NWS-3860 - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
nws3860	sony/news_38xx.cpp		no	no	no	yes	NWS-3860	1989	Sony

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
serial0:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
mpu_10__ver.1.6__1990_sony.ic159	65536	542e21b8	631dca1f3446761973073f5c32c1a0aeba538c2c	eprom	0	good	no		nws3860
idrom.bin	256	a2b9e968	09c7d253c7ed0b368c49f4b60bfe5ca76acd7cc3	idrom	0	baddump	no

chip

type	tag	name	clock
cpu	cpu	MIPS R3000A	20000000
cpu	iop	Motorola MC68030	20000000
audio	serial0:terminal:bell	Speaker
audio	serial0:terminal:beeper	Beep	2000
audio	fdc:0:35hd:flopsndout	Speaker
audio	fdc:0:35hd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
software_list	sony_news	original	RISC,NWS3000

device_ref

name
r3000a
m68030
ram
rtc62421
dmac_0266
dmac_0266
scc85c30
z80scc_channel
z80scc_channel
rs232
serial_terminal
screen
generic_keyboard
speaker
beep
rs232
am7990
n82077aa
floppy_connector
floppy_35_hd
speaker
flopsnd
nscsi_bus
nscsi_connector
scsi_harddisk
harddisk_image
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
scsi_tape
simh_tape_image
nscsi_connector
nscsi_connector
cxd1180
nscsi_bus
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
cxd1180
centronics
output_latch
news_hid_hle
software_list

biosset

name	description	default
nws3860	SONY NET WORK STATION MC68030 Monitor Release 1.6	no

sound

channels
2

feature

type	status	overall
graphics	unemulated
sound	unemulated

ramoption

name	default
32M
80M
16M	yes

device, instance

type	tag	interface	name	briefname
floppydisk	fdc:0:35hd	floppy_3_5	floppydisk	flop
harddisk	scsi0:0:harddisk:image	scsi_hdd,hdd	harddisk	hard
tape	scsi0:5:tape:image	tape	tape	tap

device, extension

type	tag	interface	extension_names
floppydisk	fdc:0:35hd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf
harddisk	scsi0:0:harddisk:image	scsi_hdd,hdd	chd, hd, hdv, 2mg, hdi
tape	scsi0:5:tape:image	tape	tap

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	reverse	minimum	maximum	sensitivity
mouse	1	3	no	0	65535	100
keyboard	1	73	no
keyboard	2	102	no

port, analog

port_tag	analog_masks
:SW1
:hid:ROW0
:hid:ROW1
:hid:ROW2
:hid:ROW3
:hid:ROW4
:hid:ROW5
:hid:ROW6
:hid:ROW7
:hid:mouse_buttons
:hid:mouse_x_axis	65535
:hid:mouse_y_axis	65535
:serial0:terminal:RS232_DATABITS
:serial0:terminal:RS232_PARITY
:serial0:terminal:RS232_RXBAUD
:serial0:terminal:RS232_STOPBITS
:serial0:terminal:RS232_TXBAUD
:serial0:terminal:TERM_CONF
:serial0:terminal:keyboard:GENKBD_CFG
:serial0:terminal:keyboard:GENKBD_MOD
:serial0:terminal:keyboard:GENKBD_ROW0
:serial0:terminal:keyboard:GENKBD_ROW1
:serial0:terminal:keyboard:GENKBD_ROW2
:serial0:terminal:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
serial0	terminal	serial_terminal	yes
serial0	sunkbd	sunkbd_adaptor	no
serial0	dec_loopback	dec_rs232_loopback	no
serial0	ie15	ie15_terminal	no
serial0	null_modem	null_modem	no
serial0	keyboard	serial_keyboard	no
serial0	patch	rs232_patch_box	no
serial0	swtpc8212	swtpc8212_terminal	no
serial0	printer	serial_printer	no
serial0	scorpion	scorpion_ic	no
serial0	loopback	rs232_loopback	no
serial0	mockingboard	mockingboardd	no
serial0	msystems_mouse	rs232_mouse_hle_msystems	no
serial0	nss_tvi	nss_tvinterface	no
serial0	rs232_sync_io	rs232_sync_io	no
serial0	pty	pseudo_terminal	no
serial0	votraxtnt	serial_votraxtnt	no
serial0	rs_printer	rs_serial_printer	no
serial1	terminal	serial_terminal	no
serial1	sunkbd	sunkbd_adaptor	no
serial1	dec_loopback	dec_rs232_loopback	no
serial1	ie15	ie15_terminal	no
serial1	null_modem	null_modem	no
serial1	keyboard	serial_keyboard	no
serial1	patch	rs232_patch_box	no
serial1	swtpc8212	swtpc8212_terminal	no
serial1	printer	serial_printer	no
serial1	scorpion	scorpion_ic	no
serial1	loopback	rs232_loopback	no
serial1	mockingboard	mockingboardd	no
serial1	msystems_mouse	rs232_mouse_hle_msystems	no
serial1	nss_tvi	nss_tvinterface	no
serial1	rs232_sync_io	rs232_sync_io	no
serial1	pty	pseudo_terminal	no
serial1	votraxtnt	serial_votraxtnt	no
serial1	rs_printer	rs_serial_printer	no
fdc:0	35hd	floppy_35_hd	yes
scsi0:0	tape	scsi_tape	no
scsi0:0	cdrom	scsi_cdrom	no
scsi0:0	harddisk	scsi_harddisk	yes
scsi0:1	tape	scsi_tape	no
scsi0:1	cdrom	scsi_cdrom	no
scsi0:1	harddisk	scsi_harddisk	no
scsi0:2	tape	scsi_tape	no
scsi0:2	cdrom	scsi_cdrom	no
scsi0:2	harddisk	scsi_harddisk	no
scsi0:3	tape	scsi_tape	no
scsi0:3	cdrom	scsi_cdrom	no
scsi0:3	harddisk	scsi_harddisk	no
scsi0:4	tape	scsi_tape	no
scsi0:4	cdrom	scsi_cdrom	no
scsi0:4	harddisk	scsi_harddisk	no
scsi0:5	tape	scsi_tape	yes
scsi0:5	cdrom	scsi_cdrom	no
scsi0:5	harddisk	scsi_harddisk	no
scsi0:6	tape	scsi_tape	no
scsi0:6	cdrom	scsi_cdrom	no
scsi0:6	harddisk	scsi_harddisk	no
scsi1:0	tape	scsi_tape	no
scsi1:0	cdrom	scsi_cdrom	no
scsi1:0	harddisk	scsi_harddisk	no
scsi1:1	tape	scsi_tape	no
scsi1:1	cdrom	scsi_cdrom	no
scsi1:1	harddisk	scsi_harddisk	no
scsi1:2	tape	scsi_tape	no
scsi1:2	cdrom	scsi_cdrom	no
scsi1:2	harddisk	scsi_harddisk	no
scsi1:3	tape	scsi_tape	no
scsi1:3	cdrom	scsi_cdrom	no
scsi1:3	harddisk	scsi_harddisk	no
scsi1:4	tape	scsi_tape	no
scsi1:4	cdrom	scsi_cdrom	no
scsi1:4	harddisk	scsi_harddisk	no
scsi1:5	tape	scsi_tape	no
scsi1:5	cdrom	scsi_cdrom	no
scsi1:5	harddisk	scsi_harddisk	no
scsi1:6	tape	scsi_tape	no
scsi1:6	cdrom	scsi_cdrom	no
scsi1:6	harddisk	scsi_harddisk	no
parallel	nlq401	nlq401	no
parallel	smartboard	centronics_smartboard	no
parallel	chessmec	centronics_chessmec	no
parallel	samdac	centronics_samdac	no
parallel	covox_stereo	covox_stereo	no
parallel	adaptator	adaptator_multitap	no
parallel	digiblst	cpcdigiblst	no
parallel	lx800	lx800	no
parallel	jx80	epson_jx80	no
parallel	ap2000	ap2000	no
parallel	ex800	ex800	no
parallel	fx80	epson_fx80	no
parallel	rx80	epson_rx80	no
parallel	mz1p16	mz1p16	no
parallel	covox	covox	no
parallel	pl80	comx_pl80	no
parallel	lx810l	lx810l	no
parallel	p72	p72	no
parallel	printer	centronics_printer	no

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	serial0:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	serial0:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	serial0:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	serial0:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	serial0:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	serial0:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	serial0:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	serial0:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	serial0:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	serial0:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	serial0:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	serial0:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	serial0:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	serial0:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	serial0:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	serial0:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

dipswitch

Display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display	SW1	117440512

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default
Console	117440512	yes
NWB-512	100663296	no
NWB-225A	50331648	no
Autoselect	0	no

Boot Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot Device	SW1	134217728

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
SCSI	134217728	yes
Floppy	0	no

Automatic Boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Automatic Boot	SW1	268435456

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	268435456	yes
On	0	no

Diagnostic Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Diagnostic Mode	SW1	536870912

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	536870912	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SW1	3221225472

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	3221225472	yes
