PC-X - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pcx	siemens/pcd.cpp		no	no	no	yes	PC-X	1984	Siemens	pcd	pcd

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
video:screen	raster	0	960	350	49.522112	24000000	1272	0	960	381	0	350	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional	merge	bios
s26361-d359.d42	8192	e20244dd	0ebc5ddb93baacd9106f1917380de58aac64fe73	bios	1	good	no	s26361-d359.d42	v2
s26361-d359.d43	8192	e03db2ec	fcae8b0c9e7543706817b0a53872826633361fda	bios	0	good	no	s26361-d359.d43	v2
361d0359.d42	8192	5b4461e4	db6756aeabb2e6d3921dc7571a5bed3497b964bf	bios	1	good	no	361d0359.d42	v3
361d0359.d43	8192	71c3189d	e8dd6c632bfc833074d3a833ea7f59bb5460f313	bios	0	good	no	361d0359.d43	v3

type	tag	name	clock
cpu	maincpu	Intel 80186	16000000
cpu	video:graphics	Intel 8031	12000000
cpu	keyboard:mcu	Intel 8035	5760000
audio	fdc:0:55f:flopsndout	Speaker
audio	fdc:0:55f:floppysound	Floppy sound	44100
audio	fdc:1:55f:flopsndout	Speaker
audio	fdc:1:55f:floppysound	Floppy sound	44100
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	keyboard:mono	Speaker
audio	keyboard:speaker	Filtered DAC

tag	name	status	filter
flop_ls	pcx_flop	original

name	description	default
v2	V2 GS	no
v3	V3 GS4	no

channels
4

name	default
1M	yes

device, instance

type	tag	interface	name	briefname
floppydisk	fdc:0:55f	floppy_5_25	floppydisk1	flop1
floppydisk	fdc:1:55f	floppy_5_25	floppydisk2	flop2
harddisk	scsi:1:harddisk:image0		harddisk1	hard1
harddisk	scsi:1:harddisk:image1		harddisk2	hard2

type	tag	interface	extension_names
floppydisk	fdc:0:55f	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf
floppydisk	fdc:1:55f	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf
harddisk	scsi:1:harddisk:image0		chd, hd, hdv, 2mg, hdi
harddisk	scsi:1:harddisk:image1		chd, hd, hdv, 2mg, hdi

players	coins	service	tilt
1		no	no

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		126		no

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	55g	teac_fd_55g	no
fdc:0	55f	teac_fd_55f	yes
fdc:1	55g	teac_fd_55g	no
fdc:1	55f	teac_fd_55f	yes
rs232_1	terminal	serial_terminal	no
rs232_1	sunkbd	sunkbd_adaptor	no
rs232_1	dec_loopback	dec_rs232_loopback	no
rs232_1	ie15	ie15_terminal	no
rs232_1	null_modem	null_modem	no
rs232_1	keyboard	serial_keyboard	no
rs232_1	patch	rs232_patch_box	no
rs232_1	swtpc8212	swtpc8212_terminal	no
rs232_1	printer	serial_printer	no
rs232_1	scorpion	scorpion_ic	no
rs232_1	loopback	rs232_loopback	no
rs232_1	mockingboard	mockingboardd	no
rs232_1	msystems_mouse	rs232_mouse_hle_msystems	no
rs232_1	nss_tvi	nss_tvinterface	no
rs232_1	rs232_sync_io	rs232_sync_io	no
rs232_1	pty	pseudo_terminal	no
rs232_1	rs_printer	rs_serial_printer	no
rs232_2	terminal	serial_terminal	no
rs232_2	sunkbd	sunkbd_adaptor	no
rs232_2	dec_loopback	dec_rs232_loopback	no
rs232_2	ie15	ie15_terminal	no
rs232_2	null_modem	null_modem	no
rs232_2	keyboard	serial_keyboard	no
rs232_2	patch	rs232_patch_box	no
rs232_2	swtpc8212	swtpc8212_terminal	no
rs232_2	printer	serial_printer	no
rs232_2	scorpion	scorpion_ic	no
rs232_2	loopback	rs232_loopback	no
rs232_2	mockingboard	mockingboardd	no
rs232_2	msystems_mouse	rs232_mouse_hle_msystems	no
rs232_2	nss_tvi	nss_tvinterface	no
rs232_2	rs232_sync_io	rs232_sync_io	no
rs232_2	pty	pseudo_terminal	no
rs232_2	rs_printer	rs_serial_printer	no
scsi:1	harddisk	omti5100	yes
scsi:2
scsi:3
scsi:4
scsi:5
scsi:6
scsi:7

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MMU Type	mmu	3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
SCSI ID	scsi:1:harddisk:SCSI_ID	7
