MZ-1500 - mame (0278) machine

MAME: 0278 - Released: 2025-06-29T00:16:39 - Machines: 48574 - rom: 362783 - disk: 1374

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
mz1500	sharp/mz700.cpp		no	no	no	yes	MZ-1500	1984	Sharp

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	200	50.036312	8867235	568	0	320	312	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
9z-502m.rom	10240	643db428	c2ad8af2ef00db32afde54d5741b07de5d4da16a	monitor	0	good	no
mz700fon.jpn	4096	425eedf5	bd2cc750f2d2f63e50a59786668509e81a276e32	cgrom	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3546894
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	cassette	Cassette
audio	sn76489n	SN76489	3546894

softwarelist

tag	name	status	filter
cass_list	mz800_cass	original

device_ref

name
z80
screen
palette
gfxdecode
speaker
speaker_sound_device
timer
timer
pit8253
pit_counter
pit_counter
pit_counter
i8255
ttl74145
cassette_image
ram
address_map_bank
sn76489
software_list
z80pio
msx_general_purpose_port
msx_joystick
msx_general_purpose_port
msx_joystick
centronics
centronics_printer
printer_image
output_latch

sound

channels
1

ramoption

name	default
64K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
cassette	cassette	mz_cass			cassette	cass
printout	centronics:printer:printer				printout	prin

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
cassette	cassette	mz_cass			wav, flac, m12, mzf, mzt
printout	centronics:printer:printer				prn

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse
joy	1	2	8	no
keyboard	1	68		no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:JOY
:ROW0
:ROW1
:ROW2
:ROW3
:ROW4
:ROW5
:ROW6
:ROW7
:ROW8
:ROW9
:joy1:joystick:JOY
:joy2:joystick:JOY
:system_settings

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
joy1	vaus	msx_vaus	no
joy1	townspad	msx_townspad	no
joy1	towns6b	msx_towns6b	no
joy1	sega	msx_segactrl	no
joy1	mouse	msx_mouse	no
joy1	magickey	msx_magickey	no
joy1	libbler	msx_libblerpad	no
joy1	martypad	msx_martypad	no
joy1	joystick	msx_joystick	yes
joy1	xe1ap	msx_xe1ap	no
joy1	hypershot	msx_hypershot	no
joy2	vaus	msx_vaus	no
joy2	townspad	msx_townspad	no
joy2	towns6b	msx_towns6b	no
joy2	sega	msx_segactrl	no
joy2	mouse	msx_mouse	no
joy2	magickey	msx_magickey	no
joy2	libbler	msx_libblerpad	no
joy2	martypad	msx_martypad	no
joy2	joystick	msx_joystick	yes
joy2	xe1ap	msx_xe1ap	no
joy2	hypershot	msx_hypershot	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes

dipswitch

Mode selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Mode selection	system_settings	1

location

name	number	inverted
SW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
MZ-700	1	no
MZ-800	0	yes

Printer selection

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Printer selection	system_settings	6

location

name	number	inverted
SW	3	no
SW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
MZ printer	6	yes
Centronics printer	0	no

Cassette polarity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cassette polarity	system_settings	8

location

name	number	inverted
SW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Unknown	8	yes
Unknown	0	no
