Acorn M4 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
am4	acorn/aa310.cpp		no	no	no	yes	Acorn M4	1988	Acorn Computers

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	735	292	50.080128	16000000	1024	0	735	312	0	292	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
m4_arf_0.bin	65536	b54544c2	f75d6b4c8506d1f14f9583b4175af0c8accd8562	maincpu	0	good	no
m4_arf_1.bin	65536	cd6fe9be	07acf52a9cc81939998f52836be477285571f332	maincpu	1	good	no
m4_arf_2.bin	65536	575ffc0a	816008aa5bd5cfbace07ae4b5e4691951beccf76	maincpu	2	good	no
m4_arf_3.bin	65536	78feaa86	476d9c0006b857b51fa272eef819ecfc8b4257d8	maincpu	3	good	no

chip

type	tag	name	clock
cpu	maincpu	ARM	8000000
cpu	keyboard:mcu	Intel 8051	12000000
audio	vidc:lspeaker	Speaker
audio	vidc:rspeaker	Speaker
audio	vidc:dac0	16-Bit R-2R Twos Complement DAC
audio	vidc:dac1	16-Bit R-2R Twos Complement DAC
audio	vidc:dac2	16-Bit R-2R Twos Complement DAC
audio	vidc:dac3	16-Bit R-2R Twos Complement DAC
audio	vidc:dac4	16-Bit R-2R Twos Complement DAC
audio	vidc:dac5	16-Bit R-2R Twos Complement DAC
audio	vidc:dac6	16-Bit R-2R Twos Complement DAC
audio	vidc:dac7	16-Bit R-2R Twos Complement DAC
audio	fdc:0:35dd:flopsndout	Speaker
audio	fdc:0:35dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
flop_list	archimedes	original
hdd_list	archimedes_hdd	original
rom_list	archimedes_rom	original	ARC

device_ref

name
arm_cpu
memc
ioc
archimedes_keyboard
i8051
screen
acorn_vidc1a
speaker
speaker
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
dac_16bit_r2r_tc
ram
software_list
software_list
software_list
archimedes_exp
pcf8583
fd1793
floppy_connector
floppy_35_dd
speaker
flopsnd
floppy_connector
centronics
input_buffer
output_latch
output_latch
scc8530
z80scc_channel
z80scc_channel
rs232
rs232
nscsi_bus
nscsi_connector
scsi_harddisk
harddisk_image
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
nscsi_connector
wd33c93a
archimedes_exp_slot
arc_tube
tube
archimedes_exp_slot
archimedes_exp_slot
archimedes_exp_slot

sound

channels
3

ramoption

name	default
8M	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:35dd	floppy_3_5			floppydisk	flop
harddisk	scsi:0:harddisk:image	scsi_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:35dd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, adf, apd, jfd, ads, adm, adl, ssd, bbc, dsd, st, msa
harddisk	scsi:0:harddisk:image	scsi_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse				no	0	65535	100
keyboard		106		no

port, analog

port_tag	analog_masks
:keyboard:MOUSE.0	65535
:keyboard:MOUSE.1	65535
:keyboard:MOUSE.2
:keyboard:ROW.0
:keyboard:ROW.1
:keyboard:ROW.10
:keyboard:ROW.11
:keyboard:ROW.12
:keyboard:ROW.13
:keyboard:ROW.14
:keyboard:ROW.15
:keyboard:ROW.2
:keyboard:ROW.3
:keyboard:ROW.4
:keyboard:ROW.5
:keyboard:ROW.6
:keyboard:ROW.7
:keyboard:ROW.8
:keyboard:ROW.9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	525qd	floppy_525_qd	no
fdc:0	525sd	floppy_525_sd	no
fdc:0	35hd	floppy_35_hd	no
fdc:0	35dd	floppy_35_dd	yes
fdc:1	525qd	floppy_525_qd	no
fdc:1	525sd	floppy_525_sd	no
fdc:1	35hd	floppy_35_hd	no
fdc:1	35dd	floppy_35_dd	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	no
rs232a	terminal	serial_terminal	no
rs232a	sunkbd	sunkbd_adaptor	no
rs232a	dec_loopback	dec_rs232_loopback	no
rs232a	ie15	ie15_terminal	no
rs232a	null_modem	null_modem	no
rs232a	keyboard	serial_keyboard	no
rs232a	patch	rs232_patch_box	no
rs232a	swtpc8212	swtpc8212_terminal	no
rs232a	printer	serial_printer	no
rs232a	scorpion	scorpion_ic	no
rs232a	loopback	rs232_loopback	no
rs232a	mockingboard	mockingboardd	no
rs232a	msystems_mouse	rs232_mouse_hle_msystems	no
rs232a	nss_tvi	nss_tvinterface	no
rs232a	rs232_sync_io	rs232_sync_io	no
rs232a	pty	pseudo_terminal	no
rs232a	rs_printer	rs_serial_printer	no
rs232b	terminal	serial_terminal	no
rs232b	sunkbd	sunkbd_adaptor	no
rs232b	dec_loopback	dec_rs232_loopback	no
rs232b	ie15	ie15_terminal	no
rs232b	null_modem	null_modem	no
rs232b	keyboard	serial_keyboard	no
rs232b	patch	rs232_patch_box	no
rs232b	swtpc8212	swtpc8212_terminal	no
rs232b	printer	serial_printer	no
rs232b	scorpion	scorpion_ic	no
rs232b	loopback	rs232_loopback	no
rs232b	mockingboard	mockingboardd	no
rs232b	msystems_mouse	rs232_mouse_hle_msystems	no
rs232b	nss_tvi	nss_tvinterface	no
rs232b	rs232_sync_io	rs232_sync_io	no
rs232b	pty	pseudo_terminal	no
rs232b	rs_printer	rs_serial_printer	no
scsi:1	cfp1080s	cfp1080s	no
scsi:1	aplcdsc	scsi_cdrom_apple	no
scsi:1	aplcd150	aplcd150	no
scsi:1	tape	scsi_tape	no
scsi:1	s1410	scsi_s1410	no
scsi:1	harddisk	scsi_harddisk	no
scsi:1	cw7501	cw7501	no
scsi:1	crd254sh	crd254sh	no
scsi:1	cdr4210	cdr4210	no
scsi:1	cdrn820s	cdrn820s	no
scsi:1	cdu75s	cdu75s	no
scsi:1	cdrom	scsi_cdrom	no
scsi:1	cdu415	cdu415	no
scsi:1	cdu561_25	cdu561_25	no
scsi:1	cdd2000	cdd2000	no
scsi:1	smoc501	smoc501	no
scsi:2	cfp1080s	cfp1080s	no
scsi:2	aplcdsc	scsi_cdrom_apple	no
scsi:2	aplcd150	aplcd150	no
scsi:2	tape	scsi_tape	no
scsi:2	s1410	scsi_s1410	no
scsi:2	harddisk	scsi_harddisk	no
scsi:2	cw7501	cw7501	no
scsi:2	crd254sh	crd254sh	no
scsi:2	cdr4210	cdr4210	no
scsi:2	cdrn820s	cdrn820s	no
scsi:2	cdu75s	cdu75s	no
scsi:2	cdrom	scsi_cdrom	no
scsi:2	cdu415	cdu415	no
scsi:2	cdu561_25	cdu561_25	no
scsi:2	cdd2000	cdd2000	no
scsi:2	smoc501	smoc501	no
scsi:3	cfp1080s	cfp1080s	no
scsi:3	aplcdsc	scsi_cdrom_apple	no
scsi:3	aplcd150	aplcd150	no
scsi:3	tape	scsi_tape	no
scsi:3	s1410	scsi_s1410	no
scsi:3	harddisk	scsi_harddisk	no
scsi:3	cw7501	cw7501	no
scsi:3	crd254sh	crd254sh	no
scsi:3	cdr4210	cdr4210	no
scsi:3	cdrn820s	cdrn820s	no
scsi:3	cdu75s	cdu75s	no
scsi:3	cdrom	scsi_cdrom	no
scsi:3	cdu415	cdu415	no
scsi:3	cdu561_25	cdu561_25	no
scsi:3	cdd2000	cdd2000	no
scsi:3	smoc501	smoc501	no
scsi:4	cfp1080s	cfp1080s	no
scsi:4	aplcdsc	scsi_cdrom_apple	no
scsi:4	aplcd150	aplcd150	no
scsi:4	tape	scsi_tape	no
scsi:4	s1410	scsi_s1410	no
scsi:4	harddisk	scsi_harddisk	no
scsi:4	cw7501	cw7501	no
scsi:4	crd254sh	crd254sh	no
scsi:4	cdr4210	cdr4210	no
scsi:4	cdrn820s	cdrn820s	no
scsi:4	cdu75s	cdu75s	no
scsi:4	cdrom	scsi_cdrom	no
scsi:4	cdu415	cdu415	no
scsi:4	cdu561_25	cdu561_25	no
scsi:4	cdd2000	cdd2000	no
scsi:4	smoc501	smoc501	no
scsi:5	cfp1080s	cfp1080s	no
scsi:5	aplcdsc	scsi_cdrom_apple	no
scsi:5	aplcd150	aplcd150	no
scsi:5	tape	scsi_tape	no
scsi:5	s1410	scsi_s1410	no
scsi:5	harddisk	scsi_harddisk	no
scsi:5	cw7501	cw7501	no
scsi:5	crd254sh	crd254sh	no
scsi:5	cdr4210	cdr4210	no
scsi:5	cdrn820s	cdrn820s	no
scsi:5	cdu75s	cdu75s	no
scsi:5	cdrom	scsi_cdrom	no
scsi:5	cdu415	cdu415	no
scsi:5	cdu561_25	cdu561_25	no
scsi:5	cdd2000	cdd2000	no
scsi:5	smoc501	smoc501	no
scsi:6	cfp1080s	cfp1080s	no
scsi:6	aplcdsc	scsi_cdrom_apple	no
scsi:6	aplcd150	aplcd150	no
scsi:6	tape	scsi_tape	no
scsi:6	s1410	scsi_s1410	no
scsi:6	harddisk	scsi_harddisk	no
scsi:6	cw7501	cw7501	no
scsi:6	crd254sh	crd254sh	no
scsi:6	cdr4210	cdr4210	no
scsi:6	cdrn820s	cdrn820s	no
scsi:6	cdu75s	cdu75s	no
scsi:6	cdrom	scsi_cdrom	no
scsi:6	cdu415	cdu415	no
scsi:6	cdu561_25	cdu561_25	no
scsi:6	cdd2000	cdd2000	no
scsi:6	smoc501	smoc501	no
podule0	ua_morley	arc_ua_morley	no
podule0	tube	arc_tube	yes
podule0	serial	arc_serial	no
podule0	scsi_aka32	arc_scsi_aka32	no
podule0	scsi_aka31	arc_scsi_aka31	no
podule0	scsi_a500	arc_scsi_a500	no
podule0	scsi_vti	arc_scsi_vti	no
podule0	scanjunior3	arc_scanjunior3	no
podule0	scanjunior	arc_scanjunior	no
podule0	scanlight	arc_scanlight	no
podule0	scan256	arc_scan256	no
podule0	scsi_morley	arc_scsi_morley	no
podule0	greyhawk	arc_greyhawk	no
podule0	rom_r225boot	arc_rom_r225	no
podule0	ether1	arc_ether1_aka25	no
podule0	hdisc_cw	arc_hdisc_cw	no
podule0	faxpack	arc_faxpack	no
podule0	eaglem2	arc_eaglem2	no
podule0	bbcio_aka10	arc_bbcio_aka10	no
podule0	hdisc_akd52	arc_hdisc_akd52	no
podule0	scsi_oak	arc_scsi_oak	no
podule0	scsi_cumana	arc_scsi_cumana	no
podule0	bbcio_we	arc_bbcio_we	no
podule0	etherr	arc_etherr	no
podule0	midi2	arc_midi2	no
podule0	scanvideo	arc_scanvideo	no
podule0	ether2	arc_ether2_aeh50	no
podule0	midi4	arc_midi4	no
podule0	nexus_a500	arc_nexus_a500	no
podule0	hdisc_morley	arc_hdisc_morley	no
podule0	ether3_aeh54	arc_ether3_aeh54	no
podule0	midimax	arc_midimax	no
podule0	hdisc_we	arc_hdisc_we	no
podule0	acejoy	arc_acejoy	no
podule0	ide_be	arc_ide_be	no
podule0	ide_rdev	arc_ide_rdev	no
podule0	lark	arc_lark	no
podule0	midimax2	arc_midimax2	no
podule0	scsi_ling	arc_scsi_ling	no
podule0	a448b	arc_a448b	no
podule0	iomidi_aka15	arc_iomidi_aka15	no
podule0	spectra	arc_spectra	no
podule0	a448	arc_a448	no
podule0	midi_aka16	arc_midi_aka16	no
podule0	lbp4	arc_lbp4	no
podule0	rs423	arc_rs423	no
podule0	armadeus	arc_armadeus	no
podule0	rom_aka05	arc_rom_aka05	no
podule1	ua_morley	arc_ua_morley	no
podule1	tube	arc_tube	no
podule1	serial	arc_serial	no
podule1	scsi_aka32	arc_scsi_aka32	no
podule1	scsi_aka31	arc_scsi_aka31	no
podule1	scsi_a500	arc_scsi_a500	no
podule1	scsi_vti	arc_scsi_vti	no
podule1	scanjunior3	arc_scanjunior3	no
podule1	scanjunior	arc_scanjunior	no
podule1	scanlight	arc_scanlight	no
podule1	scan256	arc_scan256	no
podule1	scsi_morley	arc_scsi_morley	no
podule1	greyhawk	arc_greyhawk	no
podule1	rom_r225boot	arc_rom_r225	no
podule1	ether1	arc_ether1_aka25	no
podule1	hdisc_cw	arc_hdisc_cw	no
podule1	faxpack	arc_faxpack	no
podule1	eaglem2	arc_eaglem2	no
podule1	bbcio_aka10	arc_bbcio_aka10	no
podule1	hdisc_akd52	arc_hdisc_akd52	no
podule1	scsi_oak	arc_scsi_oak	no
podule1	scsi_cumana	arc_scsi_cumana	no
podule1	bbcio_we	arc_bbcio_we	no
podule1	etherr	arc_etherr	no
podule1	midi2	arc_midi2	no
podule1	scanvideo	arc_scanvideo	no
podule1	ether2	arc_ether2_aeh50	no
podule1	midi4	arc_midi4	no
podule1	nexus_a500	arc_nexus_a500	no
podule1	hdisc_morley	arc_hdisc_morley	no
podule1	ether3_aeh54	arc_ether3_aeh54	no
podule1	midimax	arc_midimax	no
podule1	hdisc_we	arc_hdisc_we	no
podule1	acejoy	arc_acejoy	no
podule1	ide_be	arc_ide_be	no
podule1	ide_rdev	arc_ide_rdev	no
podule1	lark	arc_lark	no
podule1	midimax2	arc_midimax2	no
podule1	scsi_ling	arc_scsi_ling	no
podule1	a448b	arc_a448b	no
podule1	iomidi_aka15	arc_iomidi_aka15	no
podule1	spectra	arc_spectra	no
podule1	a448	arc_a448	no
podule1	midi_aka16	arc_midi_aka16	no
podule1	lbp4	arc_lbp4	no
podule1	rs423	arc_rs423	no
podule1	armadeus	arc_armadeus	no
podule1	rom_aka05	arc_rom_aka05	no
podule2	ua_morley	arc_ua_morley	no
podule2	tube	arc_tube	no
podule2	serial	arc_serial	no
podule2	scsi_aka32	arc_scsi_aka32	no
podule2	scsi_aka31	arc_scsi_aka31	no
podule2	scsi_a500	arc_scsi_a500	no
podule2	scsi_vti	arc_scsi_vti	no
podule2	scanjunior3	arc_scanjunior3	no
podule2	scanjunior	arc_scanjunior	no
podule2	scanlight	arc_scanlight	no
podule2	scan256	arc_scan256	no
podule2	scsi_morley	arc_scsi_morley	no
podule2	greyhawk	arc_greyhawk	no
podule2	rom_r225boot	arc_rom_r225	no
podule2	ether1	arc_ether1_aka25	no
podule2	hdisc_cw	arc_hdisc_cw	no
podule2	faxpack	arc_faxpack	no
podule2	eaglem2	arc_eaglem2	no
podule2	bbcio_aka10	arc_bbcio_aka10	no
podule2	hdisc_akd52	arc_hdisc_akd52	no
podule2	scsi_oak	arc_scsi_oak	no
podule2	scsi_cumana	arc_scsi_cumana	no
podule2	bbcio_we	arc_bbcio_we	no
podule2	etherr	arc_etherr	no
podule2	midi2	arc_midi2	no
podule2	scanvideo	arc_scanvideo	no
podule2	ether2	arc_ether2_aeh50	no
podule2	midi4	arc_midi4	no
podule2	nexus_a500	arc_nexus_a500	no
podule2	hdisc_morley	arc_hdisc_morley	no
podule2	ether3_aeh54	arc_ether3_aeh54	no
podule2	midimax	arc_midimax	no
podule2	hdisc_we	arc_hdisc_we	no
podule2	acejoy	arc_acejoy	no
podule2	ide_be	arc_ide_be	no
podule2	ide_rdev	arc_ide_rdev	no
podule2	lark	arc_lark	no
podule2	midimax2	arc_midimax2	no
podule2	scsi_ling	arc_scsi_ling	no
podule2	a448b	arc_a448b	no
podule2	iomidi_aka15	arc_iomidi_aka15	no
podule2	spectra	arc_spectra	no
podule2	a448	arc_a448	no
podule2	midi_aka16	arc_midi_aka16	no
podule2	lbp4	arc_lbp4	no
podule2	rs423	arc_rs423	no
podule2	armadeus	arc_armadeus	no
podule2	rom_aka05	arc_rom_aka05	no
podule3	ua_morley	arc_ua_morley	no
podule3	tube	arc_tube	no
podule3	serial	arc_serial	no
podule3	scsi_aka32	arc_scsi_aka32	no
podule3	scsi_aka31	arc_scsi_aka31	no
podule3	scsi_a500	arc_scsi_a500	no
podule3	scsi_vti	arc_scsi_vti	no
podule3	scanjunior3	arc_scanjunior3	no
podule3	scanjunior	arc_scanjunior	no
podule3	scanlight	arc_scanlight	no
podule3	scan256	arc_scan256	no
podule3	scsi_morley	arc_scsi_morley	no
podule3	greyhawk	arc_greyhawk	no
podule3	rom_r225boot	arc_rom_r225	no
podule3	ether1	arc_ether1_aka25	no
podule3	hdisc_cw	arc_hdisc_cw	no
podule3	faxpack	arc_faxpack	no
podule3	eaglem2	arc_eaglem2	no
podule3	bbcio_aka10	arc_bbcio_aka10	no
podule3	hdisc_akd52	arc_hdisc_akd52	no
podule3	scsi_oak	arc_scsi_oak	no
podule3	scsi_cumana	arc_scsi_cumana	no
podule3	bbcio_we	arc_bbcio_we	no
podule3	etherr	arc_etherr	no
podule3	midi2	arc_midi2	no
podule3	scanvideo	arc_scanvideo	no
podule3	ether2	arc_ether2_aeh50	no
podule3	midi4	arc_midi4	no
podule3	nexus_a500	arc_nexus_a500	no
podule3	hdisc_morley	arc_hdisc_morley	no
podule3	ether3_aeh54	arc_ether3_aeh54	no
podule3	midimax	arc_midimax	no
podule3	hdisc_we	arc_hdisc_we	no
podule3	acejoy	arc_acejoy	no
podule3	ide_be	arc_ide_be	no
podule3	ide_rdev	arc_ide_rdev	no
podule3	lark	arc_lark	no
podule3	midimax2	arc_midimax2	no
podule3	scsi_ling	arc_scsi_ling	no
podule3	a448b	arc_a448b	no
podule3	iomidi_aka15	arc_iomidi_aka15	no
podule3	spectra	arc_spectra	no
podule3	a448	arc_a448	no
podule3	midi_aka16	arc_midi_aka16	no
podule3	lbp4	arc_lbp4	no
podule3	rs423	arc_rs423	no
podule3	armadeus	arc_armadeus	no
podule3	rom_aka05	arc_rom_aka05	no
