi.u14	32768	ea6a7bae	2830f8c52dc443b4ca469dc190b33e2ff15b78e1	osrom	8000	good	no
esq1wavlo.bin	32768	4d04ac87	867b51229b0a82c886bf3b216aa8893748236d8b	es5503	0	good	no	esq1wavlo.bin
esq1wavhi.bin	32768	94c554a3	ed0318e5253637585559e8cf24c06d6115bd18f6	es5503	8000	good	no	esq1wavhi.bin

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	filters	ESQ1 Filters stage
audio	es5503	Ensoniq ES5503	8000000

device_ref

tag	name
:maincpu	mc6809e
:mainirq	ipt_merge_any_hi
:duart	scn2681
:duart:cha	duart_channel
:duart:chb	duart_channel
:panel	esqpanel240
:panel:vfd	esq2x40
:mdin	midi_port
:mdin:midiin	midiin_port
:mdin:midiin:midiinimg	midiin
:mdout	midi_port
:mdout:midiout	midiout_port
:mdout:midiout:midioutimg	midiout
:speaker	speaker
:filters	esq1_filters
:es5503	es5503

adjuster

name	default
Data Entry	100
Mod Wheel	0
Pitch Wheel	50
Volume	100

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdout:midiout:midioutimg				midiout	mout

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		112		no

port, analog

port_tag	analog_masks
:COL0
:COL1
:COL2
:COL3
:COL4
:COL5
:COL6
:INTERNAL_KBD1
:INTERNAL_KBD2
:INTERNAL_KBD3
:INTERNAL_KBD4
:INTERNAL_KBD5
:INTERNAL_KBD6
:data_entry_slider
:mdin:midiin:midiinimg:CFG
:mod_wheel
:pitch_wheel
:volume_slider

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
