name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
super80v	ausnz/super80.cpp	relay	no	no	no	yes	Super-80 (with enhanced VDUEB)	1981	Dick Smith Electronics	super80	super80

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	560	300	50.000000	8400000	560	0	560	300	0	300	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	yes	no	no

rom

name	size	crc	sha1	region	offset	status	optional
s80-v37v.u26	4096	01e0c0dd	ef66af9c44c651c65a21d5bda939ffa100078c08	maincpu	0	good	no
s80-v37v.u33	4096	812ad777	04f355bea3470a7d9ea23bb2811f6af7d81dc400	maincpu	1000	good	no
s80-v37v.u42	4096	e02e736e	57b0264c805da99234ab5e8e028fca456851a4f9	maincpu	2000	good	no
s80hmce.ic24	2048	a6488a1e	7ba613d70a37a6b738dcd80c2bb9988ff1f011ef	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	2000000
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	samples	Samples
audio	cassette	Cassette
audio	fdc:0:s80flop:flopsndout	Speaker
audio	fdc:0:s80flop:floppysound	Floppy sound	44100
audio	fdc:1:s80flop:flopsndout	Speaker
audio	fdc:1:s80flop:floppysound	Floppy sound	44100
audio	fdc:2:s80flop:flopsndout	Speaker
audio	fdc:2:s80flop:floppysound	Floppy sound	44100
audio	fdc:3:s80flop:flopsndout	Speaker
audio	fdc:3:s80flop:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
cass_list	super80_cass	original	V
quik_list	super80_quik	original	V
flop_list	super80_flop	original

device_ref

name
z80
z80pio
screen
palette
gfxdecode
mc6845
speaker
speaker_sound_device
samples
centronics
centronics_printer
printer_image
output_latch
input_buffer
quickload
cassette_image
timer
timer
z80dma
wd2793
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
software_list
software_list
software_list

sample

name
relayoff
relayon

sound

channels
5

device, instance

type	tag	interface	name	briefname
printout	centronics:printer:printer		printout	prin
quickload	quickload	super80_quik	quickload	quik
cassette	cassette	super80_cass	cassette	cass
floppydisk	fdc:0:s80flop	floppy_5_25	floppydisk1	flop1
floppydisk	fdc:1:s80flop	floppy_5_25	floppydisk2	flop2
floppydisk	fdc:2:s80flop	floppy_5_25	floppydisk3	flop3
floppydisk	fdc:3:s80flop	floppy_5_25	floppydisk4	flop4

device, extension

type	tag	interface	extension_names
printout	centronics:printer:printer		prn
quickload	quickload	super80_quik	bin
cassette	cassette	super80_cass	wav, flac
floppydisk	fdc:0:s80flop	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:s80flop	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:2:s80flop	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:3:s80flop	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		64		no

port, analog

port_tag	analog_masks
:CONFIG
:DSW
:KEY.0
:KEY.1
:KEY.2
:KEY.3
:KEY.4
:KEY.5
:KEY.6
:KEY.7

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
fdc:0	s80flop	floppy_525_qd	yes
fdc:1	s80flop	floppy_525_qd	yes
fdc:2	s80flop	floppy_525_qd	yes
fdc:3	s80flop	floppy_525_qd	yes

configuration

Autorun on Quickload

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Autorun on Quickload	CONFIG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Cassette Speaker

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cassette Speaker	CONFIG	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	8	yes
Off	0	no

Colour

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Colour	CONFIG	96

setting

name	value	default
White	96	no
Green	64	yes
Composite	0	no
RGB	32	no

dipswitch

Switch A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch A	DSW	16

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

Switch B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch B	DSW	32

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Switch C

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch C	DSW	64

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Switch D

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch D	DSW	128

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes
