Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
m4jwlcwn	barcrest/mpu4mod4oki.cpp		no	no	yes	yes	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0)	199?	Barcrest

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
cje10s.p1	131072	5f3b72b7	8faf0de0282a67c88170c13856b8816c38396e19	maincpu	0	good	no
cjesnd.p1	524288	a2f20c95	874b22850732514a26448cee8e0b68f8d042a7c7	okicard:msm6376	0	good	no
cjesnd.p2	524288	3dcb7c38	3c0e91f4d2ea9e6b25a01702c6f6fdc7cc2e0b65	okicard:msm6376	80000	good	no
jewelp2	524288	84996453	74fe377545503f1b8da9b8998514811f0c1c037c	okicard:msm6376	80000	good	no
cjhsnd.p1	524288	4add4eca	98dc644d3f3d67e764c215bd26ae010e4b23c738	okicard:msm6376	0	good	no
cjhsnd.p2	524288	5eec51f0	834d9d13f79a61c51db9df067064f64a15c956a9	okicard:msm6376	80000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	6880000
audio	mono	Speaker
audio	alarmdac	1-Bit DAC
audio	okicard	Barcrest Sampled Sound Program Card	1720000
audio	okicard:msm6376	OKI MSM6376 ADPCM	128000

device_ref

tag	name
:maincpu	mc6809
:50hz	timer
:vfd	msc1937
:ptm_ic2	ptm6840
:pia_ic3	pia6821
:pia_ic4	pia6821
:pia_ic5	pia6821
:pia_ic6	pia6821
:pia_ic7	pia6821
:pia_ic8	pia6821
:meters	meters
:dataport	bacta_datalogger
:hopper	coin_hopper
:mono	speaker
:alarmdac	dac
:nvram	nvram
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:okicard	mpu4okisnd
:okicard:ptm_ic3ss	ptm6840
:okicard:pia_ic4ss	pia6821
:okicard:msm6376	okim6376
:characteriser	mpu4chrpal
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper

sound

channels
1

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		7		no

port, analog

port_tag	analog_masks
:AUX1
:AUX2
:BLACK1
:BLACK2
:DIL1
:DIL2
:ORANGE1
:ORANGE2
:hopper:TEST

configuration

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	ORANGE1	224

setting

name	value	default
Not fitted / 5p	0	yes
10p	32	no
20p	64	no
25p	96	no
30p	128	no
40p	160	no
50p	192	no
1 GBP	224	no

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	ORANGE2	15

setting

name	value	default
Not fitted	0	no
3 GBP	1	no
4 GBP	2	no
5 GBP	8	no
6 GBP	3	no
6 GBP Token	4	no
8 GBP	5	no
8 GBP Token	6	yes
10 GBP	7	no
15 GBP	9	no
25 GBP	10	no
25 GBP (Licensed Betting Office Profile)	11	no
35 GBP	12	no
70 GBP	13	no
Reserved	14	no
Reserved	15	no

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	ORANGE2	240

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	1

location

name	number	inverted
DIL1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	2

location

name	number	inverted
DIL1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	4

location

name	number	inverted
DIL1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	8

location

name	number	inverted
DIL1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Target Percentage (if key not fitted)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Target Percentage (if key not fitted)	DIL1	240

location

name	number	inverted
DIL1	5	no
DIL1	6	no
DIL1	7	no
DIL1	8	no

value

name	value	default
Unset (Program Optimum)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

Token Lockout when full

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Lockout when full	DIL2	1

location

name	number	inverted
DIL2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL2	2

location

name	number	inverted
DIL2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Scottish Coin Handling

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Scottish Coin Handling	DIL2	4

location

name	number	inverted
DIL2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Out of Credit Display Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Out of Credit Display Inhibit	DIL2	8

location

name	number	inverted
DIL2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

OCD Audio Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
OCD Audio Enable	DIL2	16

location

name	number	inverted
DIL2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Coin Alarm Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Alarm Inhibit	DIL2	32

location

name	number	inverted
DIL2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Token Refill Level Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Refill Level Inhibit	DIL2	64

location

name	number	inverted
DIL2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Single Credit Entry

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Single Credit Entry	DIL2	128

location

name	number	inverted
DIL2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

clones

name	description
m4jwlcwn__k	Jewel In the Crown (Barcrest) (MPU4) (CJE 0.8 Y)
m4jwlcwn__a	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 AD)
m4jwlcwn__b	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 B)
m4jwlcwn__c	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 BD)
m4jwlcwn__d	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 C)
m4jwlcwn__z	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 C, hack)
m4jwlcwn__e	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 D)
m4jwlcwn__i	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 K)
m4jwlcwn__f	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 KD)
m4jwlcwn__j	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 R)
m4jwlcwn__g	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 RD)
m4jwlcwn__l	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 Y)
m4jwlcwn__h	Jewel In the Crown (Barcrest) (MPU4) (CJE 1.0 YD)
m4jwlcwn__0	Jewel In the Crown (Barcrest) (MPU4) (CJH 0.8)
m4jwlcwn__m	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 AD)
m4jwlcwn__n	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 B)
m4jwlcwn__o	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 BD)
m4jwlcwn__p	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 C)
m4jwlcwn__y	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 C, hack)
m4jwlcwn__q	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 D)
m4jwlcwn__u	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 K)
m4jwlcwn__r	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 KD)
m4jwlcwn__v	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 R)
m4jwlcwn__s	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 RD)
m4jwlcwn__x	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 Y)
m4jwlcwn__t	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0 YD)
m4jwlcwn__w	Jewel In the Crown (Barcrest) (MPU4) (CJH 1.0)
m4jwlcwn__3	Jewel In the Crown (Barcrest) (MPU4) (JC4 3.1 K)
m4jwlcwn__4	Jewel In the Crown (Barcrest) (MPU4) (JC5 1.9 K)
m4jwlcwn__5	Jewel In the Crown (Barcrest) (MPU4) (JC8 4.2 K)
m4jwlcwn__1	Jewel In the Crown (Barcrest) (MPU4) (JC8 4.4)
m4jwlcwn__2	Jewel In the Crown (Barcrest) (MPU4) (JCC 3.3)
m4jwlcwn__6	Jewel In the Crown (Barcrest) (MPU4) (JCC 3.7)
