Ace Of Clubs (Crystal) (IMPACT, GND D 4 P, Protocol) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
j6aceclba	jpm/jpmimpctsw.cpp		no	no	yes	yes	Ace Of Clubs (Crystal) (IMPACT, GND D 4 P, Protocol)	199?	Crystal	j6aceclb	j6aceclb

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
aocdp1.b8	131072	78b1b442	b2fe66e3ac5b7a2eb4b0dbcc6237259aef61abfd	maincpu	0	good	no
aocd2.bin	131072	d18d8b24	df09419c3702efb340da3e7327e1139c54351926	maincpu	1	good	no	aocd2.bin
aceofclubssnd.bin	524288	9ea8bce4	0849be87528168dbc5c07a31138edcb30a611c5c	upd	0	good	no	aceofclubssnd.bin

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
mc68681
duart_channel
duart_channel
timer
nvram
i8255
timer
timer
timer
timer
timer
timer
speaker
upd7759
meters
bacta_datalogger
s16lf01
stepper
stepper
stepper
stepper
stepper
stepper

sound

channels
1

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		10		no

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO
