FM-NEW7 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
fmnew7	fujitsu/fm7.cpp		no	no	no	yes	FM-NEW7	1984	Fujitsu	fm7	fm7

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	200	60.114504	16128000	1024	0	640	262	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
fbasic302.rom	31744	a96d19b6	8d5f0cfe7e0d39bf2ab7e4c798a13004769c28b2	fbasic	0	baddump	no
subsys_c.rom	10240	24cec93f	50b7283db6fe1342c6063fc94046283f4feddc1c	sub	d800	baddump	no	subsys_c.rom
boot_bas.rom	512	c70f0c74	53b63a301cba7e3030e79c59a4d4291eab6e64b0	boot	200	baddump	no	boot_bas.rom
boot_dos.rom	512	198614ff	037e5881bd3fed472a210ee894a6446965a8d2ef	boot	600	baddump	no
kanji.rom	131072	62402ac9	bf52d22b119d54410dad4949b0687bb0edf3e143	kanji1	0	good	yes	kanji.rom

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	8064000
cpu	sub	Motorola MC6809	8064000
audio	mono	Speaker
audio	psg	AY-3-8913 PSG	1228800
audio	beeper	Beep	1200
audio	cassette	Cassette
audio	fdc:0:qd:flopsndout	Speaker
audio	fdc:0:qd:floppysound	Floppy sound	44100
audio	fdc:1:qd:flopsndout	Speaker
audio	fdc:1:qd:floppysound	Floppy sound	44100

softwarelist

tag	name	status
fm7_cass_list	fm7_cass	original
fm8_cass_list	fm8_cass	compatible
flop_list	fm7_disk	original

device_ref

name
mc6809
mc6809
speaker
ay8913
beep
screen
palette
cassette_image
software_list
software_list
mb8877
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
software_list
centronics
centronics_printer
printer_image
output_latch

sound

channels
3

device, instance

type	tag	interface	name	briefname
cassette	cassette	fm7_cass	cassette	cass
floppydisk	fdc:0:qd	floppy_5_25	floppydisk1	flop1
floppydisk	fdc:1:qd	floppy_5_25	floppydisk2	flop2
printout	centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
cassette	cassette	fm7_cass	wav, flac, t77
floppydisk	fdc:0:qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
printout	centronics:printer:printer		prn

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse
joy	1	2	8	no
keyboard	1	98		no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSW
:joy1
:joy2
:key1
:key2
:key3
:key_modifiers

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	qd	floppy_525_qd	yes
fdc:1	qd	floppy_525_qd	yes
centronics	dsjoy	dempa_shinbunsha_joystick	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes

dipswitch

Switch A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch A	DSW	1

location

name	number	inverted
SWA	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

Boot mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot mode	DSW	2

location

name	number	inverted
SWA	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
DOS	0	no
BASIC	2	yes

Switch C

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch C	DSW	4

location

name	number	inverted
SWA	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

FM-8 Compatibility mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
FM-8 Compatibility mode	DSW	8

location

name	number	inverted
SWA	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no
