Pentagon 1024SL - mame (0278) machine

MAME: 0278 - Released: 2025-06-29T00:16:39 - Machines: 48574 - rom: 362783 - disk: 1374

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pent1024	sinclair/pentagon.cpp		no	no	no	yes	Pentagon 1024SL	2005	Alex Zhabin	spec128	spec128

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	352	288	48.828125	7000000	448	88	440	320	32	320	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
gluk63r.rom	16384	ca321d79	015eb96dafb273d4f4512c467e9b43c305fd1bc4	maincpu	18000	good	no		v1
gluk52i.rom	16384	fe44b86a	9099d8a0f99a818849ca67ae1a8d3e7eacf06e65	maincpu	18000	good	no		v2
gluk53.rom	16384	479515ef	ed656cd4faa36de2e31b38102bcbd8cee12e7976	maincpu	18000	good	no		v3
gluk54r.rom	16384	f4c1e975	7e9e116750e1398572695b9cf8a120e47066256e	maincpu	18000	good	no		v4
gluk55r.rom	16384	3658c1ee	4a5c8ca1e090cfb0168796f0d695310fa5c955d3	maincpu	18000	good	no		v5
gluk55rr.rom	16384	6b60b818	9d606275d17770c9341b33b43f40aee227078827	maincpu	18000	good	no		v6
gluk60r.rom	16384	d114a032	5db3462ce7a51b473a3a7056e67c11a62cc1cc2a	maincpu	18000	good	no		v7
gluk601r.rom	16384	daf6310b	b8945168d4d136b731b33ec4758f8510c47fb8c4	maincpu	18000	good	no		v8
gluk51.rom	16384	ea8c760b	adaab28066ca46fbcdcf084c3b53d5a1b82d94a9	maincpu	18000	good	no		v9
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no
128p-1.rom	16384	b96a36be	80080644289ed93d71a1103992a154cc9802b2fa	maincpu	14000	good	no	zx128_1.rom

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3500000
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	cassette	Cassette
audio	ay_slot	AY Slot	1750000
audio	ay_slot:ay_ay8912:ay0	AY-3-8912A PSG	1750000
audio	beta:wd179x:0:525qd:flopsndout	Speaker
audio	beta:wd179x:0:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:1:525qd:flopsndout	Speaker
audio	beta:wd179x:1:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:2:525qd:flopsndout	Speaker
audio	beta:wd179x:2:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:3:525qd:flopsndout	Speaker
audio	beta:wd179x:3:525qd:floppysound	Floppy sound	44100
audio	speakers	Speaker

softwarelist

tag	name	status	filter
cass_list	spectrum_cass	original
cass_list_pen	pentagon_cass	original
betadisc_list	spectrum_betadisc_flop	original

device_ref

name
z80
address_map_bank
screen
palette
gfxdecode
speaker
speaker_sound_device
snapshot_image
quickload
cassette_image
software_list
ram
ay_slot
ay_ay8912
ay8912
betadisk
kr1818vg93
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
speaker
software_list
software_list

biosset

name	description	default
v1	Gluk 6.3r	no
v2	Gluk 5.2i	no
v3	Gluk 5.3	no
v4	Gluk 5.4	no
v5	Gluk 5.5r	no
v6	Gluk 5.5rr	no
v7	Gluk 6.0r	no
v8	Gluk 6.0-1r	no
v9	Gluk 5.1	no

sound

channels
6

ramoption

name	default
16K
1024K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
snapshot	snapshot				snapshot	dump
quickload	quickload				quickload	quik
cassette	cassette	spectrum_cass			cassette	cass
floppydisk	beta:wd179x:0:525qd	floppy_5_25			floppydisk1	flop1
floppydisk	beta:wd179x:1:525qd	floppy_5_25			floppydisk2	flop2
floppydisk	beta:wd179x:2:525qd	floppy_5_25			floppydisk3	flop3
floppydisk	beta:wd179x:3:525qd	floppy_5_25			floppydisk4	flop4

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
snapshot	snapshot				ach, frz, plusd, prg, sem, sit, sna, snp, snx, sp, z80, zx
quickload	quickload				raw, scr
cassette	cassette	spectrum_cass			wav, flac, tzx, tap, blk
floppydisk	beta:wd179x:0:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:1:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:2:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:3:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	1	8	no
keyboard	1	57		no
joy	2	1	8	no

port, analog

port_tag	analog_masks
:CONFIG
:JOY1
:JOY2
:LINE0
:LINE1
:LINE2
:LINE3
:LINE4
:LINE5
:LINE6
:LINE7
:NMI
:PLUS0
:PLUS1
:PLUS2
:PLUS3
:PLUS4

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
ay_slot	ay_ym2149	ay_ym2149	no
ay_slot	ay_turbosound	ay_turbosound	no
ay_slot	ay_ay8912	ay_ay8912	yes
beta:wd179x:0	35dd	floppy_35_dd	no
beta:wd179x:0	35hd	floppy_35_hd	no
beta:wd179x:0	525qd	floppy_525_qd	yes
beta:wd179x:0	525hd	floppy_525_hd	no
beta:wd179x:1	35dd	floppy_35_dd	no
beta:wd179x:1	35hd	floppy_35_hd	no
beta:wd179x:1	525qd	floppy_525_qd	yes
beta:wd179x:1	525hd	floppy_525_hd	no
beta:wd179x:2	35dd	floppy_35_dd	no
beta:wd179x:2	35hd	floppy_35_hd	no
beta:wd179x:2	525qd	floppy_525_qd	yes
beta:wd179x:2	525hd	floppy_525_hd	no
beta:wd179x:3	35dd	floppy_35_dd	no
beta:wd179x:3	35hd	floppy_35_hd	no
beta:wd179x:3	525qd	floppy_525_qd	yes
beta:wd179x:3	525hd	floppy_525_hd	no

configuration

Hardware Version

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hardware Version	CONFIG	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Issue 2	0	yes
Issue 3	128	no
