Crystal Maze - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pl6_cm	jpm/pluto6.cpp		no	no	no	yes	Crystal Maze	2004	JPM

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
pl6_cm	15786	29/12/2025 11:31:38	495	640	96	96	0	Format24bppRgb	305:MAMEUI 0.282.0 (2025-10-31)	0e1e27c09f827728147e47c0637904a74fec4cbd

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
60a8_b1.u1	1048576	1e9bbb77	a93b89856f41cfe477a2791ca22c25e8249ab496	maincpu	0	good	no
acc6_b2.u2	1048576	97494822	01b7f2eb9af34e0a2d626ec303979c6b53cb83b9	program1	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Freescale MCF5206E	40000000
audio	speaker	Speaker
audio	fpga:ldac	CS4334 DAC
audio	fpga:rdac	CS4334 DAC

device_ref

tag	name
:maincpu	mcf5206e
:maincpu:sim	coldfire_sim
:maincpu:sim:watchdog	watchdog
:maincpu:timer1	coldfire_timer
:maincpu:timer2	coldfire_timer
:maincpu:uart1	mcf5206euart
:maincpu:uart1:cha	duart_channel
:maincpu:uart1:chb	duart_channel
:maincpu:uart2	mcf5206euart
:maincpu:uart2:cha	duart_channel
:maincpu:uart2:chb	duart_channel
:maincpu:mbus	coldfire_mbus
:maincpu:dma0	coldfire_dma
:maincpu:dma1	coldfire_dma
:exp0	pl6expslot
:exp1	pl6expslot
:speaker	speaker
:fpga	pl6_fpga
:fpga:ldac	cs4334
:fpga:rdac	cs4334
:fpga:rs232a	rs232
:fpga:bactaport	rs232
:fpga:rs232c	rs232
:fpga:rs232d	rs232
:fpga:cctalk1	rs232
:fpga:cctalk2	rs232
:fpga:ttl	rs232
:fpga:rs485	rs232
:pic18	pl6_pic
:nvram	nvram
:duart	mc68681
:duart:cha	duart_channel
:duart:chb	duart_channel
:i2cmem	24c04
:ata	ata_interface
:ata:0	ata_slot
:ata:0:hdd	idehd
:ata:0:hdd:image	harddisk_image
:ata:1	ata_slot
:vfd	msc1937

sound

channels
1

feature

type	status	overall
protection	unemulated
sound		unemulated

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
harddisk	ata:0:hdd:image	ide_hdd,hdd			harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
harddisk	ata:0:hdd:image	ide_hdd,hdd			chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons	1	16		no
only_buttons	2	16		no

port, analog

port_tag	analog_masks
:DEBUG
:IN0
:fpga:IN1
:pic18:Percentage
:pic18:SECSW
:pic18:SW1
:pic18:SW2
:pic18:Stake-Jackpot
