Take Note Club (Bellfruit) (Scorpion 4) (set 1) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sc4takcl	bfm/bfm_sc4.cpp		no	no	no	yes	Take Note Club (Bellfruit) (Scorpion 4) (set 1)	200?	BFM

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
95408062.lo	524288	bb70c78a	187409c94b89b3990e464beef0a78d1c7fe6038d	maincpu	1	good	no
95408063.hi	524288	7f85a7bd	5355d2ac07790796379f376ff334d0c17cc913f6	maincpu	0	good	no
95008314.bin	1048576	64d2a26a	f01944363e77bf33b44a06224e44828b065fdee4	ymz	0	good	no

chip

type	tag	name	clock
cpu	maincpu	MC68307	16000000
audio	mono	Speaker
audio	ymz	Yamaha YMZ280B PCMD8	16000000

device_ref

tag	name
:maincpu	mc68307
:maincpu:internal68681	mc68681
:maincpu:internal68681:cha	duart_channel
:maincpu:internal68681:chb	duart_channel
:mono	speaker
:nvram	nvram
:duart68681	mc68681
:duart68681:cha	duart_channel
:duart68681:chb	duart_channel
:vfd0	bfm_bda
:ymz	ymz280b
:sec	sec
:reel1	stepper
:reel2	stepper
:reel3	stepper
:reel4	stepper
:reel5	stepper

sound

channels
1

input

players	coins	service	tilt
1	6	no	no
