mame (0289) • machine sc5tbox • Top Box (Mazooma) (Scorpion 5) (set 1)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sc5tbox	bfm/bfm_sc5sw.cpp		no	no	yes	yes	Top Box (Mazooma) (Scorpion 5) (set 1)	200?	Mazooma

snap

Top Box (Mazooma) (Scorpion 5) (set 1) png snap

Top Box (Mazooma) (Scorpion 5) (set 1) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
sc5tbox	9504	25/09/2026 12:12:23	640	480	96	96	0	Format24bppRgb	305:MAME 0.289 (mame0289)	82d83dc381b67af71c92afa00c2a5c23dbe6bad1

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
75585130_gal20v8c.ic29	343	d3a6d883	5a968c34958bfe415e372bfa11004f82b29366ff	pld	0	good	no
95414778.lo	524288	487c5cc4	a9145aba9402d86ab70c46f09c85f6f3d46fd205	maincpu	1	good	no
95414779.hi	524288	2873e6b2	81c9a4505367402924793720a753e035972e38ce	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Freescale MCF5206E	40000000
audio	mono	Speaker
audio	ymz	Yamaha YMZ280B PCMD8	16000000

device_ref

tag	name
:maincpu	mcf5206e
:maincpu:sim	coldfire_sim
:maincpu:sim:watchdog	watchdog
:maincpu:timer1	coldfire_timer
:maincpu:timer2	coldfire_timer
:maincpu:uart1	mcf5206euart
:maincpu:uart1:cha	duart_channel
:maincpu:uart1:chb	duart_channel
:maincpu:uart2	mcf5206euart
:maincpu:uart2:cha	duart_channel
:maincpu:uart2:chb	duart_channel
:maincpu:mbus	coldfire_mbus
:maincpu:dma0	coldfire_dma
:maincpu:dma1	coldfire_dma
:mono	speaker
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:vfd1	bfm_gu96x8m_k657c2
:ymz	ymz280b

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
0		no	no

clones

name	description
sc5tboxi	Top Box (Mazooma) (Scorpion 5) (set 10)
sc5tboxj	Top Box (Mazooma) (Scorpion 5) (set 11)
sc5tboxk	Top Box (Mazooma) (Scorpion 5) (set 12)
sc5tboxl	Top Box (Mazooma) (Scorpion 5) (set 13)
sc5tboxm	Top Box (Mazooma) (Scorpion 5) (set 14)
sc5tboxn	Top Box (Mazooma) (Scorpion 5) (set 15)
sc5tboxo	Top Box (Mazooma) (Scorpion 5) (set 16)
sc5tboxp	Top Box (Mazooma) (Scorpion 5) (set 17)
sc5tboxq	Top Box (Mazooma) (Scorpion 5) (set 18)
sc5tboxa	Top Box (Mazooma) (Scorpion 5) (set 2)
sc5tboxb	Top Box (Mazooma) (Scorpion 5) (set 3)
sc5tboxc	Top Box (Mazooma) (Scorpion 5) (set 4)
sc5tboxd	Top Box (Mazooma) (Scorpion 5) (set 5)
sc5tboxe	Top Box (Mazooma) (Scorpion 5) (set 6)
sc5tboxf	Top Box (Mazooma) (Scorpion 5) (set 7)
sc5tboxg	Top Box (Mazooma) (Scorpion 5) (set 8)
sc5tboxh	Top Box (Mazooma) (Scorpion 5) (set 9)
