Video Pinball (16 PROMs version) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
videopin	atari/videopin.cpp		no	no	no	yes	Video Pinball (16 PROMs version)	1979	Atari

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	304	256	60.000000	4797120	304	0	304	263	0	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
34242-01.e0	1024	c6a83795	73a65cca7c1e337b336b7d515eafc2981e669be8	maincpu	2000	good	no
34237-01.k0	1024	9b5ef087	4ecf441742e7c39237cd544b0f0d9339943e1a2c	maincpu	2000	good	no
34243-01.d0	1024	dc87d023	1ecec121067a60b91b3912bd28737caaae463167	maincpu	2400	good	no
34238-01.j0	1024	280d9e67	229cc0448bb95f86fc7acbcb9594bc313f316580	maincpu	2400	good	no
34250-01.h1	1024	26fdd5a3	a5f1624b36f58fcdfc7c6c04784340bb08a89785	maincpu	2800	good	no
34249-01.h1	1024	923b3609	1b9fc60b27ff80b0ec26d897ea1817f466269506	maincpu	2800	good	no
34244-01.c0	1024	4c12a4b1	4351887a8dada92cd24cfa5930456e7c5c251ceb	maincpu	2c00	good	no
34240-01.h0	1024	d487eff5	45bbf7e693f5471ea25e6ec71ce34708335d2d0b	maincpu	2c00	good	no
34252-01.e1	1024	4858d87a	a50d7ef3d7a804defa25483768cf1a931dd799d5	maincpu	3000	good	no
34247-01.k1	1024	d3083368	c2083edb0f424dbf02caeaf786ab572326ae48d0	maincpu	3000	good	no
34246-01.a0	1024	39ff2d49	59221be088d783210516858a4272f7364e00e7b4	maincpu	3400	good	no
34239-01.h0	1024	692de455	ccbed14cdbeaf23961c356dfac98c6c7fb022486	maincpu	3400	good	no
34251-01.f1	1024	5d416efc	1debd835cc3e52f526fc0aab4955be7f3682b8c0	maincpu	3800	good	no
34248-01.j1	1024	9f120e95	d7434f437137690873cba66b408ec8e92b6509c1	maincpu	3800	good	no
34245-01.b0	1024	da02c194	a4ec66c85f084286d13a9fc0b35ba5ad896bef44	maincpu	3c00	good	no
34241-01.f0	1024	5bfb83da	9f392b0d4a972b6ae15ec12913a7e66761f4175d	maincpu	3c00	good	no
34259-01.d5	512	6cd98c06	48bf077b7abbd2f529a19bdf85700b93014f39f9	tiles	0	good	no
34258-01.c5	512	91a5f117	03ac6b0b3da0ed5faf1ba6695d16918d12ceeff5	tiles	0	good	no
34257-01.m1	32	50245866	b0692bc8d44f127f6e7182a1ce75a785e22ac5b9	ball	0	good	no
9402-01.h4	256	b8094b4c	82dc6799a19984f3b204ee3aeeb007e55afc8be3	sync_prom	0	good	no

chip

type	tag	name	clock
cpu	maincpu	MOS Technology 6502	756000
audio	mono	Speaker
audio	discrete	Discrete Sound

device_ref

name
m6502
watchdog
screen
gfxdecode
palette
speaker
discrete

sound

channels
1

input

players	coins	service	tilt
1	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		4		no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

Replay Level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Replay Level	DSW	1

location

name	number	inverted
DSW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
180000 (3 balls) / 300000 (5 balls)	0	no
210000 (3 balls) / 350000 (5 balls)	1	yes

Extra Ball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extra Ball	DSW	2

location

name	number	inverted
DSW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off (award 50000 points instead)	2	no
On	0	yes

Replay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Replay	DSW	4

location

name	number	inverted
DSW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off (award 80000 points instead)	4	no
On	0	yes

Balls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Balls	DSW	8

location

name	number	inverted
DSW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	8	yes
5	0	no

Language

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Language	DSW	48

location

name	number	inverted
DSW	6	no
DSW	5	no

value

name	value	default
English	0	yes
German	16	no
French	32	no
Spanish	48	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	192

location

name	number	inverted
DSW	8	no
DSW	7	no

value

name	value	default
2 Coins/1 Credit	192	no
1 Coin/1 Credit	128	yes
1 Coin/2 Credits	64	no
Free Play	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	IN0	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no
