Action Fighter (FD1089A 317-0018) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
afighter	sega/segas16a.cpp		no	no	no	yes	Action Fighter (FD1089A 317-0018)	1986	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	224	60.000000	5376240	342	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
epr-10350	32768	f2cd6b3f	380f75b8c1696b388179641866cd1d23f78664e7	maincpu	1	good	no
epr-10353	32768	5a757dc9	b0540844c8a09195f5d12312f8e27c334641d7b8	maincpu	0	good	no
epr-10349	32768	4b434c37	5f3afbdb9cdb0762e56b702a195274f30193b472	maincpu	10001	good	no
epr-10352	32768	f8abb143	97e78291c15bdf95fd35adca6b9e002480137b12	maincpu	10000	good	no
epr-10348	32768	e51e3012	bb5522aacb55b5f04aa4cb7a642e202f0ddd7c84	maincpu	20001	good	no
epr-10351	32768	ede21d8d	b3e3944d706c606fd01e00d9511f020ce9aec9f0	maincpu	20000	good	no
epr-10281.95	65536	30e92cda	36293a2a8a22dca5350571f19f3d5d04e1b27458	gfx1	0	good	no
epr-10282.94	65536	b67b8910	f3f029a3e6547114cec28e5cf8fda65ef434c353	gfx1	10000	good	no
epr-10283.93	65536	e7dbfd2d	91bae3fbc4a3c612dc507eecfa8de1c2e1e7afee	gfx1	20000	good	no
epr-10285	32768	98aa3d04	1d26d17a72e55281e3444fee9c5af69ffb9e3c69	sprites	1	good	no
epr-10286	32768	8da050cf	c28e8968dbd9c110672581f4486f70d5f45df7f5	sprites	10001	good	no
epr-10287	32768	7989b74a	a87acafe82b37a11d8f8b1f2ee4c9b2e1bb8161c	sprites	20001	good	no
epr-10288	32768	d3ce551a	0ff2170d9ef89058273025dd8d5e1021094adef1	sprites	30001	good	no
epr-10289	32768	c59d1b98	e232f2519234981c0e4ffecdd25c48083d9f93a8	sprites	0	good	no
epr-10290	32768	39354223	d8a73d3f7fc2d83d23bb7434f43bc8804f35cc16	sprites	10000	good	no
epr-10291	32768	6e4b245c	1f8cecf7ea2d2dfa5ce18d7ee34b0da2cc40221e	sprites	20000	good	no
epr-10292	32768	cef289a3	7ab817b6348c168f79be325fb3cc2cca14ee0f8e	sprites	30000	good	no
epr-10284.12	32768	8ff09116	8b99b6d2499897cfbd037a7e7cf5bc53bce8a63a	soundcpu	0	good	no
317-0018.key	8192	65b5b1af	9a236c0c223064f9a2a56561e10b9ffed0f567a3	maincpu:key	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi FD1089A Encrypted CPU	10000000
cpu	soundcpu	Zilog Z80	4000000
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	4000000

device_ref

name
fd1089a
z80
i8243
nvram
watchdog
i8255
screen
sega_sys16a_sprite
segaic16_video
gfxdecode
palette
speaker
generic_latch_8
ym2151

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SERVICE
:UNUSED

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	0	yes
Cocktail	1	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	8	no
3	12	yes
4	4	no
Infinite	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW2	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10000 - 20000	48	yes
20000 - 40000	32	no
30000 - 60000	16	no
40000 - 80000	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	64	yes
Hard	0	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	128	yes
