name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pc8801	nec/pc8801.cpp		no	no	no	yes	PC-8801	1981	NEC

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	200	61.461972	14318181	896	0	640	260	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
n80.rom	32768	5cb8b584	063609dd518c124a4fc9ba35d1bae35771666a34	n80rom	0	good	no
n88.rom	32768	ffd68be0	3518193b8207bdebf22c1380c2db8c554baff329	n88rom	0	good	no
n88_0.rom	8192	61984bab	d1ae642aed4f0584eeb81ff50180db694e5101d4	n88rom	8000	good	no
kanji1.rom	131072	6178bd43	82e11a177af6a5091dd67f50a2f4bafda84d6556	kanji	0	good	yes
font.rom	2048	56653188	84b90f69671d4b72e8f219e1fe7cd667e976cf7f	cgrom	0	good	no

chip

type	tag	name	clock
cpu	z80	Zilog Z80	3993600
cpu	pc80s31:fdc_cpu	Zilog Z80	4000000
cpu	i8257	Intel 8257 DMA Controller	3993600
audio	pc80s31:fdc:0:525hd:flopsndout	Speaker
audio	pc80s31:fdc:0:525hd:floppysound	Floppy sound	44100
audio	pc80s31:fdc:1:525hd:flopsndout	Speaker
audio	pc80s31:fdc:1:525hd:floppysound	Floppy sound	44100
audio	cassette	Cassette
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	beeper	Beep	2400

softwarelist

tag	name	status
tape_list	pc8801_cass	original
disk_n88_list	pc8801_flop	original
disk_n_list	pc8001_flop	compatible

device_ref

name
z80
pc80s31
z80
upd765a
floppy_connector
floppy_525_hd
speaker
flopsnd
floppy_connector
floppy_525_hd
speaker
flopsnd
generic_latch_8
generic_latch_8
generic_latch_8
generic_latch_8
generic_latch_8
generic_latch_8
i8255
i8255
i8214
upd1990a
centronics
centronics_printer
printer_image
output_latch
cassette_image
software_list
i8251
software_list
software_list
screen
gfxdecode
palette
palette
upd3301
i8257
timer
speaker
speaker
beep
msx_general_purpose_port
msx_joystick
pc8801_exp_slot

sound

channels
4

feature

type	status	overall
timing	imperfect
graphics	imperfect
printer	unemulated
tape	unemulated

device, instance

type	tag	interface	name	briefname
floppydisk	pc80s31:fdc:0:525hd	floppy_5_25	floppydisk1	flop1
floppydisk	pc80s31:fdc:1:525hd	floppy_5_25	floppydisk2	flop2
printout	centronics:printer:printer		printout	prin
cassette	cassette	pc8801_cass	cassette	cass

device, extension

type	tag	interface	extension_names
floppydisk	pc80s31:fdc:0:525hd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi
floppydisk	pc80s31:fdc:1:525hd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, xdf, hdm, 2hd, fdi
printout	centronics:printer:printer		prn
cassette	cassette	pc8801_cass	wav, flac

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy		2	8	no
keyboard		90		no

port, analog

port_tag	analog_masks
:BOARD_CONFIG
:CFG
:CTRL
:DSW1
:DSW2
:KEY0
:KEY1
:KEY10
:KEY11
:KEY12
:KEY13
:KEY14
:KEY15
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9
:MEM
:mouseport:joystick:JOY

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
pc80s31:fdc:0	525hd	floppy_525_hd	yes
pc80s31:fdc:1	525hd	floppy_525_hd	yes
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
mouseport	vaus	msx_vaus	no
mouseport	townspad	msx_townspad	no
mouseport	towns6b	msx_towns6b	no
mouseport	sega	msx_segactrl	no
mouseport	mouse	msx_mouse	no
mouseport	magickey	msx_magickey	no
mouseport	libbler	msx_libblerpad	no
mouseport	martypad	msx_martypad	no
mouseport	joystick	msx_joystick	yes
mouseport	xe1ap	msx_xe1ap	no
mouseport	hypershot	msx_hypershot	no
exp	gsx8800	gsx8800	no
exp	jmbx1	jmbx1	no
exp	hmb20	hmb20	no
exp	pcg8100	pcg8100	no
exp	sbii	pc8801_23	no

configuration

Extension memory

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extension memory	MEM	15

setting

name	value	default
None	0	no
32KB (PC-8012-02 x 1)	1	no
64KB (PC-8012-02 x 2)	2	no
128KB (PC-8012-02 x 4)	3	no
128KB (PC-8801-02N x 1)	4	no
256KB (PC-8801-02N x 2)	5	no
512KB (PC-8801-02N x 4)	6	no
1M (PIO-8234H-1M x 1)	7	no
2M (PIO-8234H-2M x 1)	8	no
4M (PIO-8234H-2M x 2)	9	no
8M (PIO-8234H-2M x 4)	10	yes
1.1M (PIO-8234H-1M x 1 + PC-8801-02N x 1)	11	no
2.1M (PIO-8234H-2M x 1 + PC-8801-02N x 1)	12	no
4.1M (PIO-8234H-2M x 2 + PC-8801-02N x 1)	13	no

dipswitch

Speed mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Speed mode	CFG	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Slow	0	no
High	64	yes

Monitor Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Monitor Type	CTRL	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
15 KHz	2	yes
24 KHz	0	no

Auto-boot floppy at start-up

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto-boot floppy at start-up	CTRL	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

BASIC

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
BASIC	DSW1	1

location

name	number	inverted
SW4	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
N88-BASIC	1	yes
N-BASIC	0	no

Terminal mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Terminal mode	DSW1	2

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Text width

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Text width	DSW1	4

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
40 chars/line	4	no
80 chars/line	0	yes

Text height

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Text height	DSW1	8

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
20 lines/screen	8	no
25 lines/screen	0	yes

Enable S parameter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Enable S parameter	DSW1	16

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Enable DEL code

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Enable DEL code	DSW1	32

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

Memory wait

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Memory wait	DSW1	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Disable CMD SING

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable CMD SING	DSW1	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Parity generate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity generate	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Parity type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity type	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Even	0	yes
Odd	2	no

Serial character length

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Serial character length	DSW2	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
7 bits/char	4	no
8 bits/char	0	yes

Stop bit length

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop bit length	DSW2	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	8	yes
2	0	no

Enable X parameter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Enable X parameter	DSW2	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Duplex

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Duplex	DSW2	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Half	32	yes
Full	0	no

BASIC speed select

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
BASIC speed select	DSW2	64

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
High Speed Mode (V1H, V2)	64	yes
Standard Mode (V1S)	0	no

BASIC Version select

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
BASIC Version select	DSW2	128

location

name	number	inverted
SW4	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
V1 Mode	128	no
V2 Mode	0	yes
