MikroMikko 1 M7 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
mm1m7	nokia/mikromik.cpp	MM1_keyboard	no	no	no	yes	MikroMikko 1 M7	1981	Nokia Data

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	800	375	50.000000	15000000	800	0	800	375	0	375	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional
9057c.ic2	8192	89bbc042	7e8800c94934b81ce08b7af862e1159e0517684d	ic40	good	no
726972b.ic24	512	2487d4ca	e883a2e9540c31abba3d7f3bc23a48941f655ea0	address	good	no
6807b.ic61	4096	32b36220	8fe7a181badea3f7e656dfaea21ee9e4c9baf0f1	chargen	good	no

chip

type	tag	name	clock
cpu	ic40	Intel 8085A	6144000
cpu	ic45	AM9517A	3072000
audio	ic15:0:525:flopsndout	Speaker
audio	ic15:0:525:floppysound	Floppy sound	44100
audio	kb:mono	Speaker
audio	kb:keyboard_and_chassis_sounds	Samples

softwarelist

tag	name	status	filter
flop_list	mm1_flop	original

device_ref

name
i8085a
address_map_bank
i8212
ls259
am9517a
pit8253
pit_counter
pit_counter
pit_counter
upd765a
floppy_connector
floppy_525_qd
speaker
flopsnd
upd7201
i8274_channel
i8274_channel
rs232
rs232
rs232
mm1kb
speaker
samples
ram
software_list
screen
gfxdecode
palette
i8275
nscsi_bus
nscsi_connector
scsi_s1410
harddisk_image
nscsi_connector
nscsi_cb

sample

name
beep
power_switch

sound

channels
2

ramoption

name	default
64K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	ic15:0:525	floppy_5_25			floppydisk	flop
harddisk	sasi:0:s1410:image	scsi_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	ic15:0:525	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
harddisk	sasi:0:s1410:image	scsi_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		83		no

port, analog

port_tag	analog_masks
:T5
:kb:SPECIAL
:kb:Y0
:kb:Y1
:kb:Y2
:kb:Y3
:kb:Y4
:kb:Y5
:kb:Y6
:kb:Y7
:kb:Y8
:kb:Y9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
ic15:0	525	floppy_525_qd	yes
rs232a	terminal	serial_terminal	no
rs232a	sunkbd	sunkbd_adaptor	no
rs232a	dec_loopback	dec_rs232_loopback	no
rs232a	ie15	ie15_terminal	no
rs232a	null_modem	null_modem	no
rs232a	keyboard	serial_keyboard	no
rs232a	patch	rs232_patch_box	no
rs232a	swtpc8212	swtpc8212_terminal	no
rs232a	printer	serial_printer	no
rs232a	scorpion	scorpion_ic	no
rs232a	loopback	rs232_loopback	no
rs232a	mockingboard	mockingboardd	no
rs232a	msystems_mouse	rs232_mouse_hle_msystems	no
rs232a	nss_tvi	nss_tvinterface	no
rs232a	rs232_sync_io	rs232_sync_io	no
rs232a	pty	pseudo_terminal	no
rs232a	rs_printer	rs_serial_printer	no
rs232b	terminal	serial_terminal	no
rs232b	sunkbd	sunkbd_adaptor	no
rs232b	dec_loopback	dec_rs232_loopback	no
rs232b	ie15	ie15_terminal	no
rs232b	null_modem	null_modem	no
rs232b	keyboard	serial_keyboard	no
rs232b	patch	rs232_patch_box	no
rs232b	swtpc8212	swtpc8212_terminal	no
rs232b	printer	serial_printer	no
rs232b	scorpion	scorpion_ic	no
rs232b	loopback	rs232_loopback	no
rs232b	mockingboard	mockingboardd	no
rs232b	msystems_mouse	rs232_mouse_hle_msystems	no
rs232b	nss_tvi	nss_tvinterface	no
rs232b	rs232_sync_io	rs232_sync_io	no
rs232b	pty	pseudo_terminal	no
rs232b	rs_printer	rs_serial_printer	no
rs232c	terminal	serial_terminal	no
rs232c	sunkbd	sunkbd_adaptor	no
rs232c	dec_loopback	dec_rs232_loopback	no
rs232c	ie15	ie15_terminal	no
rs232c	null_modem	null_modem	no
rs232c	keyboard	serial_keyboard	no
rs232c	patch	rs232_patch_box	no
rs232c	swtpc8212	swtpc8212_terminal	no
rs232c	printer	serial_printer	no
rs232c	scorpion	scorpion_ic	no
rs232c	loopback	rs232_loopback	no
rs232c	mockingboard	mockingboardd	no
rs232c	msystems_mouse	rs232_mouse_hle_msystems	no
rs232c	nss_tvi	nss_tvinterface	no
rs232c	rs232_sync_io	rs232_sync_io	no
rs232c	pty	pseudo_terminal	no
rs232c	rs_printer	rs_serial_printer	no
sasi:0	cfp1080s	cfp1080s	no
sasi:0	aplcdsc	scsi_cdrom_apple	no
sasi:0	aplcd150	aplcd150	no
sasi:0	tape	scsi_tape	no
sasi:0	s1410	scsi_s1410	yes
sasi:0	harddisk	scsi_harddisk	no
sasi:0	cw7501	cw7501	no
sasi:0	crd254sh	crd254sh	no
sasi:0	cdr4210	cdr4210	no
sasi:0	cdrn820s	cdrn820s	no
sasi:0	cdu75s	cdu75s	no
sasi:0	cdrom	scsi_cdrom	no
sasi:0	cdu415	cdu415	no
sasi:0	cdu561_25	cdu561_25	no
sasi:0	cdd2000	cdd2000	no
sasi:0	smoc501	smoc501	no

configuration

Floppy Drive Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Floppy Drive Type	T5	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
640 KB	0	yes
160/320 KB	1	no
