Pot Black (Barcrest) (MPU4) (PBG 1.6)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
m4potblk	barcrest/mpu4mod4oki.cpp		no	no	yes	yes	Pot Black (Barcrest) (MPU4) (PBG 1.6)	199?	Barcrest

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
pbg16s.p1	131072	36a1c679	bf2eb5c2a07e61b7a2c0d8402b0e0583adfa22dc	maincpu	0	good	no
pbsnd1.hex	524288	72a3331d	b7475ba0ad86a6277e3d4f7b4311a98f3fc29802	okicard:msm6376	0	good	no
pbsnd2.hex	524288	c2460eec	7c62fbc69ffaa788bf3839e37a75a812a7b8caef	okicard:msm6376	80000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	6880000
audio	mono	Speaker
audio	alarmdac	1-Bit DAC
audio	okicard	Barcrest Sampled Sound Program Card	1720000
audio	okicard:msm6376	OKI MSM6376 ADPCM	128000

device_ref

tag	name
:maincpu	mc6809
:50hz	timer
:vfd	msc1937
:ptm_ic2	ptm6840
:pia_ic3	pia6821
:pia_ic4	pia6821
:pia_ic5	pia6821
:pia_ic6	pia6821
:pia_ic7	pia6821
:pia_ic8	pia6821
:meters	meters
:dataport	bacta_datalogger
:hopper	coin_hopper
:mono	speaker
:alarmdac	dac
:nvram	nvram
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:okicard	mpu4okisnd
:okicard:ptm_ic3ss	ptm6840
:okicard:pia_ic4ss	pia6821
:okicard:msm6376	okim6376
:characteriser	mpu4chrpal
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper

sound

channels
1

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		7		no

port, analog

port_tag	analog_masks
:AUX1
:AUX2
:BLACK1
:BLACK2
:DIL1
:DIL2
:ORANGE1
:ORANGE2
:hopper:TEST

configuration

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	ORANGE1	224

setting

name	value	default
Not fitted / 5p	0	yes
10p	32	no
20p	64	no
25p	96	no
30p	128	no
40p	160	no
50p	192	no
1 GBP	224	no

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	ORANGE2	15

setting

name	value	default
Not fitted	0	yes
3 GBP	1	no
4 GBP	2	no
5 GBP	8	no
6 GBP	3	no
6 GBP Token	4	no
8 GBP	5	no
8 GBP Token	6	no
10 GBP	7	no
15 GBP	9	no
25 GBP	10	no
25 GBP (Licensed Betting Office Profile)	11	no
35 GBP	12	no
70 GBP	13	no
Reserved	14	no
Reserved	15	no

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	ORANGE2	240

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	1

location

name	number	inverted
DIL1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	2

location

name	number	inverted
DIL1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	4

location

name	number	inverted
DIL1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	8

location

name	number	inverted
DIL1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Target Percentage (if key not fitted)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Target Percentage (if key not fitted)	DIL1	240

location

name	number	inverted
DIL1	5	no
DIL1	6	no
DIL1	7	no
DIL1	8	no

value

name	value	default
Unset (Program Optimum)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

Token Lockout when full

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Lockout when full	DIL2	1

location

name	number	inverted
DIL2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL2	2

location

name	number	inverted
DIL2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Scottish Coin Handling

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Scottish Coin Handling	DIL2	4

location

name	number	inverted
DIL2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Out of Credit Display Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Out of Credit Display Inhibit	DIL2	8

location

name	number	inverted
DIL2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

OCD Audio Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
OCD Audio Enable	DIL2	16

location

name	number	inverted
DIL2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Coin Alarm Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Alarm Inhibit	DIL2	32

location

name	number	inverted
DIL2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Token Refill Level Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Refill Level Inhibit	DIL2	64

location

name	number	inverted
DIL2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Single Credit Entry

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Single Credit Entry	DIL2	128

location

name	number	inverted
DIL2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

clones

name	description
m4potblk__c	Pot Black (Barcrest) (MPU4) (PBG 1.4)
m4potblk__d	Pot Black (Barcrest) (MPU4) (PBG 1.5 AD)
m4potblk__e	Pot Black (Barcrest) (MPU4) (PBG 1.5 B)
m4potblk__f	Pot Black (Barcrest) (MPU4) (PBG 1.5 BD)
m4potblk__g	Pot Black (Barcrest) (MPU4) (PBG 1.5 D)
m4potblk__h	Pot Black (Barcrest) (MPU4) (PBG 1.5 DH)
m4potblk__l	Pot Black (Barcrest) (MPU4) (PBG 1.5 H)
m4potblk__m	Pot Black (Barcrest) (MPU4) (PBG 1.5 K)
m4potblk__i	Pot Black (Barcrest) (MPU4) (PBG 1.5 KD)
m4potblk__n	Pot Black (Barcrest) (MPU4) (PBG 1.5 R)
m4potblk__j	Pot Black (Barcrest) (MPU4) (PBG 1.5 RD)
m4potblk__p	Pot Black (Barcrest) (MPU4) (PBG 1.5 Y)
m4potblk__a	Pot Black (Barcrest) (MPU4) (PBG 1.5 Y, hack)
m4potblk__k	Pot Black (Barcrest) (MPU4) (PBG 1.5 YD)
m4potblk__o	Pot Black (Barcrest) (MPU4) (PBG 1.5)
m4potblk__q	Pot Black (Barcrest) (MPU4) (PBG 1.6 AD)
m4potblk__r	Pot Black (Barcrest) (MPU4) (PBG 1.6 B)
m4potblk__s	Pot Black (Barcrest) (MPU4) (PBG 1.6 BD)
m4potblk__t	Pot Black (Barcrest) (MPU4) (PBG 1.6 D)
m4potblk__u	Pot Black (Barcrest) (MPU4) (PBG 1.6 DH)
m4potblk__y	Pot Black (Barcrest) (MPU4) (PBG 1.6 H)
m4potblk__z	Pot Black (Barcrest) (MPU4) (PBG 1.6 K)
m4potblk__v	Pot Black (Barcrest) (MPU4) (PBG 1.6 KD)
m4potblk__0	Pot Black (Barcrest) (MPU4) (PBG 1.6 R)
m4potblk__w	Pot Black (Barcrest) (MPU4) (PBG 1.6 RD)
m4potblk__1	Pot Black (Barcrest) (MPU4) (PBG 1.6 Y)
m4potblk__x	Pot Black (Barcrest) (MPU4) (PBG 1.6 YD)
m4potblk__2	Pot Black (Barcrest) (MPU4) (PBS 0.4 AD)
m4potblk__3	Pot Black (Barcrest) (MPU4) (PBS 0.4 B)
m4potblk__4	Pot Black (Barcrest) (MPU4) (PBS 0.4 BD)
m4potblk__5	Pot Black (Barcrest) (MPU4) (PBS 0.4 C)
m4potblk__b	Pot Black (Barcrest) (MPU4) (PBS 0.4 C, hack)
m4potblk__6	Pot Black (Barcrest) (MPU4) (PBS 0.4 DH)
m4potblk__aa	Pot Black (Barcrest) (MPU4) (PBS 0.4 H)
m4potblk__ab	Pot Black (Barcrest) (MPU4) (PBS 0.4 K)
m4potblk__7	Pot Black (Barcrest) (MPU4) (PBS 0.4 KD)
m4potblk__ac	Pot Black (Barcrest) (MPU4) (PBS 0.4 R)
m4potblk__8	Pot Black (Barcrest) (MPU4) (PBS 0.4 RD)
m4potblk__ae	Pot Black (Barcrest) (MPU4) (PBS 0.4 Y)
m4potblk__9	Pot Black (Barcrest) (MPU4) (PBS 0.4 YD)
m4potblk__ad	Pot Black (Barcrest) (MPU4) (PBS 0.4)
m4potblk__af	Pot Black (Barcrest) (MPU4) (PBS 0.6 AD)
m4potblk__ag	Pot Black (Barcrest) (MPU4) (PBS 0.6 B)
m4potblk__ah	Pot Black (Barcrest) (MPU4) (PBS 0.6 BD)
m4potblk__ai	Pot Black (Barcrest) (MPU4) (PBS 0.6 C)
m4potblk__aj	Pot Black (Barcrest) (MPU4) (PBS 0.6 D)
m4potblk__ak	Pot Black (Barcrest) (MPU4) (PBS 0.6 DH)
m4potblk__ao	Pot Black (Barcrest) (MPU4) (PBS 0.6 H)
m4potblk__ap	Pot Black (Barcrest) (MPU4) (PBS 0.6 K)
m4potblk__al	Pot Black (Barcrest) (MPU4) (PBS 0.6 KD)
m4potblk__aq	Pot Black (Barcrest) (MPU4) (PBS 0.6 R)
m4potblk__am	Pot Black (Barcrest) (MPU4) (PBS 0.6 RD)
m4potblk__as	Pot Black (Barcrest) (MPU4) (PBS 0.6 Y)
m4potblk__an	Pot Black (Barcrest) (MPU4) (PBS 0.6 YD)
m4potblk__ar	Pot Black (Barcrest) (MPU4) (PBS 0.6)
m4potblk__aw	Pot Black (BWB) (MPU4) (PO 1.1 D)
m4potblk__ax	Pot Black (BWB) (MPU4) (PO 1.1 K)
m4potblk__au	Pot Black (BWB) (MPU4) (PO 1.1)
m4potblk__av	Pot Black (BWB) (MPU4) (PO 1.2 D)
m4ptblkc	Pot Black (BWB) (MPU4) (PO 1.2 K)
m4potblk__at	Pot Black (BWB) (MPU4) (PO 1.2)
