Duty Free (Barcrest) (MPU4) (DUT 0.4)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
m4dtyfre	barcrest/mpu4mod4oki.cpp		no	no	yes	yes	Duty Free (Barcrest) (MPU4) (DUT 0.4)	1993	Barcrest

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
duts.p1	65536	8c7d6567	8e82c4168d4d455c7cb95a895c04f7ad327894ec	maincpu	0	good	no
dutsnd.p1	524288	a5829cec	eb65c86125350a7f384f9033f6a217284b6ff3d1	okicard:msm6376	0	good	no
dutsnd.p2	524288	1e5d8407	64ee6eba3fb7700a06b89a1e0489a0cd54bb89fd	okicard:msm6376	80000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	6880000
audio	mono	Speaker
audio	alarmdac	1-Bit DAC
audio	okicard	Barcrest Sampled Sound Program Card	1720000
audio	okicard:msm6376	OKI MSM6376 ADPCM	128000

device_ref

tag	name
:maincpu	mc6809
:50hz	timer
:vfd	msc1937
:ptm_ic2	ptm6840
:pia_ic3	pia6821
:pia_ic4	pia6821
:pia_ic5	pia6821
:pia_ic6	pia6821
:pia_ic7	pia6821
:pia_ic8	pia6821
:meters	meters
:dataport	bacta_datalogger
:hopper	coin_hopper
:mono	speaker
:alarmdac	dac
:nvram	nvram
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:okicard	mpu4okisnd
:okicard:ptm_ic3ss	ptm6840
:okicard:pia_ic4ss	pia6821
:okicard:msm6376	okim6376
:characteriser	mpu4chrpal
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper

sound

channels
1

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		7		no

port, analog

port_tag	analog_masks
:AUX1
:AUX2
:BLACK1
:BLACK2
:DIL1
:DIL2
:ORANGE1
:ORANGE2
:hopper:TEST

configuration

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	ORANGE1	224

setting

name	value	default
Not fitted / 5p	0	yes
10p	32	no
20p	64	no
25p	96	no
30p	128	no
40p	160	no
50p	192	no
1 GBP	224	no

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	ORANGE2	15

setting

name	value	default
Not fitted	0	yes
3 GBP	1	no
4 GBP	2	no
5 GBP	8	no
6 GBP	3	no
6 GBP Token	4	no
8 GBP	5	no
8 GBP Token	6	no
10 GBP	7	no
15 GBP	9	no
25 GBP	10	no
25 GBP (Licensed Betting Office Profile)	11	no
35 GBP	12	no
70 GBP	13	no
Reserved	14	no
Reserved	15	no

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	ORANGE2	240

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	1

location

name	number	inverted
DIL1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	2

location

name	number	inverted
DIL1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	4

location

name	number	inverted
DIL1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	8

location

name	number	inverted
DIL1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Target Percentage (if key not fitted)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Target Percentage (if key not fitted)	DIL1	240

location

name	number	inverted
DIL1	5	no
DIL1	6	no
DIL1	7	no
DIL1	8	no

value

name	value	default
Unset (Program Optimum)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

Token Lockout when full

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Lockout when full	DIL2	1

location

name	number	inverted
DIL2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL2	2

location

name	number	inverted
DIL2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Scottish Coin Handling

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Scottish Coin Handling	DIL2	4

location

name	number	inverted
DIL2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Out of Credit Display Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Out of Credit Display Inhibit	DIL2	8

location

name	number	inverted
DIL2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

OCD Audio Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
OCD Audio Enable	DIL2	16

location

name	number	inverted
DIL2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Coin Alarm Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Alarm Inhibit	DIL2	32

location

name	number	inverted
DIL2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Token Refill Level Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Refill Level Inhibit	DIL2	64

location

name	number	inverted
DIL2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Single Credit Entry

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Single Credit Entry	DIL2	128

location

name	number	inverted
DIL2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

clones

name	description
m4dtyfref5ad	Duty Free (Barcrest) (MPU4) (DF5 0.3 AD)
m4dtyfref5b	Duty Free (Barcrest) (MPU4) (DF5 0.3 B)
m4dtyfref5bd	Duty Free (Barcrest) (MPU4) (DF5 0.3 BD)
m4dtyfref5d	Duty Free (Barcrest) (MPU4) (DF5 0.3 D)
m4dtyfref5k	Duty Free (Barcrest) (MPU4) (DF5 0.3 K)
m4dtyfref5kd	Duty Free (Barcrest) (MPU4) (DF5 0.3 KD)
m4dtyfref5r	Duty Free (Barcrest) (MPU4) (DF5 0.3 R)
m4dtyfref5rd	Duty Free (Barcrest) (MPU4) (DF5 0.3 RD)
m4dtyfref5y	Duty Free (Barcrest) (MPU4) (DF5 0.3 Y)
m4dtyfref5yd	Duty Free (Barcrest) (MPU4) (DF5 0.3 YD)
m4dtyfref5	Duty Free (Barcrest) (MPU4) (DF5 0.3)
m4dtyfref8c	Duty Free (Barcrest) (MPU4) (DF8 0.1 C)
m4dtyfref8d	Duty Free (Barcrest) (MPU4) (DF8 0.1 D)
m4dtyfref8k	Duty Free (Barcrest) (MPU4) (DF8 0.1 K)
m4dtyfref8y	Duty Free (Barcrest) (MPU4) (DF8 0.1 Y)
m4dtyfref8yd	Duty Free (Barcrest) (MPU4) (DF8 0.1 YD)
m4dtyfref8	Duty Free (Barcrest) (MPU4) (DF8 0.1)
m4dtyfreftad	Duty Free (Barcrest) (MPU4) (DFT 0.1 AD)
m4dtyfreftb	Duty Free (Barcrest) (MPU4) (DFT 0.1 B)
m4dtyfreftbd	Duty Free (Barcrest) (MPU4) (DFT 0.1 BD)
m4dtyfreftd	Duty Free (Barcrest) (MPU4) (DFT 0.1 D)
m4dtyfreftk	Duty Free (Barcrest) (MPU4) (DFT 0.1 K)
m4dtyfreftkd	Duty Free (Barcrest) (MPU4) (DFT 0.1 KD)
m4dtyfrefty	Duty Free (Barcrest) (MPU4) (DFT 0.1 Y)
m4dtyfreftyd	Duty Free (Barcrest) (MPU4) (DFT 0.1 YD)
m4dtyfreft	Duty Free (Barcrest) (MPU4) (DFT 0.1)
m4dtyfre_h2	Duty Free (Barcrest) (MPU4) (DFT 0.1, hack?)
m4dtyfreutb	Duty Free (Barcrest) (MPU4) (DUT 0.4 B)
m4dtyfreutc	Duty Free (Barcrest) (MPU4) (DUT 0.4 C)
m4dtyfrexd_a	Duty Free (Barcrest) (MPU4) (XD5 0.1)
m4dtyfrexdad	Duty Free (Barcrest) (MPU4) (XD5 0.2 AD)
m4dtyfrexdb	Duty Free (Barcrest) (MPU4) (XD5 0.2 B)
m4dtyfrexdbd	Duty Free (Barcrest) (MPU4) (XD5 0.2 BD)
m4dtyfrexdc	Duty Free (Barcrest) (MPU4) (XD5 0.2 C)
m4dtyfrexdd	Duty Free (Barcrest) (MPU4) (XD5 0.2 D)
m4dtyfrexdk	Duty Free (Barcrest) (MPU4) (XD5 0.2 K)
m4dtyfrexdkd	Duty Free (Barcrest) (MPU4) (XD5 0.2 KD)
m4dtyfrexdr	Duty Free (Barcrest) (MPU4) (XD5 0.2 R)
m4dtyfrexdrd	Duty Free (Barcrest) (MPU4) (XD5 0.2 RD)
m4dtyfrexdy	Duty Free (Barcrest) (MPU4) (XD5 0.2 Y)
m4dtyfrexdyd	Duty Free (Barcrest) (MPU4) (XD5 0.2 YD)
m4dtyfrexd	Duty Free (Barcrest) (MPU4) (XD5 0.2)
m4dtyfrexfad	Duty Free (Barcrest) (MPU4) (XFT 0.1 AD)
m4dtyfrexfb	Duty Free (Barcrest) (MPU4) (XFT 0.1 B)
m4dtyfrexfbd	Duty Free (Barcrest) (MPU4) (XFT 0.1 BD)
m4dtyfrexfc	Duty Free (Barcrest) (MPU4) (XFT 0.1 C)
m4dtyfrexfd	Duty Free (Barcrest) (MPU4) (XFT 0.1 D)
m4dtyfrexfk	Duty Free (Barcrest) (MPU4) (XFT 0.1 K)
m4dtyfrexfkd	Duty Free (Barcrest) (MPU4) (XFT 0.1 KD)
m4dtyfrexfr	Duty Free (Barcrest) (MPU4) (XFT 0.1 R)
m4dtyfrexfrd	Duty Free (Barcrest) (MPU4) (XFT 0.1 RD)
m4dtyfrexfy	Duty Free (Barcrest) (MPU4) (XFT 0.1 Y)
m4dtyfrexfyd	Duty Free (Barcrest) (MPU4) (XFT 0.1 YD)
m4dtyfrexf	Duty Free (Barcrest) (MPU4) (XFT 0.1)
m4dtyfrebwb	Duty Free (BWB / Barcrest) (MPU4) (DF10 4.3, set 1)
m4dtyfrebwb_a	Duty Free (BWB / Barcrest) (MPU4) (DF10 4.3, set 2)
m4dtyfrebwb_g	Duty Free (BWB / Barcrest) (MPU4) (DF4 1.1)
m4dtyfrebwb_f	Duty Free (BWB / Barcrest) (MPU4) (DF4 2.1)
m4dtyfrebwb_e	Duty Free (BWB / Barcrest) (MPU4) (DF4 4.1)
m4dtyfre_h1	Duty Free (BWB / Barcrest) (MPU4) (DF4 4.1, hack?)
m4dtyfrebwb_c	Duty Free (BWB / Barcrest) (MPU4) (DF8 2.2, set 1)
m4dtyfrebwb_d	Duty Free (BWB / Barcrest) (MPU4) (DF8 2.2, set 2)
m4dtyfrebwb_b	Duty Free (BWB / Barcrest) (MPU4) (DF8 4.2)
m4dtyfrebwb_h	Duty Free (BWB / Barcrest) (MPU4) (DFC 2.3)
