Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 1)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
m4rmtpd	barcrest/mpu4avan.cpp		no	no	yes	yes	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 1)	199?	Avantime?

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
rdiua202.bin	65536	faa875ea	d8d206fed8965a26dd8ded38a3be018311ccf407	maincpu	0	good	no
rmdxi	2903	c16021ec	df77e410ea2edae1559e40a877e292f0d1969b0a	gal	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	6880000
audio	mono	Speaker
audio	alarmdac	1-Bit DAC
audio	okicard	Barcrest Sampled Sound Program Card	1720000
audio	okicard:msm6376	OKI MSM6376 ADPCM	128000

device_ref

tag	name
:maincpu	mc6809
:50hz	timer
:vfd	msc1937
:ptm_ic2	ptm6840
:pia_ic3	pia6821
:pia_ic4	pia6821
:pia_ic5	pia6821
:pia_ic6	pia6821
:pia_ic7	pia6821
:pia_ic8	pia6821
:meters	meters
:dataport	bacta_datalogger
:hopper	coin_hopper
:mono	speaker
:alarmdac	dac
:nvram	nvram
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:okicard	mpu4okisnd
:okicard:ptm_ic3ss	ptm6840
:okicard:pia_ic4ss	pia6821
:okicard:msm6376	okim6376
:reel0	stepper
:reel1	stepper
:reel2	stepper
:reel3	stepper

sound

channels
1

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		7		no

port, analog

port_tag	analog_masks
:AUX1
:AUX2
:BLACK1
:BLACK2
:DIL1
:DIL2
:ORANGE1
:ORANGE2
:hopper:TEST

configuration

Stake Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stake Key	ORANGE1	224

setting

name	value	default
Not fitted / 5p	0	yes
10p	32	no
20p	64	no
25p	96	no
30p	128	no
40p	160	no
50p	192	no
1 GBP	224	no

Jackpot / Prize Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Jackpot / Prize Key	ORANGE2	15

setting

name	value	default
Not fitted	0	yes
3 GBP	1	no
4 GBP	2	no
5 GBP	8	no
6 GBP	3	no
6 GBP Token	4	no
8 GBP	5	no
8 GBP Token	6	no
10 GBP	7	no
15 GBP	9	no
25 GBP	10	no
25 GBP (Licensed Betting Office Profile)	11	no
35 GBP	12	no
70 GBP	13	no
Reserved	14	no
Reserved	15	no

Percentage Key

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Percentage Key	ORANGE2	240

setting

name	value	default
Not fitted / 68% (Invalid for UK Games)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	1

location

name	number	inverted
DIL1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	2

location

name	number	inverted
DIL1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	4

location

name	number	inverted
DIL1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL1	8

location

name	number	inverted
DIL1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Target Percentage (if key not fitted)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Target Percentage (if key not fitted)	DIL1	240

location

name	number	inverted
DIL1	5	no
DIL1	6	no
DIL1	7	no
DIL1	8	no

value

name	value	default
Unset (Program Optimum)	0	yes
70	16	no
72	32	no
74	48	no
76	64	no
78	80	no
80	96	no
82	112	no
84	128	no
86	144	no
88	160	no
90	176	no
92	192	no
94	208	no
96	224	no
98	240	no

Token Lockout when full

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Lockout when full	DIL2	1

location

name	number	inverted
DIL2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIL2	2

location

name	number	inverted
DIL2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Scottish Coin Handling

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Scottish Coin Handling	DIL2	4

location

name	number	inverted
DIL2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Out of Credit Display Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Out of Credit Display Inhibit	DIL2	8

location

name	number	inverted
DIL2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

OCD Audio Enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
OCD Audio Enable	DIL2	16

location

name	number	inverted
DIL2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Coin Alarm Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Alarm Inhibit	DIL2	32

location

name	number	inverted
DIL2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Token Refill Level Inhibit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Token Refill Level Inhibit	DIL2	64

location

name	number	inverted
DIL2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Single Credit Entry

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Single Credit Entry	DIL2	128

location

name	number	inverted
DIL2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

clones

name	description
m4rmtpd__i	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 10)
m4rmtpd__j	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 11)
m4rmtpd__k	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 12)
m4rmtpd__l	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 13)
m4rmtpd__m	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 14)
m4rmtpd__n	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 15)
m4rmtpd__o	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 16)
m4rmtpd__p	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 17)
m4rmtpd__q	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 18)
m4rmtpd__r	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 19)
m4rmtpd__a	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 2)
m4rmtpd__s	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 20)
m4rmtpd__t	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 21)
m4rmtpd__u	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 22)
m4rmtpd__v	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 23)
m4rmtpd__w	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 24)
m4rmtpd__x	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 25)
m4rmtpd__y	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 26)
m4rmtpd__z	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 27)
m4rmtpd__0	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 28)
m4rmtpd__1	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 29)
m4rmtpd__b	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 3)
m4rmtpd__2	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 30)
m4rmtpd__3	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 31)
m4rmtpd__4	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 32)
m4rmtpd__5	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 33)
m4rmtpd__6	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 34)
m4rmtpd__7	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 35)
m4rmtpd__8	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 36)
m4rmtpd__9	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 37)
m4rmtpd__aa	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 38)
m4rmtpd__ab	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 39)
m4rmtpd__c	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 4)
m4rmtpd__ac	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 40)
m4rmtpd__ad	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 41)
m4rmtpd__ae	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 42)
m4rmtpd__af	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 43)
m4rmtpd__ag	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 44)
m4rmtpd__ah	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 45)
m4rmtpd__ai	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 46)
m4rmtpd__aj	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 47)
m4rmtpd__ak	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 48)
m4rmtpd__al	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 49)
m4rmtpd__d	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 5)
m4rmtpd__am	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 50)
m4rmtpd__e	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 6)
m4rmtpd__f	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 7)
m4rmtpd__g	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 8)
m4rmtpd__h	Reel Magic Turbo Play Deluxe (Avantime?) (MPU4) (set 9)
