Tetris (v341R) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
igstet341	igs/igspoker.cpp		no	no	no	yes	Tetris (v341R)	199?	IGS	pktet346	pktet346

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	256	57.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
tetris_v-341r.u23	65536	3a9762e6	9307bfba4c715075edc4e3b892acf49d08b14266	maincpu	0	good	no
tetris_3.u6	131072	8159768d	b28026afa8206adbc381dfa461eea842354ea5b6	gfx1	0	good	no
tetris_2.u5	131072	7079e79e	bc44c446e8a7ee9cb75695ca1c1a27f78e4b3e30	gfx1	20000	good	no
tetris_1.u4	131072	6bf90dd5	280eb3a54cf5e4fbeeee25d87b10900bba360641	gfx1	40000	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3579545
audio	mono	Speaker
audio	ymsnd	YM2413 OPLL	3579545

device_ref

name
z80
timer
nvram
screen
gfxdecode
palette
speaker
i8255
ym2413

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy			2	no
gambling		10		no

port, analog

port_tag	analog_masks
:BUTTONS1
:BUTTONS2
:COINS
:DSW1
:DSW2
:DSW3
:DSW4
:DSW5
:SERVICE

dipswitch

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	1

location

name	number	inverted
SWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Display Card

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display Card	DSW1	2

location

name	number	inverted
SWA	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Poker	2	yes
Numbers	0	no

Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Speed	DSW1	4

location

name	number	inverted
SWA	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Slow	4	yes
Quick	0	no

Double Gate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Gate	DSW1	8

location

name	number	inverted
SWA	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	8	yes
Difficult	0	no

System Limit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
System Limit	DSW1	48

location

name	number	inverted
SWA	4	no
SWA	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10000	48	yes
15000	32	no
30000	16	no
70000	0	no

Coin Setting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Setting	DSW1	192

location

name	number	inverted
SWA	2	no
SWA	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	192	yes
2	128	no
5	64	no
10	0	no

Min Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Min Bet	DSW2	3

location

name	number	inverted
SWB	8	no
SWB	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	3	yes
2	2	no
5	1	no
10	0	no

Max Bet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Max Bet	DSW2	12

location

name	number	inverted
SWB	6	no
SWB	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
40	12	yes
50	8	no
80	4	no
100	0	no

Key In

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key In	DSW2	48

location

name	number	inverted
SWB	4	no
SWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10	48	yes
20	32	no
50	16	no
100	0	no

Demo Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Game	DSW2	64

location

name	number	inverted
SWB	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Amuse Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Amuse Game	DSW2	128

location

name	number	inverted
SWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Free	128	yes
1 Credit	0	no

Double Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Game	DSW3	1

location

name	number	inverted
SWC	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Royal Appear

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Royal Appear	DSW3	2

location

name	number	inverted
SWC	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

5 Kind Appear

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
5 Kind Appear	DSW3	4

location

name	number	inverted
SWC	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Key Out Base

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key Out Base	DSW3	8

location

name	number	inverted
SWC	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	8	yes
10	0	no

Open Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Open Mode	DSW3	16

location

name	number	inverted
SWC	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Demo	16	yes
Amuse	0	no

Quick Get

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Quick Get	DSW3	32

location

name	number	inverted
SWC	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Bet Base

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bet Base	DSW3	64

location

name	number	inverted
SWC	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	64	yes
10	0	no

Percentage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage	DSW3	128

location

name	number	inverted
SWC	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Amuse Coin

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Amuse Coin	DSW4	1

location

name	number	inverted
SWD	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1:1	1	yes
5:1	0	no
