Top Box (Mazooma) (Scorpion 5) (set 16) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sc5tboxo	bfm/bfm_sc5sw.cpp		no	no	yes	yes	Top Box (Mazooma) (Scorpion 5) (set 16)	200?	Mazooma	sc5tbox	sc5tbox

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
95417142.lo	524288	e51d2ea6	7270cd90ea1c95675102bc7cb75e819a9c4b51c5	maincpu	1	good	no
95417143.hi	524288	0204eef4	6a240c108f5e196aff7b0e2caf81cd9b366d12dd	maincpu	0	good	no
75585130_gal20v8c.ic29	343	d3a6d883	5a968c34958bfe415e372bfa11004f82b29366ff	pld	0	good	no	75585130_gal20v8c.ic29

chip

type	tag	name	clock
cpu	maincpu	Freescale MCF5206E	40000000
audio	mono	Speaker
audio	ymz	Yamaha YMZ280B PCMD8	16000000

device_ref

tag	name
:maincpu	mcf5206e
:maincpu:sim	coldfire_sim
:maincpu:sim:watchdog	watchdog
:maincpu:timer1	coldfire_timer
:maincpu:timer2	coldfire_timer
:maincpu:uart1	mcf5206euart
:maincpu:uart1:cha	duart_channel
:maincpu:uart1:chb	duart_channel
:maincpu:uart2	mcf5206euart
:maincpu:uart2:cha	duart_channel
:maincpu:uart2:chb	duart_channel
:maincpu:mbus	coldfire_mbus
:maincpu:dma0	coldfire_dma
:maincpu:dma1	coldfire_dma
:mono	speaker
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:vfd1	bfm_gu96x8m_k657c2
:ymz	ymz280b

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
0		no	no
