name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pt68k2	skeleton/pt68k4.cpp		no	no	no	yes	PT68K2	1988	Peripheral Technology

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
isa1:cga:screen	raster	0	640	200	59.922748	14318181	912	0	640	262	0	200	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional
hum_u20.bin	32768	69db483a	9dfea73e4d7deef7c66a27cca92eb7c9ff767215	roms	0	good	no
hum_u27.bin	32768	54441b06	0e2d63b1cd01f88f37fc4859c11c252c4fea220b	roms	1	good	no
u21_ds1220.bin	2048	7a6b75ce	07663860aa6cc21aed04a568ff9c05bc75d62e4f	timekpr	0	good	no

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
cpu	kbd:pcxt:i8048	Intel 8048	5102535
audio	wdfdc:0:525dd:flopsndout	Speaker
audio	wdfdc:0:525dd:floppysound	Floppy sound	44100
audio	wdfdc:1:525dd:flopsndout	Speaker
audio	wdfdc:1:525dd:floppysound	Floppy sound	44100
audio	mono	Speaker
audio	speaker	Filtered DAC

tag	name	status	filter
flop525_list	pt68k2	original

channels
3

type	status	overall
graphics		imperfect

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	wdfdc:0:525dd	floppy_5_25			floppydisk1	flop1
floppydisk	wdfdc:1:525dd	floppy_5_25			floppydisk2	flop2

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	wdfdc:0:525dd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	wdfdc:1:525dd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

players	coins	service	tilt
1		no	no

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		83		no

slot_name	slotoption_name	slotoption_devname	slotoption_default
kbd	iskr1030	kb_iskr1030	no
kbd	ec1841	kb_ec1841	no
kbd	pcxt	kb_pcxt83	yes
kbd	pc	kb_pc83	no
kbd	keytronc_pc3270	keytronic_pc3270	no
wdfdc:0	525dd	floppy_525_dd	yes
wdfdc:1	525dd	floppy_525_dd	yes
isa1	xtide	xtide	no
isa1	lpt	isa_lpt	no
isa1	wdxt_gen	wdxt_gen	no
isa1	vga	ibm_vga	no
isa1	fdc_at	isa8_fdc_at	no
isa1	ega	ega	no
isa1	cga	cga	yes
isa1	mda	isa_ibm_mda	no
isa2	xtide	xtide	no
isa2	lpt	isa_lpt	no
isa2	wdxt_gen	wdxt_gen	no
isa2	vga	ibm_vga	no
isa2	fdc_at	isa8_fdc_at	no
isa2	ega	ega	no
isa2	cga	cga	no
isa2	mda	isa_ibm_mda	no
isa3	xtide	xtide	no
isa3	lpt	isa_lpt	no
isa3	wdxt_gen	wdxt_gen	no
isa3	vga	ibm_vga	no
isa3	fdc_at	isa8_fdc_at	no
isa3	ega	ega	no
isa3	cga	cga	no
isa3	mda	isa_ibm_mda	no
isa4	xtide	xtide	no
isa4	lpt	isa_lpt	no
isa4	wdxt_gen	wdxt_gen	no
isa4	vga	ibm_vga	no
isa4	fdc_at	isa8_fdc_at	no
isa4	ega	ega	no
isa4	cga	cga	no
isa4	mda	isa_ibm_mda	no
isa5	xtide	xtide	no
isa5	lpt	isa_lpt	no
isa5	wdxt_gen	wdxt_gen	no
isa5	vga	ibm_vga	no
isa5	fdc_at	isa8_fdc_at	no
isa5	ega	ega	no
isa5	cga	cga	no
isa5	mda	isa_ibm_mda	no
isa6	xtide	xtide	no
isa6	lpt	isa_lpt	no
isa6	wdxt_gen	wdxt_gen	no
isa6	vga	ibm_vga	no
isa6	fdc_at	isa8_fdc_at	no
isa6	ega	ega	no
isa6	cga	cga	no
isa6	mda	isa_ibm_mda	no

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA character set	isa1:cga:cga_config	3

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Alternative	1	no

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA monitor type	isa1:cga:cga_config	28

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA chipset	isa1:cga:cga_config	224
