PC-6601 (Japan) - mame (0278) machine

MAME: 0278 - Released: 2025-06-29T00:16:39 - Machines: 48574 - rom: 362783 - disk: 1374

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pc6601	nec/pc6001.cpp		no	no	no	yes	PC-6601 (Japan)	1983	NEC	pc6001	pc6001

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	60.000000	4665600	320	0	320	243	0	240	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional
basicrom.66	32768	c0b01772	9240bb6b97fe06f5f07b5d65541c4d2f8758cc2a	maincpu	10000	good	no
voicerom.66	16384	91d078c1	6a93bd7723ef67f461394530a9feee57c8caf7b7	maincpu	18000	good	no
cgrom60.66	8192	d2434f29	a56d76f5cbdbcdb8759abe601eab68f01b0a8fe8	maincpu	1c000	good	no
cgrom66.66	8192	3ce48c33	f3b6c63e83a17d80dde63c6e4d86adbc26f84f79	maincpu	1e000	good	no
kanjirom.66	32768	20c8f3eb	4c9f30f0a2ebbe70aa8e697f94eac74d8241cadd	maincpu	20000	good	no
i8049	4096			mcu	0	nodump	no

type	tag	name	clock
cpu	maincpu	Zilog Z80	3993600
cpu	pc80s31:fdc_cpu	Zilog Z80	4000000
audio	mono	Speaker
audio	aysnd	AY-3-8910A PSG	1996800
audio	upd7752	NEC uPD7752	1996800
audio	fdc:0:35ssdd:flopsndout	Speaker
audio	fdc:0:35ssdd:floppysound	Floppy sound	44100
audio	pc80s31:fdc:0:525hd:flopsndout	Speaker
audio	pc80s31:fdc:0:525hd:floppysound	Floppy sound	44100
audio	pc80s31:fdc:1:525hd:flopsndout	Speaker
audio	pc80s31:fdc:1:525hd:floppysound	Floppy sound	44100

tag	name	status	filter
cart_list_pc6001	pc6001_cart	original

channels
4

device, instance

type	tag	interface	name	briefname
cartridge	cartslot	pc6001_cart	cartridge1	cart1
cartridge	cas_hack	pc6001_cass	cartridge2	cart2
floppydisk	fdc:0:35ssdd	floppy_3_5	floppydisk1	flop1
floppydisk	pc80s31:fdc:0:525hd	floppy_5_25	floppydisk2	flop2
floppydisk	pc80s31:fdc:1:525hd	floppy_5_25	floppydisk3	flop3

type	tag	interface	extension_names
cartridge	cartslot	pc6001_cart	bin
cartridge	cas_hack	pc6001_cass	cas, p6
floppydisk	fdc:0:35ssdd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	pc80s31:fdc:0:525hd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi
floppydisk	pc80s31:fdc:1:525hd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi

players	coins	service	tilt
2		no	no

slot_name	slotoption_name	slotoption_devname	slotoption_default
joy1	vaus	msx_vaus	no
joy1	townspad	msx_townspad	no
joy1	towns6b	msx_towns6b	no
joy1	sega	msx_segactrl	no
joy1	mouse	msx_mouse	no
joy1	magickey	msx_magickey	no
joy1	libbler	msx_libblerpad	no
joy1	martypad	msx_martypad	no
joy1	joystick	msx_joystick	yes
joy1	xe1ap	msx_xe1ap	no
joy1	hypershot	msx_hypershot	no
joy2	vaus	msx_vaus	no
joy2	townspad	msx_townspad	no
joy2	towns6b	msx_towns6b	no
joy2	sega	msx_segactrl	no
joy2	mouse	msx_mouse	no
joy2	magickey	msx_magickey	no
joy2	libbler	msx_libblerpad	no
joy2	martypad	msx_martypad	no
joy2	joystick	msx_joystick	yes
joy2	xe1ap	msx_xe1ap	no
joy2	hypershot	msx_hypershot	no
cartslot
cas_hack
fdc:0	35ssdd	floppy_35_ssdd	yes
fdc:0	35dd	floppy_35_dd	no
pc80s31:fdc:0	525hd	floppy_525_hd	yes
pc80s31:fdc:1	525hd	floppy_525_hd	yes

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Mode 4 GFX colors	MODE4_DSW	7
