EC-1840 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
ec1840	pc/ec184x.cpp		no	no	no	yes	EC-1840	1986	<unknown>	ibm5150	ibm5150

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
isa1:ec1840.0002:mda_screen	raster	0	640	350	55.477068	16257000	792	0	640	370	0	350	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
000-01.bin	2048	c3ab1fad	8168bdee30698f4f9aa7bbb6dfabe62dd723cec5	bios	e000	good	no	v1
001-01.bin	2048	601d1155	9684d33b92743749704587a48e679ef7a3b20f9c	bios	f000	good	no	v1
002-01.bin	2048	ce4dddb7	f9b1da60c848e68ff1c154d695a36a0833de4804	bios	e001	good	no	v1
003-01.bin	2048	14b40431	ce7fffa41897405ee64fd4e86015e774f8bd108a	bios	f001	good	no	v1
000-04-971b.bin	2048	06aeaee8	9f954e4c48156d573a8e0109e7ca652be9e6036a	bios	e000	good	no	v4
001-04-92b7.bin	2048	3fae650a	c98b777fdeceadd72d6eb9465b3501b9ead55a08	bios	f000	good	no	v4
002-04-9e17.bin	2048	d59712df	02ea1b3ae9662f5c64c58920a32ca9db0f6fbd12	bios	e001	good	no	v4
003-04-3ccb.bin	2048	7fc362c7	538e13639ad2b4c30bd72582e323181e63513306	bios	f001	good	no	v4

chip

type	tag	name	clock
cpu	maincpu	Intel 8086	4096000
cpu	mb:dma8237	AM9517A	4772727
cpu	kbd:ec1841:i8048	Intel 8048	5460000
audio	mb:mono	Speaker
audio	mb:speaker	Filtered DAC
audio	isa2:ec1840.0003:fdc:0:525dd:flopsndout	Speaker
audio	isa2:ec1840.0003:fdc:0:525dd:floppysound	Floppy sound	44100
audio	isa2:ec1840.0003:fdc:1:525dd:flopsndout	Speaker
audio	isa2:ec1840.0003:fdc:1:525dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
flop_list	ec1841	original

device_ref

name
i8086
ec1840_mb
pit8253
pit_counter
pit_counter
pit_counter
am9517a
pic8259
i8255
isa8
speaker
speaker_sound_device
isa8_slot
ec1840_0002
screen
palette
mc6845
isa8_slot
isa8_fdc_xt
upd765a
floppy_connector
floppy_525_dd
speaker
flopsnd
floppy_connector
floppy_525_dd
speaker
flopsnd
isa8_slot
isa_lpt
pc_lpt
centronics
centronics_printer
printer_image
input_buffer
input_buffer
input_buffer
output_latch
output_latch
isa8_slot
isa8_slot
software_list
pc_kbdc
kb_ec1841
i8048
ram

biosset

name	description	default
v1	EC-1840.01	no
v4	EC-1840.04	yes

sound

channels
3

ramoption

name	default
128K
256K
384K
512K
640K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	isa2:ec1840.0003:fdc:0:525dd	floppy_5_25	floppydisk1	flop1
floppydisk	isa2:ec1840.0003:fdc:1:525dd	floppy_5_25	floppydisk2	flop2
printout	isa3:ec1840.0004:lpt:centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
floppydisk	isa2:ec1840.0003:fdc:0:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf
floppydisk	isa2:ec1840.0003:fdc:1:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf
printout	isa3:ec1840.0004:lpt:centronics:printer:printer		prn

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		92		no

port, analog

port_tag	analog_masks
:isa3:ec1840.0004:DSW
:kbd:ec1841:MD00
:kbd:ec1841:MD01
:kbd:ec1841:MD02
:kbd:ec1841:MD03
:kbd:ec1841:MD04
:kbd:ec1841:MD05
:kbd:ec1841:MD06
:kbd:ec1841:MD07
:kbd:ec1841:MD08
:kbd:ec1841:MD09
:kbd:ec1841:MD10
:kbd:ec1841:MD11
:kbd:ec1841:MD12
:kbd:ec1841:MD13
:kbd:ec1841:MD14
:kbd:ec1841:MD15
:mb:DSW0
:mb:SA2

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
isa1	pccom	isa_com	no
isa1	ec1841.0003	isa8_ec1841_0003	no
isa1	hdc	isa_hdc_ec1841	no
isa1	ec1841.0002	ec1841_0002	no
isa1	xtide	xtide	no
isa1	ec1840.0004	isa_lpt	no
isa1	mda	isa_ibm_mda	no
isa1	ec1840.0003	isa8_fdc_xt	no
isa1	ec1840.0002	ec1840_0002	yes
isa2	pccom	isa_com	no
isa2	ec1841.0003	isa8_ec1841_0003	no
isa2	hdc	isa_hdc_ec1841	no
isa2	ec1841.0002	ec1841_0002	no
isa2	xtide	xtide	no
isa2	ec1840.0004	isa_lpt	no
isa2	mda	isa_ibm_mda	no
isa2	ec1840.0003	isa8_fdc_xt	yes
isa2	ec1840.0002	ec1840_0002	no
isa2:ec1840.0003:fdc:0	35dd	floppy_35_dd	no
isa2:ec1840.0003:fdc:0	525dd	floppy_525_dd	yes
isa2:ec1840.0003:fdc:1	35dd	floppy_35_dd	no
isa2:ec1840.0003:fdc:1	525dd	floppy_525_dd	yes
isa3	pccom	isa_com	no
isa3	ec1841.0003	isa8_ec1841_0003	no
isa3	hdc	isa_hdc_ec1841	no
isa3	ec1841.0002	ec1841_0002	no
isa3	xtide	xtide	no
isa3	ec1840.0004	isa_lpt	yes
isa3	mda	isa_ibm_mda	no
isa3	ec1840.0003	isa8_fdc_xt	no
isa3	ec1840.0002	ec1840_0002	no
isa3:ec1840.0004:lpt:centronics	nlq401	nlq401	no
isa3:ec1840.0004:lpt:centronics	smartboard	centronics_smartboard	no
isa3:ec1840.0004:lpt:centronics	chessmec	centronics_chessmec	no
isa3:ec1840.0004:lpt:centronics	samdac	centronics_samdac	no
isa3:ec1840.0004:lpt:centronics	covox_stereo	covox_stereo	no
isa3:ec1840.0004:lpt:centronics	adaptator	adaptator_multitap	no
isa3:ec1840.0004:lpt:centronics	digiblst	cpcdigiblst	no
isa3:ec1840.0004:lpt:centronics	lx800	lx800	no
isa3:ec1840.0004:lpt:centronics	jx80	epson_jx80	no
isa3:ec1840.0004:lpt:centronics	ap2000	ap2000	no
isa3:ec1840.0004:lpt:centronics	ex800	ex800	no
isa3:ec1840.0004:lpt:centronics	fx80	epson_fx80	no
isa3:ec1840.0004:lpt:centronics	rx80	epson_rx80	no
isa3:ec1840.0004:lpt:centronics	covox	covox	no
isa3:ec1840.0004:lpt:centronics	pl80	comx_pl80	no
isa3:ec1840.0004:lpt:centronics	lx810l	lx810l	no
isa3:ec1840.0004:lpt:centronics	p72	p72	no
isa3:ec1840.0004:lpt:centronics	printer	centronics_printer	yes
isa4	pccom	isa_com	no
isa4	ec1841.0003	isa8_ec1841_0003	no
isa4	hdc	isa_hdc_ec1841	no
isa4	ec1841.0002	ec1841_0002	no
isa4	xtide	xtide	no
isa4	ec1840.0004	isa_lpt	no
isa4	mda	isa_ibm_mda	no
isa4	ec1840.0003	isa8_fdc_xt	no
isa4	ec1840.0002	ec1840_0002	no
isa5	pccom	isa_com	no
isa5	ec1841.0003	isa8_ec1841_0003	no
isa5	hdc	isa_hdc_ec1841	no
isa5	ec1841.0002	ec1841_0002	no
isa5	xtide	xtide	no
isa5	ec1840.0004	isa_lpt	no
isa5	mda	isa_ibm_mda	no
isa5	ec1840.0003	isa8_fdc_xt	no
isa5	ec1840.0002	ec1840_0002	no
kbd	iskr1030	kb_iskr1030	no
kbd	ec1841	kb_ec1841	yes
kbd	pcxt	kb_pcxt83	no
kbd	pc	kb_pc83	no
kbd	keytronc_pc3270	keytronic_pc3270	no

dipswitch

Base address

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Base address	isa3:ec1840.0004:DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0x378	0	yes
0x278	1	no

Boot from floppy

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot from floppy	mb:DSW0	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

DMAC installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DMAC installed	mb:DSW0	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	2	yes

Graphics adapter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphics adapter	mb:DSW0	48

value

name	value	default
Reserved	0	no
Color 40x25	16	no
Color 80x25	32	no
Monochrome	48	yes

Number of floppy drives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number of floppy drives	mb:DSW0	192

value

name	value	default
1	0	no
2	64	yes
3	128	no
4	192	no

SA2.4

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
SA2.4	mb:SA2	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	16	yes

SA2.5

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
SA2.5	mb:SA2	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	32	yes
