NWS-3260 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
nws3260	sony/news_r3k.cpp		no	no	no	yes	NWS-3260	1991	Sony

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
lcd	lcd	0	1120	780	60.000000	52416000	1120	0	1120	780	0	780	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
mpu-16__ver.2.0a__1990_sony.ic64	131072	61222991	076fab0ad0682cd7dacc7094e42efe8558cbaaa1	eprom	0	good	no	nws3260
051_aa.ic109	524288	1411cbcb	793394cd3919034f85bfb015d6d3c504f83b6626	krom	0	good	no
052_aa.ic110	524288	df0f39da	076881da022a3fe6731de0ead217285293c25dc7	krom	4	good	no
idrom.bin	256	17a3d9c6	d300e6908210f540951211802c38ad7f8037aa15	idrom	0	baddump	no

chip

type	tag	name	clock
cpu	cpu	MIPS R3000A	20000000
audio	fdc:0:35hd:flopsndout	Speaker
audio	fdc:0:35hd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
software_list	sony_news	original	RISC,NWS3000

device_ref

name
r3000a
ram
dmac_0448
m48t02
scc85c30
z80scc_channel
z80scc_channel
rs232
rs232
am7990
upd72067
floppy_connector
floppy_35_hd
speaker
flopsnd
nscsi_bus
nscsi_connector
scsi_harddisk
harddisk_image
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
cxd1185
news_hid_hle
software_list
screen

biosset

name	description	default
nws3260	SONY NET WORK STATION R3000 Monitor Release 2.0A	no

sound

channels
1

feature

type	status	overall
sound	unemulated

ramoption

name	default
4M
8M
12M
20M
24M
32M
36M
48M
16M	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:35hd	floppy_3_5			floppydisk	flop
harddisk	scsi:0:harddisk:image	scsi_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:35hd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf
harddisk	scsi:0:harddisk:image	scsi_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		3		no	0	65535	100
keyboard		102		no

port, analog

port_tag	analog_masks
:SW2
:SW3
:hid:ROW0
:hid:ROW1
:hid:ROW2
:hid:ROW3
:hid:ROW4
:hid:ROW5
:hid:ROW6
:hid:ROW7
:hid:mouse_buttons
:hid:mouse_x_axis	65535
:hid:mouse_y_axis	65535

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
serial0	terminal	serial_terminal	no
serial0	sunkbd	sunkbd_adaptor	no
serial0	dec_loopback	dec_rs232_loopback	no
serial0	ie15	ie15_terminal	no
serial0	null_modem	null_modem	no
serial0	keyboard	serial_keyboard	no
serial0	patch	rs232_patch_box	no
serial0	swtpc8212	swtpc8212_terminal	no
serial0	printer	serial_printer	no
serial0	scorpion	scorpion_ic	no
serial0	loopback	rs232_loopback	no
serial0	mockingboard	mockingboardd	no
serial0	msystems_mouse	rs232_mouse_hle_msystems	no
serial0	nss_tvi	nss_tvinterface	no
serial0	rs232_sync_io	rs232_sync_io	no
serial0	pty	pseudo_terminal	no
serial0	rs_printer	rs_serial_printer	no
serial1	terminal	serial_terminal	no
serial1	sunkbd	sunkbd_adaptor	no
serial1	dec_loopback	dec_rs232_loopback	no
serial1	ie15	ie15_terminal	no
serial1	null_modem	null_modem	no
serial1	keyboard	serial_keyboard	no
serial1	patch	rs232_patch_box	no
serial1	swtpc8212	swtpc8212_terminal	no
serial1	printer	serial_printer	no
serial1	scorpion	scorpion_ic	no
serial1	loopback	rs232_loopback	no
serial1	mockingboard	mockingboardd	no
serial1	msystems_mouse	rs232_mouse_hle_msystems	no
serial1	nss_tvi	nss_tvinterface	no
serial1	rs232_sync_io	rs232_sync_io	no
serial1	pty	pseudo_terminal	no
serial1	rs_printer	rs_serial_printer	no
fdc:0	35hd	floppy_35_hd	yes
scsi:0	cdrom	scsi_cdrom	no
scsi:0	harddisk	scsi_harddisk	yes
scsi:1	cdrom	scsi_cdrom	no
scsi:1	harddisk	scsi_harddisk	no
scsi:2	cdrom	scsi_cdrom	no
scsi:2	harddisk	scsi_harddisk	no
scsi:3	cdrom	scsi_cdrom	no
scsi:3	harddisk	scsi_harddisk	no
scsi:4	cdrom	scsi_cdrom	no
scsi:4	harddisk	scsi_harddisk	no
scsi:5	cdrom	scsi_cdrom	no
scsi:5	harddisk	scsi_harddisk	no
scsi:6	cdrom	scsi_cdrom	no
scsi:6	harddisk	scsi_harddisk	no

dipswitch

Display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display	SW2	117440512

location

name	number	inverted
SW2	1	no
SW2	2	no
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Console	0	no
LCD	33554432	yes

Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot Device	SW2	134217728

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disk	0	yes
Network	134217728	no

Automatic Boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Automatic Boot	SW2	268435456

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	268435456	no

Diagnostic Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Diagnostic Mode	SW2	536870912

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	536870912	no

RAM

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RAM	SW2	1073741824

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Enabled	0	yes
Disabled	1073741824	no

Console Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Console Baud	SW2	2147483648

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
9600	0	yes
1200	2147483648	no
