Video Genie EG3003 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
eg3003	trs/trs80.cpp		no	no	no	yes	Video Genie EG3003	1980	EACA Computers Ltd

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	192	60.000113	10644500	672	0	384	264	0	192	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
3001.z10	4096	8f5214de	d8c052be5a2d0ec74433043684791d0554bf203b	maincpu	0	good	no
3002.z11	4096	46e88fbf	a3ca32757f269e09316e1e91ba1502774e2f5155	maincpu	1000	good	no
3003.z12	4096	306e5d66	1e1abcfb5b02d4567cf6a81ffc35318723442369	maincpu	2000	good	no
tcs-ext.z13	2048	8f2ac112	be0c2a5fb9cb01173c4da6dc8c71ca5975f441bb	maincpu	3000	good	no
tcs-ext.z25	2048	150c5f1f	afbce73ab0360108b32e75eb75a3966eb5c503e7	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	1774083
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	cassette	Cassette
audio	floppy0:80t_qd:flopsndout	Speaker
audio	floppy0:80t_qd:floppysound	Floppy sound	44100
audio	floppy1:80t_qd:flopsndout	Speaker
audio	floppy1:80t_qd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
cass_list	trs80_cass	original	1
quik_list	trs80_quik	original	1
flop_list	trs80_flop	original	1

device_ref

name
z80
ipt_merge_any_hi
screen
gfxdecode
palette
speaker
speaker_sound_device
cassette_image
software_list
trs80_quickload
fd1771
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_connector
centronics
centronics_printer
printer_image
input_buffer
output_latch
ay31015
rs232
software_list
software_list
clock

sound

channels
3

device, instance

type	tag	interface	name	briefname
cassette	cassette	trs80_cass	cassette	cass
quickload	quickload	trs80_quik	quickload	quik
floppydisk	floppy0:80t_qd	floppy_5_25	floppydisk1	flop1
floppydisk	floppy1:80t_qd	floppy_5_25	floppydisk2	flop2
printout	centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
cassette	cassette	trs80_cass	wav, flac, cas
quickload	quickload	trs80_quik	cmd
floppydisk	floppy0:80t_qd	floppy_5_25	mfi, dfi, dmk, jv1, dsk
floppydisk	floppy1:80t_qd	floppy_5_25	mfi, dfi, dmk, jv1, dsk
printout	centronics:printer:printer		prn

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		58		no

port, analog

port_tag	analog_masks
:BAUD
:CONFIG
:E9
:LINE0
:LINE1
:LINE2
:LINE3
:LINE4
:LINE5
:LINE6
:LINE7
:RESET

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
floppy0	80t_qd	floppy_525_qd	yes
floppy0	40t_dd	floppy_525_dd	no
floppy0	40t_sd	floppy_525_sssd	no
floppy0	35t_sd	floppy_525_sssd_35t	no
floppy1	80t_qd	floppy_525_qd	yes
floppy1	40t_dd	floppy_525_dd	no
floppy1	40t_sd	floppy_525_sssd	no
floppy1	35t_sd	floppy_525_sssd_35t	no
floppy2	80t_qd	floppy_525_qd	no
floppy2	40t_dd	floppy_525_dd	no
floppy2	40t_sd	floppy_525_sssd	no
floppy2	35t_sd	floppy_525_sssd_35t	no
floppy3	80t_qd	floppy_525_qd	no
floppy3	40t_dd	floppy_525_dd	no
floppy3	40t_sd	floppy_525_sssd	no
floppy3	35t_sd	floppy_525_sssd_35t	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no

configuration

Video Cut

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Video Cut	CONFIG	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Floppy Disc Drives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Floppy Disc Drives	CONFIG	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

dipswitch

Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Baud Rate	BAUD	255

value

name	value	default
110	0	no
300	1	no
600	2	no
1200	3	no
2400	4	no
4800	5	no
9600	6	yes
19200	7	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	E9	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	16	yes
1	0	no

Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bits	E9	96

value

name	value	default
5	0	no
6	32	no
7	64	no
8	96	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	E9	136

value

name	value	default
None	8	yes
Odd	0	no
Even	128	no
