MU500 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mu500	yamaha/ymmu2000.cpp		no	no	no	yes	MU500	2000	Yamaha

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
lcd:screen	svg	0	1280	386	60.000000	29644800	1280	0	1280	386	0	386	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
xv364a0.ic49	8388608	cda1afd6	e7098246b33c3cf22ed8cc15ed6383f8a06d17e9	swp30	0	good	no
xv365a0.ic50	8388608	10985ed0	d45a2e85859e05046f3ede8317a9bb0b88898116	swp30	2	good	no
xw848a0.ic53	8388608	34913e42	9e8b55c2cbac3f69cc0b17aeaf02053145bfaeda	swp30	1000000	good	no
xw849a0.ic54	8388608	3728f1f2	7670d672e24d6388fa92799175f35869a140c451	swp30	1000002	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi SH-2 (SH7043A)	28000000
cpu	swp30m	Yamaha SWP30 sound chip	33868800
audio	speaker	Speaker
audio	swp30m	Yamaha SWP30 sound chip	33868800
audio	plg1	PLG1x0 extension connector
audio	plg2	PLG1x0 extension connector
audio	plg3	PLG1x0 extension connector

device_ref

name
sh7043a
sh_intc
sh_adc_ms
sh_adc_ms
sh_bsc
sh_cmt
sh_dmac
sh_dmac_channel
sh_dmac_channel
sh_dmac_channel
sh_dmac_channel
sh_mtu
sh_mtu_channel
sh_mtu_channel
sh_mtu_channel
sh_mtu_channel
sh_mtu_channel
sh_port32
sh_port16
sh_port16
sh_port32
sh_port16
sh_port16
sh_sci
sh_sci
ipt_merge_any_hi
sci4
nvram
mulcd
hd44780
screen
speaker
swp30
midi_port
midiin_port
midiin
midi_port
midiin_port
midiin
midi_port
midiout_port
midiout
plg1x0_connector
plg1x0_connector
plg1x0_connector

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin_a:midiin:midiinimg				midiin1	min1
midiin	mdin_b:midiin:midiinimg				midiin2	min2
midiout	mdout:midiout:midioutimg				midiout	mout

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin_a:midiin:midiinimg				mid, syx
midiin	mdin_b:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid

input

players	coins	service	tilt
1		no	no

port, analog

port_tag	analog_masks
:SWS0
:SWS1
:SWS2
:SWS3
:SWS4
:SWS5
:mdin_a:midiin:midiinimg:CFG
:mdin_b:midiin:midiinimg:CFG

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin_a	midiin	midiin_port	yes
mdin_b	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes
plg1	plg150ap	plg150_ap	no
plg1	plg100vl	plg100_vl	no
plg2	plg150ap	plg150_ap	no
plg2	plg100vl	plg100_vl	no
plg3	plg150ap	plg150_ap	no
plg3	plg100vl	plg100_vl	no

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin_a:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin_b:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
