mame (0289) • machine pc6001mk2sr • PC-6001mkIISR (Japan)

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pc6001mk2sr	nec/pc6001.cpp		no	no	no	yes	PC-6001mkIISR (Japan)	1984	NEC

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
pc6001mk2sr	1563	29/12/2025 11:31:37	320	240	96	96	0	Format24bppRgb	305:MAME 0.176 (Jul 27 2016)	b3e8b424e95b6caae3c5b28b1838230e02fae0ee

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	59.922743	7159090	456	0	320	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
basicrom.68	32768	516b1be3	e9977fc13f65f009f03d0340b1f1eb9a3e586739	basic_rom	0	good	no
cgrom60.68	8192	331473a9	361836f9758d6d9b5133c9dc7860a7c74f9cf596	tv_rom	0	good	no
cgrom66.68	8192	03ba2cf1	6fb32a4332b26aba2f28c3d8872cac5606be3998	tv_rom	2000	good	no
cgrom68.64	16384	73bc3256	5f80d62a95331dc39b2fb448a380fd10083947eb	cgrom	0	good	no
i8049	2048			mcu	0	nodump	no
systemrom1.64	65536	b6fc2db2	dd48b1eee60aa34780f153359f5da7f590f8dff4	sr_sysrom	10000	good	no
systemrom2.64	65536	55a62a1d	3a19855d290fd4ac04e6066fe4a80ecd81dc8dd7	sr_sysrom	0	good	no
voicerom.68	16384	37ff3829	f887e95e29d071df8329168b48c07b78e492c837	voice_rom	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3579545
cpu	pc80s31:fdc_cpu	Zilog Z80	4000000
audio	mono	Speaker
audio	upd7752	NEC uPD7752	1996800
audio	fdc:0:35sssd:flopsndout	Speaker
audio	fdc:0:35sssd:flopsnd	Floppy sound	44100
audio	pc80s31:fdc:0:525sd:flopsndout	Speaker
audio	pc80s31:fdc:0:525sd:flopsnd	Floppy sound	44100
audio	pc80s31:fdc:1:525sd:flopsndout	Speaker
audio	pc80s31:fdc:1:525sd:flopsnd	Floppy sound	44100
audio	ymsnd	YM2203 OPN	4000000

softwarelist

tag	name	status
cart_list	pc6001_cart	original
cass_list	pc6001_cass	original
cass_list_mk2	pc6001mk2_cass	original
flop_list_mk2	pc6001mk2_flop	original
cass_list_mk2sr	pc6001mk2sr_cass	original
flop_list_mk2sr	pc6001mk2sr_flop	original

device_ref

tag	name
:maincpu	z80
:ram	ram
:ppi8255	i8255
:gfxdecode	gfxdecode
:screen	screen
:palette	palette
:uart	i8251
:joy1	msx_general_purpose_port
:joy1:joystick	msx_joystick
:joy2	msx_general_purpose_port
:joy2:joystick	msx_joystick
:joymux	ls157_x2
:cartslot	generic_cartslot
:snapshot	snapshot_image
:mono	speaker
:centronics	centronics
:centronics:printer	centronics_printer
:centronics:printer:printer	printer_image
:cent_data_out	output_latch
:kbd	pc6001_kbd
:cart_list	software_list
:cass_list	software_list
:mk2_bank_0	address_map_bank
:mk2_bank_1	address_map_bank
:mk2_bank_2	address_map_bank
:mk2_bank_3	address_map_bank
:upd7752	upd7752
:cass_list_mk2	software_list
:sr_bank_1	address_map_bank
:sr_bank_2	address_map_bank
:sr_bank_3	address_map_bank
:sr_bank_4	address_map_bank
:sr_bank_5	address_map_bank
:sr_bank_6	address_map_bank
:sr_bank_7	address_map_bank
:sr_bank_8	address_map_bank
:sr_bank_9	address_map_bank
:sr_bank_10	address_map_bank
:sr_bank_11	address_map_bank
:sr_bank_12	address_map_bank
:sr_bank_13	address_map_bank
:sr_bank_14	address_map_bank
:sr_bank_15	address_map_bank
:sr_bank_16	address_map_bank
:fdc	upd765a
:fdc:0	floppy_connector
:fdc:0:35sssd	floppy_35_sssd
:fdc:0:35sssd:flopsndout	speaker
:fdc:0:35sssd:flopsnd	flopsnd
:pc80s31	pc80s31
:pc80s31:fdc_cpu	z80
:pc80s31:fdc	upd765a
:pc80s31:fdc:0	floppy_connector
:pc80s31:fdc:0:525sd	floppy_525_sd
:pc80s31:fdc:0:525sd:flopsndout	speaker
:pc80s31:fdc:0:525sd:flopsnd	flopsnd
:pc80s31:fdc:1	floppy_connector
:pc80s31:fdc:1:525sd	floppy_525_sd
:pc80s31:fdc:1:525sd:flopsndout	speaker
:pc80s31:fdc:1:525sd:flopsnd	flopsnd
:pc80s31:latch_0	generic_latch_8
:pc80s31:latch_1	generic_latch_8
:pc80s31:latch_2	generic_latch_8
:pc80s31:latch_3	generic_latch_8
:pc80s31:latch_4	generic_latch_8
:pc80s31:latch_5	generic_latch_8
:pc80s31:ppi_host	i8255
:pc80s31:ppi_fdc	i8255
:ymsnd	ym2203
:cass_list_mk2sr	software_list
:flop_list_mk2sr	software_list
:flop_list_mk2	software_list

sound

channels
4

feature

type	status	overall
sound	imperfect

ramoption

name	default
64K	yes

device, instance

type	tag	interface	name	briefname
cartridge	cartslot	pc6001_cart	cartridge	cart
snapshot	snapshot	pc6001_snap	snapshot	dump
printout	centronics:printer:printer		printout	prin
floppydisk	fdc:0:35sssd	floppy_3_5	floppydisk1	flop1
floppydisk	pc80s31:fdc:0:525sd	floppy_5_25	floppydisk2	flop2
floppydisk	pc80s31:fdc:1:525sd	floppy_5_25	floppydisk3	flop3

device, extension

type	tag	interface	extension_names
cartridge	cartslot	pc6001_cart	bin
snapshot	snapshot	pc6001_snap	cas, p6
printout	centronics:printer:printer		prn
floppydisk	fdc:0:35sssd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	pc80s31:fdc:0:525sd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi, hfe
floppydisk	pc80s31:fdc:1:525sd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi, hfe

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse
joy	1	2	8	no
keyboard	1	67		no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:MODE4_DSW
:joy1:joystick:JOY
:joy2:joystick:JOY
:kbd:KEY0
:kbd:KEY1
:kbd:KEY2
:kbd:KEY3
:kbd:KEY4
:kbd:KEY5
:kbd:KEY6
:kbd:KEY7
:kbd:KEY8
:kbd:KEY9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
joy1	xe1ap	msx_xe1ap	no
joy1	towns6b	msx_towns6b	no
joy1	townspad	msx_townspad	no
joy1	sega	msx_segactrl	no
joy1	vaus	msx_vaus	no
joy1	mouse	msx_mouse	no
joy1	martypad	msx_martypad	no
joy1	dual_joyport	msx_dual_joyport	no
joy1	libbler	msx_libblerpad	no
joy1	joystick	msx_joystick	yes
joy1	magickey	msx_magickey	no
joy1	hypershot	msx_hypershot	no
joy2	xe1ap	msx_xe1ap	no
joy2	towns6b	msx_towns6b	no
joy2	townspad	msx_townspad	no
joy2	sega	msx_segactrl	no
joy2	vaus	msx_vaus	no
joy2	mouse	msx_mouse	no
joy2	martypad	msx_martypad	no
joy2	dual_joyport	msx_dual_joyport	no
joy2	libbler	msx_libblerpad	no
joy2	joystick	msx_joystick	yes
joy2	magickey	msx_magickey	no
joy2	hypershot	msx_hypershot	no
cartslot
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	mz1p16	mz1p16	no
centronics	covox_stereo	covox_stereo	no
centronics	chessmec	centronics_chessmec	no
centronics	digiblst	cpcdigiblst	no
centronics	pl80	comx_pl80	no
centronics	printer	centronics_printer	yes
centronics	neomania	neomania_adapter	no
centronics	ex800	ex800	no
centronics	rx80	epson_rx80	no
centronics	ap2000	ap2000	no
centronics	samdac	centronics_samdac	no
centronics	fx80	epson_fx80	no
centronics	lx810l	lx810l	no
centronics	pc6022	pc6022	no
centronics	lx800	lx800	no
centronics	p72	p72	no
centronics	jx80	epson_jx80	no
centronics	covox	covox	no
centronics	adaptator	adaptator_multitap	no
fdc:0	35sssd	floppy_35_sssd	yes
fdc:0	35ssdd	floppy_35_ssdd	no
pc80s31:fdc:0	525dd	teac_fd_55f	no
pc80s31:fdc:0	525hd	floppy_525_hd	no
pc80s31:fdc:0	525sd	floppy_525_sd	yes
pc80s31:fdc:1	525dd	teac_fd_55f	no
pc80s31:fdc:1	525hd	floppy_525_hd	no
pc80s31:fdc:1	525sd	floppy_525_sd	yes

dipswitch

Screen 4 GFX colors

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Screen 4 GFX colors	MODE4_DSW	7

value

name	value	default
Monochrome	0	yes
Red/Blue	1	no
Blue/Red	2	no
Pink/Green	3	no
Green/Pink	4	no

clones

name	description
pc6601sr	PC-6601SR "Mr. PC" (Japan)
