Time Scanner (set 2, System 16B) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
timescan	sega/segas16b.cpp		no	no	no	yes	Time Scanner (set 2, System 16B)	1987	Sega

snap

Time Scanner (set 2, System 16B) png snap

Time Scanner (set 2, System 16B) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
timescan	19883	29/12/2025 11:31:47	224	320	96	96	0	Format24bppRgb	305:MAME 0.127u1 (Aug 28 2008)	55d424d164fd290feb860dd6305deedcaad1f58d

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	224	60.054389	6293700	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
epr-10853.a4	32768	24d7c5fb	b1796e77cf968f9bdae7a47c5c02b93aaec10ade	maincpu	0	good	no
epr-10850.a1	32768	f1575732	d0c8fc42171c436cc1cd55a33295bd019a474d47	maincpu	1	good	no
epr-10854.a5	32768	82d0b237	c1defda4785014ccd7164f49f53f77e36fcb3a8d	maincpu	10000	good	no
epr-10851.a2	32768	f5ce271b	8b4f1178c87e657d8d5805d908100f0d5fb030da	maincpu	10001	good	no
epr-10855.a6	32768	63e95a53	60c42bbb1c316deb493a237990a7938551f8bc2e	maincpu	20000	good	no
epr-10852.a3	32768	7cd1382b	6263cc863cbf0ef66a7ba8cc1c98212917d7c131	maincpu	20001	good	no
epr-10543.b9	32768	07dccc37	544cc6a3b3ef64727ecf5098b84ade2dd5330614	tiles	0	good	no
epr-10544.b10	32768	84fb9a3a	efde54cc9582f68e58cae05f717a4fc8f620c0fc	tiles	8000	good	no
epr-10545.b11	32768	c8694bc0	e48fc349ef454ded86141937f70b006e64da6b6b	tiles	10000	good	no
epr-10548.b1	32768	aa150735	b6e6ff9229c641e196fc7a0a2cf7aa362f554676	sprites	1	good	no
epr-10552.b5	32768	6fcbb9f7	0a0fab930477d8b79e500263bbc80d3bf73778f8	sprites	0	good	no
epr-10549.b2	32768	2f59f067	1fb64cce2f98ddcb5ecb662e63ea636a8da08bcd	sprites	20001	good	no
epr-10553.b6	32768	8a220a9f	c17547d85721fa19e5f445b5be30b3fbf5e8cc6e	sprites	20000	good	no
epr-10550.b3	32768	f05069ff	bd95761036c2fad8ddf4e169d899b173822ee4b0	sprites	40001	good	no
epr-10554.b7	32768	dc64f809	ea85eefa98ec55e9e872940821a959ff4eb1bd1c	sprites	40000	good	no
epr-10551.b4	32768	435d811f	b28eb09620113cd7578387c4d96029f2acb8ec06	sprites	60001	good	no
epr-10555.b8	32768	2143c471	d413aa216349ddf773a39d2826c3a940b4149229	sprites	60000	good	no
epr-10562.a7	32768	3f5028bf	02081569a5f4dc64771e97651a9902a98d54a952	soundcpu	0	good	no
epr-10563.a8	32768	9db7eddf	8b9a27442a623bee6b9b5b06275226734d132e17	soundcpu	10000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	soundcpu	Zilog Z80	5000000
audio	mono	Speaker
audio	ym2151	YM2151 OPM	4000000
audio	upd	NEC uPD7759	640000
audio	netlist	Netlist Sound Device

device_ref

tag	name
:maincpu	m68000
:soundcpu	z80
:nvram	nvram
:mapper	sega_315_5195
:gfxdecode	gfxdecode
:palette	palette
:screen	screen
:sprites	sega_sys16b_sprite
:segaic16vid	segaic16_video
:mono	speaker
:ym2151	ym2151
:upd	upd7759
:netlist	netlist_sound
:netlist:cin0	nl_stream_in
:netlist:cin1	nl_stream_in
:netlist:cin2	nl_stream_in
:netlist:cout0	nl_stream_out

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
joy	1	3	5 (half8)	no
joy	2	3	5 (half8)	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SERVICE
:UNUSED

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
3 Coins/4 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
3 Coins/4 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	1	yes
Cocktail	0	no

Extended Score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extended Score	DSW2	30

location

name	number	inverted
SW2	2	no
SW2	3	no
SW2	4	no
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Credit 1000000/2000000	22	no
Credit 1200000/2500000	20	no
Credit 1500000/3000000	18	no
Credit 2000000/4000000	16	no
Credit 1000000	28	no
Credit 1200000	30	yes
Credit 1500000	26	no
Credit 1800000	24	no
Ball 100000	14	no
Ball 200000	12	no
Ball 300000	10	no
Ball 400000	8	no
Ball 500000	6	no
Ball 600000	4	no
Ball 700000	2	no
None	0	no

Number Match

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number Match	DSW2	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	32	yes

Pin Rebound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Pin Rebound	DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Well	64	yes
A Little	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	128	yes
5	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	UNUSED	1

location

name	number	inverted
SWE	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Out Lane Pin

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Out Lane Pin	UNUSED	2

location

name	number	inverted
SWE	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Near	2	yes
Far	0	no

Special

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Special	UNUSED	12

location

name	number	inverted
SWE	3	no
SWE	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Credits	8	no
2 Credits	12	yes
1 Credit	4	no
2000000 Points	0	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	UNUSED	16

location

name	number	inverted
SWE	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	16	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	UNUSED	32

location

name	number	inverted
SWE	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	UNUSED	64

location

name	number	inverted
SWE	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	UNUSED	128

location

name	number	inverted
SWE	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

clones

name	description
timescanbl	Time Scanner (bootleg)
timescan1	Time Scanner (set 1, System 16A, FD1089B 317-0024)
timescan3	Time Scanner (set 3, Japan, System 16B) (FD1089B 317-0024)
