HB-G900AP (MSX2, Europe) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
hbg900ap	msx/msx2.cpp		no	no	no	yes	HB-G900AP (MSX2, Europe)	1987	Sony	hbg900p	hbg900p

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	543	567	50.158978	21477272	684	0	543	626	10	577	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional	merge
g900bios.ic109	32768	b31c851d	0de3c802057560560a03d7965fcc4cff69f8575c	mainrom	good	no	g900bios.rom
g900ext.ic112	16384	8f84f783	3288894e1be6af705871499b23c85732dbc40993	subrom	good	no	g900ext.rom
g900disk.ic117	16384	54c73ad6	12f2cc79b3d09723840bae774be48c0d721ec1c6	diskrom	good	no	g900disk.rom
g900232c.rom	8192	be88e5f7	b2776159a7b92d74308b434a6b3e5feba161e2b7	rs232	baddump	no	g900232c.rom
g900util.rom	16384	ecf6abcf	6bb18cd2d69f124ad0c7c23a13eb0d2139037696	firmware	baddump	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3579545
audio	disk:fdc:0:35dd:flopsndout	Speaker
audio	disk:fdc:0:35dd:floppysound	Floppy sound	44100
audio	cartslot1	MSX Cartridge slot	3579545
audio	cartslot2	MSX Cartridge slot	3579545
audio	speaker	Speaker
audio	dac	1-Bit DAC
audio	ay8910	YM2149 SSG	1789772
audio	cassette	Cassette

softwarelist

tag	name	status
cass_list	msx2_cass	original
msx1_cass_list	msx1_cass	compatible
cart_list	msx2_cart	original
msx1_cart_list	msx1_cart	compatible
flop_list	msx2_flop	original
msx1_flop_list	msx1_flop	compatible

device_ref

name
msx_slot_rom
msx_slot_rom
msx_slot_disk1_wd2793_n
wd2793
floppy_connector
floppy_35_dd
speaker
flopsnd
msx_slot_rs232_sony
i8251
pit8253
pit_counter
pit_counter
pit_counter
rs232
msx_slot_rom
msx_slot_cartridge
msx_slot_cartridge
msx_slot_ram_mm
z80
ipt_merge_any_hi
i8255
screen
speaker
dac
ym2149
msx_general_purpose_port
msx_joystick
msx_general_purpose_port
msx_joystick
centronics
centronics_printer
printer_image
output_latch
input_buffer
output_latch
cassette_image
rp5c01
v9938
software_list
software_list
software_list
software_list
software_list
software_list

sound

channels
2

device, instance

type	tag	interface	name	briefname
floppydisk	disk:fdc:0:35dd	floppy_3_5	floppydisk	flop
cartridge	cartslot1	msx_cart	cartridge1	cart1
cartridge	cartslot2	msx_cart	cartridge2	cart2
printout	centronics:printer:printer		printout	prin
cassette	cassette	msx_cass	cassette	cass

device, extension

type	tag	interface	extension_names
floppydisk	disk:fdc:0:35dd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, dmk
cartridge	cartslot1	msx_cart	mx1, bin, rom
cartridge	cartslot2	msx_cart	mx1, bin, rom
printout	centronics:printer:printer		prn
cassette	cassette	msx_cass	wav, flac, tap, cas

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse
joy	1	2	8	no
keyboard	1	88		no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:KEY0
:KEY1
:KEY10
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9
:gen1:joystick:JOY
:gen2:joystick:JOY
:rs232:SWITCH

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
disk:fdc:0	35ssdd	floppy_35_ssdd	no
disk:fdc:0	35dd	floppy_35_dd	yes
rs232:rs232	terminal	serial_terminal	no
rs232:rs232	sunkbd	sunkbd_adaptor	no
rs232:rs232	dec_loopback	dec_rs232_loopback	no
rs232:rs232	ie15	ie15_terminal	no
rs232:rs232	null_modem	null_modem	no
rs232:rs232	keyboard	serial_keyboard	no
rs232:rs232	patch	rs232_patch_box	no
rs232:rs232	swtpc8212	swtpc8212_terminal	no
rs232:rs232	printer	serial_printer	no
rs232:rs232	scorpion	scorpion_ic	no
rs232:rs232	loopback	rs232_loopback	no
rs232:rs232	mockingboard	mockingboardd	no
rs232:rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232:rs232	nss_tvi	nss_tvinterface	no
rs232:rs232	rs232_sync_io	rs232_sync_io	no
rs232:rs232	pty	pseudo_terminal	no
rs232:rs232	rs_printer	rs_serial_printer	no
cartslot1	ucn01	msx_cart_ucn01	no
cartslot1	softcard	msx_cart_softcard	no
cartslot1	moonsound	msx_moonsound	no
cartslot1	franky	msx_cart_franky	no
cartslot1	beepack	msx_cart_beepack	no
cartslot1	ram16k	msx_cart_16k_ram	no
cartslot1	mm768k	msx_cart_768k_mm_ram	no
cartslot1	mmm	msx_cart_mmm	no
cartslot1	sunrise_ataide	msx_cart_sunrise_ataide	no
cartslot1	slotexp	msx_cart_slotexpander	no
cartslot1	mm1024k	msx_cart_1024k_mm_ram	no
cartslot1	mm4096k	msx_cart_4096k_mm_ram	no
cartslot1	mm512k	msx_cart_512k_mm_ram	no
cartslot1	hbi55	msx_cart_hbi55	no
cartslot1	mm256k	msx_cart_256k_mm_ram	no
cartslot1	double_ram	msx_cart_double_ram	no
cartslot1	ram64k	msx_cart_64k_ram	no
cartslot1	ram32k	msx_cart_32k_ram	no
cartslot1	ram48k	msx_cart_48k_ram	no
cartslot1	mm2048k	msx_cart_2048k_mm_ram	no
cartslot1	bm_012	msx_cart_bm_012	no
cartslot2	ucn01	msx_cart_ucn01	no
cartslot2	softcard	msx_cart_softcard	no
cartslot2	moonsound	msx_moonsound	no
cartslot2	franky	msx_cart_franky	no
cartslot2	beepack	msx_cart_beepack	no
cartslot2	ram16k	msx_cart_16k_ram	no
cartslot2	mm768k	msx_cart_768k_mm_ram	no
cartslot2	mmm	msx_cart_mmm	no
cartslot2	sunrise_ataide	msx_cart_sunrise_ataide	no
cartslot2	slotexp	msx_cart_slotexpander	no
cartslot2	mm1024k	msx_cart_1024k_mm_ram	no
cartslot2	mm4096k	msx_cart_4096k_mm_ram	no
cartslot2	mm512k	msx_cart_512k_mm_ram	no
cartslot2	hbi55	msx_cart_hbi55	no
cartslot2	mm256k	msx_cart_256k_mm_ram	no
cartslot2	double_ram	msx_cart_double_ram	no
cartslot2	ram64k	msx_cart_64k_ram	no
cartslot2	ram32k	msx_cart_32k_ram	no
cartslot2	ram48k	msx_cart_48k_ram	no
cartslot2	mm2048k	msx_cart_2048k_mm_ram	no
cartslot2	bm_012	msx_cart_bm_012	no
gen1	vaus	msx_vaus	no
gen1	townspad	msx_townspad	no
gen1	towns6b	msx_towns6b	no
gen1	sega	msx_segactrl	no
gen1	mouse	msx_mouse	no
gen1	magickey	msx_magickey	no
gen1	libbler	msx_libblerpad	no
gen1	martypad	msx_martypad	no
gen1	joystick	msx_joystick	yes
gen1	xe1ap	msx_xe1ap	no
gen1	hypershot	msx_hypershot	no
gen2	vaus	msx_vaus	no
gen2	townspad	msx_townspad	no
gen2	towns6b	msx_towns6b	no
gen2	sega	msx_segactrl	no
gen2	mouse	msx_mouse	no
gen2	magickey	msx_magickey	no
gen2	libbler	msx_libblerpad	no
gen2	martypad	msx_martypad	no
gen2	joystick	msx_joystick	yes
gen2	xe1ap	msx_xe1ap	no
gen2	hypershot	msx_hypershot	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes

configuration

RS-232C is

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232C is	rs232:SWITCH	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
disabled	0	no
enabled	1	yes
