name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ivg09	skeleton/tavernie.cpp		no	no	no	yes	CPU09 with IVG09 and IFD09	1983	C. Tavernier	cpu09	cpu09

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	250	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
tavbug.bin	4096	77945cae	d89b577bc0b4e15e9a49a849998681bdc6cf5fbe	roms	0	good	no	tavbug.bin
promon.bin	2048	43256bf2	e81acb5b659d50d7b019b97ad5d2a8f129da39f6	roms	1000	good	yes
boottav.bin	496	ae1a858d	ab2144a00afd5b75c6dcb15c2c3f9d6910a159ae	roms	1800	good	yes
big.bin	8192	f27f6bfe	d9509c6e1d10e042ad3cdfaec31114148dee9ff4	chargen	0	good	no
small.bin	4096	16e25eed	5d31f127fe635be4bca06840b15a1bd77f971492	chargen	1000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	4000000
audio	mono	Speaker
audio	cassette	Cassette
audio	beeper	Beep	950
audio	fdc:0:525dd:flopsndout	Speaker
audio	fdc:0:525dd:floppysound	Floppy sound	44100

device_ref

name
mc6809
speaker
cassette_image
timer
pia6821
ptm6840
acia6850
rs232
screen
gfxdecode
palette
beep
generic_keyboard
mc6845
pia6821
wd2795
floppy_connector
floppy_525_dd
speaker
flopsnd

sound

channels
2

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
cassette	cassette				cassette	cass
floppydisk	fdc:0:525dd	floppy_5_25			floppydisk	flop

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
cassette	cassette				wav, flac
floppydisk	fdc:0:525dd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:DSW
:keyboard:GENKBD_CFG
:keyboard:GENKBD_MOD
:keyboard:GENKBD_ROW0
:keyboard:GENKBD_ROW1
:keyboard:GENKBD_ROW2
:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no
fdc:0	525dd	floppy_525_dd	yes

configuration

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

dipswitch

IRQ PTM

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ PTM	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

IRQ ACIA

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ ACIA	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Terminal

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Terminal	DSW	96

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
110 baud	0	no
300 baud	32	no
1200 baud	64	no
IVG09 (mc6845)	96	yes
