Ace Of Clubs (Crystal) (IMPACT, GND D 4) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6aceclb	jpm/jpmimpctsw.cpp		no	no	yes	yes	Ace Of Clubs (Crystal) (IMPACT, GND D 4)	199?	Crystal

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
aocd1.bin	131072	932fe07a	4f4dbfa627364edf8408264e547d0f21d306c59e	maincpu	0	good	no
aocd2.bin	131072	d18d8b24	df09419c3702efb340da3e7327e1139c54351926	maincpu	1	good	no
aceofclubssnd.bin	524288	9ea8bce4	0849be87528168dbc5c07a31138edcb30a611c5c	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
mc68681
duart_channel
duart_channel
timer
nvram
i8255
timer
timer
timer
timer
timer
timer
speaker
upd7759
meters
bacta_datalogger
s16lf01
stepper
stepper
stepper
stepper
stepper
stepper

sound

channels
1

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		10		no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
