Pinball Champ - mame (0288) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pinchamp	pinball/zac_2.cpp	genpin	no	no	yes	yes	Pinball Champ	1983	Zaccaria

snap

Pinball Champ png snap

Pinball Champ jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
pinchamp	17718	20/03/2026 16:23:36	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	c021d434cc8766ce5418eb3047c40dcb915492a9

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
pinchamp.ic1	4096	1412ec33	82c158ec0536f76cbe80e8c12e0047579439a5b7	maincpu	0	good	no
pinchamp.ic2	4096	a24ba4c6	4f02c4d6cd727fa96a68c72012b0b4a4484397c4	maincpu	800	good	no
pinchamp.ic3	4096	df5f4f88	249cf958b0998aa41fa26c617be9b6c52c2f5549	maincpu	1000	good	no
pchmp_gb.1c	4096	f739fcba	7460f1da99c474601e8cec64683cbd61837a82e8	cpu2	f000	good	no
pchmp_gb.1e	4096	24d83e74	f78e151c9885b965cd5209777580414522362ebf	cpu2	e000	good	no
pchmp_gb.1f	4096	d055e8c6	0820d941880aa8925b400c792af7ce6b80dcbc48	cpu2	d000	good	no
pchmp_gb.1g	2048	39b68215	4d57f1f1f71f7bdbef67ca4cc62cfde80d1ab04c	cpu2	c000	good	no

chip

type	tag	name	clock
cpu	maincpu	Signetics 2650	3000000
audio	mechvol	Speaker
audio	samples	Samples

device_ref

tag	name
:maincpu	s2650
:ram	nvram
:zac_2_inttimer	timer
:zac_2_outtimer	timer
:mechvol	speaker
:samples	samples

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		54		no

port, analog

port_tag	analog_masks
:DSW
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7

dipswitch

Switch A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch A	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Switch B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch B	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Switch C

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch C	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Switch D

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Switch D	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

clones

name	description
pinchamp7f	Pinball Champ (7 digits French speech)
pinchamp7g	Pinball Champ (7 digits German speech)
pinchamp7i	Pinball Champ (7 digits Italian speech)
pinchamp7	Pinball Champ (7 digits)
pinchampf	Pinball Champ (French speech)
pinchampg	Pinball Champ (German speech)
pinchampi	Pinball Champ (Italian speech)
