Pentagon 128K - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pentagon	sinclair/pentagon.cpp		no	no	no	yes	Pentagon 128K	1991	Vladimir Drozdov	spec128	spec128

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	352	288	48.828125	7000000	448	88	440	320	32	320	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no		v1
128p-1.rom	16384	b96a36be	80080644289ed93d71a1103992a154cc9802b2fa	maincpu	14000	good	no	zx128_1.rom	v1
128tr93.rom	16384	08ad241c	16daba547c644ef01ce76d2686ccfbff72e13dbe	maincpu	10000	good	no		v2
128p-1.rom	16384	b96a36be	80080644289ed93d71a1103992a154cc9802b2fa	maincpu	14000	good	no	zx128_1.rom	v2
pentagon.rom	32768	aa1ce4bd	a584272f21dc82c14b7d4f1ed440e23a976e71f0	maincpu	10000	good	no		v3
pent-es.rom	32768	34d04bae	6782c8c0ee77c40d6d3170a254894dae44ddc93e	maincpu	10000	good	no		v4
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no		v5
sos89r.rom	16384	09c9e7e1	29c567921abd377d2f9c088352c392a5a0858651	maincpu	14000	good	no		v5
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no		v6
basic90.rom	16384	a41575ba	44c5de86e765172b0af154fe3934643ce40bf378	maincpu	14000	good	no		v6
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no		v7
sos48.rom	16384	ceb4005d	d56c01ea7abdca178efb2b1c6b2866a9a38274ee	maincpu	14000	good	no		v7
128p-0.rom	16384	124ad9e0	d07fcdeca892ee80494d286ea9ea5bf3928a1aca	maincpu	10000	good	no		v8
m48a.rom	16384	a3b4def6	7ad59ca373876d452b0cf0ed5edb0e93c3176f1a	maincpu	14000	good	no		v8
zxvgs-22-0.rom	16384	63041c61	f6718097d939afa8881b4436741a5a23d7e93d78	maincpu	10000	good	no		v9
zxvgs-22-1.rom	16384	f3736047	f3739bf460a57e3f10e8dfb1e7120842938d27ea	maincpu	14000	good	no		v9
zxvg-29-0.rom	16384	3b66f433	d21df9e7f1ee99d8b38c2e6a32727aac0f1d5dc6	maincpu	10000	good	no		v10
zxvg-1.rom	16384	a8baca3e	f2f131eaa4de832eda76290e48f86e465d28ded7	maincpu	14000	good	no		v10
zxvg-30-0.rom	16384	533e0f26	b5f157c5d0da414ec77e445fdc40b78450129709	maincpu	10000	good	no		v11
zxvg-1.rom	16384	a8baca3e	f2f131eaa4de832eda76290e48f86e465d28ded7	maincpu	14000	good	no		v11
zxvg-31-0.rom	16384	76f43500	1c7cd52894847668418876d55b93b213d89d92ee	maincpu	10000	good	no		v12
zxvg-1.rom	16384	a8baca3e	f2f131eaa4de832eda76290e48f86e465d28ded7	maincpu	14000	good	no		v12
zxvg-35-0.rom	16384	5cc8b3b1	6c6d0ef1b65d7dc4f607d17204488264575ce48c	maincpu	10000	good	no		v13
zxvg-1.rom	16384	a8baca3e	f2f131eaa4de832eda76290e48f86e465d28ded7	maincpu	14000	good	no		v13
neos_512.rom	16384	1657fa43	647545f06257bce9b1919fcb86b2a49a21c851a7	maincpu	10000	good	no		v14
128p-1.rom	16384	b96a36be	80080644289ed93d71a1103992a154cc9802b2fa	maincpu	14000	good	no	zx128_1.rom	v14

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3500000
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	cassette	Cassette
audio	ay8912	AY-3-8912A PSG	1750000
audio	beta:wd179x:0:525qd:flopsndout	Speaker
audio	beta:wd179x:0:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:1:525qd:flopsndout	Speaker
audio	beta:wd179x:1:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:2:525qd:flopsndout	Speaker
audio	beta:wd179x:2:525qd:floppysound	Floppy sound	44100
audio	beta:wd179x:3:525qd:flopsndout	Speaker
audio	beta:wd179x:3:525qd:floppysound	Floppy sound	44100
audio	lspeaker	Speaker
audio	rspeaker	Speaker

softwarelist

tag	name	status
cass_list	spectrum_cass	original
cass_list_pen	pentagon_cass	original
betadisc_list	spectrum_betadisc_flop	original

device_ref

name
z80
address_map_bank
screen
palette
gfxdecode
speaker
speaker_sound_device
snapshot_image
quickload
cassette_image
software_list
ram
ay8912
betadisk
kr1818vg93
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
speaker
speaker
software_list
software_list

biosset

name	description	default
v1	Pentagon 128K	no
v2	Pentagon 128K 93	no
v3	Pentagon 128K (joined)	no
v4	Pentagon 128K Spanish	no
v5	Pentagon 128K SOS89R Monitor	no
v6	Pentagon 128K 1990 Monitor	no
v7	Pentagon 128K RaK(c) 1991 Monitor	no
v8	Pentagon 128K Dynaelectronics 1989	no
v9	ZXVGS v0.22 by Yarek	no
v10	ZXVGS v0.29 by Yarek	no
v11	ZXVGS v0.30 by Yarek	no
v12	ZXVGS v0.31 by Yarek	no
v13	ZXVGS v0.35 by Yarek	no
v14	NeOS 512	no

sound

channels
7

ramoption

name	default
16K
128K	yes

device, instance

type	tag	interface	name	briefname
snapshot	snapshot		snapshot	dump
quickload	quickload		quickload	quik
cassette	cassette	spectrum_cass	cassette	cass
floppydisk	beta:wd179x:0:525qd	floppy_5_25	floppydisk1	flop1
floppydisk	beta:wd179x:1:525qd	floppy_5_25	floppydisk2	flop2
floppydisk	beta:wd179x:2:525qd	floppy_5_25	floppydisk3	flop3
floppydisk	beta:wd179x:3:525qd	floppy_5_25	floppydisk4	flop4

device, extension

type	tag	interface	extension_names
snapshot	snapshot		ach, frz, plusd, prg, sem, sit, sna, snp, snx, sp, z80, zx
quickload	quickload		raw, scr
cassette	cassette	spectrum_cass	wav, flac, tzx, tap, blk
floppydisk	beta:wd179x:0:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:1:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:2:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd
floppydisk	beta:wd179x:3:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, trd

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse
joy	1	1	8	no
keyboard	1	57		no
joy	2	1	8	no

port, analog

port_tag	analog_masks
:CONFIG
:JOY1
:JOY2
:LINE0
:LINE1
:LINE2
:LINE3
:LINE4
:LINE5
:LINE6
:LINE7
:NMI
:PLUS0
:PLUS1
:PLUS2
:PLUS3
:PLUS4

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
beta:wd179x:0	35dd	floppy_35_dd	no
beta:wd179x:0	35hd	floppy_35_hd	no
beta:wd179x:0	525qd	floppy_525_qd	yes
beta:wd179x:0	525hd	floppy_525_hd	no
beta:wd179x:1	35dd	floppy_35_dd	no
beta:wd179x:1	35hd	floppy_35_hd	no
beta:wd179x:1	525qd	floppy_525_qd	yes
beta:wd179x:1	525hd	floppy_525_hd	no
beta:wd179x:2	35dd	floppy_35_dd	no
beta:wd179x:2	35hd	floppy_35_hd	no
beta:wd179x:2	525qd	floppy_525_qd	yes
beta:wd179x:2	525hd	floppy_525_hd	no
beta:wd179x:3	35dd	floppy_35_dd	no
beta:wd179x:3	35hd	floppy_35_hd	no
beta:wd179x:3	525qd	floppy_525_qd	yes
beta:wd179x:3	525hd	floppy_525_hd	no

configuration

Hardware Version

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hardware Version	CONFIG	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Issue 2	0	yes
Issue 3	128	no
