beatmania 3rd MIX (ver JA-B) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
bm3rdmix	konami/djmain.cpp		no	no	no	yes	beatmania 3rd MIX (ver JA-B)	1998	Konami

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	488	384	57.996230	16000000	660	12	500	418	0	384	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
825_b01.6a	524288	934fdcb2	b88bada065b5464c579039c2e403c061e6eeb356	maincpu	0	good	no
825_b02.8a	524288	6012c488	df32db41942c2fe2b2aa7439900372e22ea54c3c	maincpu	1	good	no
825_a03.19a	524288	ecd62652	bceab4052dce2c843358f0a98aacc6e1124e3068	gfx1	0	good	no
825_a04.20a	524288	437a576f	f30fd15d4f0d776e9b29ccfcd6e26861fb42e51a	gfx1	1	good	no
825_a05.22a	524288	9f9a3369	d8b20127336af89b9e886289fb4f5a2e0db65f9b	gfx1	100000	good	no
825_a06.24a	524288	e7a3991a	6c8cb481e721428e1365f784e97bb6f6d421ed5a	gfx1	100001	good	no
825_b07.22d	524288	1a515c82	a0c908d449aa45cb3a90a42c97429f10873e884b	k056832	0	good	no
825_b08.23d	524288	82731b07	c0d391fcd94c6b2225fca338c0c5db5d35e2d8bc	k056832	1	good	no
825_b09.25d	524288	1407ba5d	e7a0d190326589f4d94e83cb7c85dd4e91f4efad	k056832	100000	good	no
825_b10.27d	524288	2afd0a10	1b8b868ac5720bb1b376f4eb8952efb190257bda	k056832	100001	good	no

disk

name	merge	sha1	region	index	writable	status	optional
825jab11		f506a83d43aeed87a7a32c3f7312d2a2b7d60d91	ata:0:hdd	0	yes	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68EC020	16000000
audio	speaker	Speaker
audio	k054539_1	Konami 054539 ADPCM	18432000
audio	k054539_2	Konami 054539 ADPCM	18432000

device_ref

name
m68ec020
ata_interface
ata_slot
idehd
harddisk_image
ata_slot
screen
palette
gfxdecode
k056832
k055555
speaker
k054539
k054539

sound

channels
1

feature

type	status	overall
sound		imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	ata:0:hdd:image	ide_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	ata:0:hdd:image	ide_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
2	1	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
dial	1	5		no	0	255	30	15
dial	2	5		no	0	255	30	15

port, analog

port_tag	analog_masks
:BTN1
:BTN2
:BTN3
:DSW1
:DSW2
:DSW3
:TT1	255
:TT2	255
:UNK1
:UNK2

dipswitch

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	31

location

name	number	inverted
SW1	8	no
SW1	7	no
SW1	6	no
SW1	5	no
SW1	4	no

value

name	value	default
1P 8C / 2P 16C / Continue 8C	0	no
1P 8C / 2P 16C / Continue 7C	1	no
1P 8C / 2P 16C / Continue 6C	2	no
1P 7C / 2P 14C / Continue 7C	3	no
1P 7C / 2P 14C / Continue 6C	4	no
1P 7C / 2P 14C / Continue 5C	5	no
1P 6C / 2P 12C / Continue 6C	6	no
1P 6C / 2P 12C / Continue 5C	7	no
1P 6C / 2P 12C / Continue 4C	8	no
1P 5C / 2P 10C / Continue 5C	9	no
1P 5C / 2P 10C / Continue 3C	11	no
1P 5C / 2P 10C / Continue 4C	10	no
1P 4C / 2P 8C / Continue 4C	12	no
1P 4C / 2P 8C / Continue 3C	13	no
1P 4C / 2P 8C / Continue 2C	14	no
1P 3C / 2P 6C / Continue 3C	15	no
1P 3C / 2P 6C / Continue 2C	16	no
1P 3C / 2P 6C / Continue 1C	17	no
1P 3C / 2P 4C / Continue 3C	18	no
1P 3C / 2P 4C / Continue 2C	19	no
1P 3C / 2P 4C / Continue 1C	20	no
1P 3C / 2P 3C / Continue 3C	21	no
1P 3C / 2P 3C / Continue 2C	22	no
1P 3C / 2P 3C / Continue 1C	23	no
1P 2C / 2P 3C / Continue 2C	26	no
1P 2C / 2P 3C / Continue 1C	27	no
1P 2C / 2P 4C / Continue 2C	24	no
1P 2C / 2P 4C / Continue 1C	31	yes
1P 2C / 2P 2C / Continue 2C	28	no
1P 2C / 2P 2C / Continue 1C	29	no
1P 1C / 2P 2C / Continue 1C	30	no
1P 1C / 2P 1C / Continue 1C	25	no

Free Play (Ignore Coinage)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play (Ignore Coinage)	DSW1	32

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	64

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	128

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	15

location

name	number	inverted
SW2	8	no
SW2	7	no
SW2	6	no
SW2	5	no

value

name	value	default
Level 0	10	no
Level 1	14	no
Level 2	13	no
Level 3	12	no
Level 4	11	no
Level 5	15	yes
Level 6	9	no
Level 7	8	no
Level 8	7	no
Level 9	6	no
Level 10	5	no
Level 11	4	no
Level 12	3	no
Level 13	2	no
Level 14	1	no
Level 15	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	16

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	96

location

name	number	inverted
SW2	3	no
SW2	2	no

value

name	value	default
Loud	96	yes
Medium	32	no
Low	64	no
Silent	0	no

Score Display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Score Display	DSW2	128

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	1

location

name	number	inverted
SW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	2

location

name	number	inverted
SW3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Event Mode Stages

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Event Mode Stages	DSW3	28	DSW3	32	ne	32

location

name	number	inverted
SW3	4	no
SW3	3	no
SW3	2	no

value

name	value	default
1 Stage	12	no
2 Stages	20	no
3 Stages	16	no
4 Stages	28	yes
4 Stages	4	no
4 Stages	24	no
4 Stages	0	no
5 Stages	8	no

Normal Mode Stages

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Normal Mode Stages	DSW3	28	DSW3	32	eq	32

location

name	number	inverted
SW3	4	no
SW3	3	no
SW3	2	no

value

name	value	default
3 Stages	16	no
4 Stages	28	yes
4 Stages	12	no
4 Stages	20	no
4 Stages	4	no
4 Stages	24	no
4 Stages	0	no
5 Stages	8	no

Event Mode (Ignore Coinage)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Event Mode (Ignore Coinage)	DSW3	32

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no
